Outdoor Waterproof Full Color SMD3535 4000cd/㎡ Brightness Shopping Mall Led Advertising Screens

Brand Name:	SCXK
Model Number:	P8
MOQ:	2sqm
Price:	negotiation
Payment Terms:	Western Union, MoneyGram, D/P, T/T, L/C
Supply Ability:	5000sqm per month

Detail Information

Product Description

Detail Information

Place of Origin:

Shenzheng, China

Certification:

CE/ROHS/FCC/ISO/UL

Pixels Pitch:

8mm

LED Chip:

Epistar, Kinglight

Cabinet Material:

Iron Or Die-casting Aluminum For Option

Module Size:

320mm*160mm

Working Voltage:

DC5V

Warranty:

2~5 Years

Pixel Density:

15625dots/sqm

Driving Mode:

1/4scaning

Certificates:

CE, RoHs, FCC, ISO

Packaging Details:

flight case, wooden case, carton, it is up to you.

Highlight:

4000cd/㎡ Outdoor Led Advertising Screens

SMD3528 Outdoor Led Advertising Screens

6500 Nits Led Advertising Board

Product Description

P8 Professional Outdoor Digital SMD LED Screen Comercial Advertising 3 Years Warranty

Protection Rate IP65 and Module Style Design

The special waterproof design of P8 SMD Outdoor LED Billboard protects it from water and dust. When instalLED in outdoor areas, protection is a serious matter. Special guard protects it from environment dangers. High IP Rating IP65 ensures great quality outputs in every condition.

Unique Design - Easy to Install & Transport

The cabinet of PH8 LED Display Price features unique rugged design which makes it easy to carry and install. The lightweight cabinet is easy to carry and saves transportation cost. It's damage free and lasts for a lifetime. Pick out from different standard colors of cabinets.

The Advantages of P8 Advertising Led Screens.

1. High brightness, ≥4000cd/㎡, is the only large display terminal that can be used all day in outdoors.
2. Long life span, ≥ 100,000 hours.
3. Large viewing angle. The Indoor angle of view is ≥ 160 degrees, the outdoor viewing angle is ≥ 120 degrees.
4. An Intelligent control system, two kinds of systems, directly controlled by computer, or by WiFi.
5. Compared with the Lcd display, the led display can be arbitrarily formed into a shape and seamlessly spliced.
Technical Parameters of P8 Advertising Led Screens

			Pixel pitch(mm)
			8mm

			LED Type
			SMD3535

			Pixel composition
			1R1G1B

			Scan method
			1/8

			Screen brightness(cd/sqm,nit)
			>6500nits(adjustable)

			Average power consumption(W/sqm)
			305

			Maximum power consumption(W/sqm)
			610

			Module resolution(dot)
			32dotsX16 dots

			Module size(mm)
			256mmX128mm

			Pixel density(dots/sqm)
			15625dots

			Viewing distance(m)
			8-150m

			Pixel weight
			350g

			Pixel power(max)
			16 W/PCS

			Visual range
			>8 m

			Grey Grade
			≥10 BIT

			Color temperature
			11000±500K

			Viewing angle
			Lever: 105° vertical: 50°

			Life span
			>50,000hours

			Working temperature(Celsius degree)
			-10~+50'

Outstanding Outdoor Performance
The displays are created for supreme quality outdoor performance, and it delivers the same with perfection. See pictures, videos, text and much more with every detail. The high resolution display offers picture-perfect outputs in outdoor areas - in any environment conditions.

The Advantages of our Products
1. The product structure is resistant to 100 Km / h wind and 8 earthquakes.

2. With excellent waterproof performance, safe and reliable power system.

3. All components of the product can be processed according to customer requirements.

4. All materials are environmentally friendly materials.

5. The life of the product is more than 5 years.

6. The warranty is for 2~5 years.

7. We can provide additional installation, permanent technical supports, and training services.

Control System

Certificates:

♦ Our Mission:

To be the premier providr of creative, marketing and innovative solutions devoted to helping other companies succeed and grow.

Why Choose us?

Packing&Shipping

Packing: wooden case, flight case for choose.

shipping: by air, sea, train, DHL, you are the boss.

Outdoor Waterproof Full Color SMD3535 4000cd/㎡ Brightness Shopping Mall Led Advertising Screens 7

FAQ

1. How can I place an order?
Please provide the details of your requirements as clear as possible. So we can send you the offer at the first time. For designing or further discussion, it is better to contact us with Skype/email /Whatsapp, in case of any delays.

2. What kind of display do we provide?
We have indoor/outdoor/mobile LED /rental LED display /LED stage/ Advertising LED display for you to choose. The customized service also could be provided.

3. What about the lead time for an order?
Always: 7-17 days after receiving your payment, as your order quantity, sometimes we have stock, can delivery within 7 days.

4. What about the warranty?
We have 2~5 years of quality guaranteed, spare parts such as the led module, receiving card, control card, power supply are damaged not cause of artificial damaged, then it's free maintenance and ship back new ones for replacement.

5.How about the quality?

Our led products must be testing of at least 72hours before shipping, from purchase raw materials to ship, Each step has strict quality control systems to ensure led display with good quality.

6. Can you offer technical support? Since it's my first time....
We provide free training for our customer, teach the client how to set up screens, make configuration of parameters, broadcast the videos through Nova star and colorlight or Linsn control systems, our engineer can directly teach you how to control, or help you to do if you are really don't know how to control(Our Engineer can text English, we can saving more time ).

Tags:

Pixel pitch(mm)	8mm
LED Type	SMD3535
Pixel composition	1R1G1B
Scan method	1/8
Screen brightness(cd/sqm,nit)	>6500nits(adjustable)
Average power consumption(W/sqm)	305
Maximum power consumption(W/sqm)	610
Module resolution(dot)	32dotsX16 dots
Module size(mm)	256mmX128mm
Pixel density(dots/sqm)	15625dots
Viewing distance(m)	8-150m
Pixel weight	350g
Pixel power(max)	16 W/PCS
Visual range	>8 m
Grey Grade	≥10 BIT
Color temperature	11000±500K
Viewing angle	Lever: 105° vertical: 50°
Life span	>50,000hours
Working temperature(Celsius degree)	-10~+50'
