Place of Origin:	China
Brand Name:	SCXK
Certification:	CE/ROHS/FCC/ISO/UL
Model Number:	P8，P10

Minimum Order Quantity:	10sqm
Price:	negotiation
Packaging Details:	wooden case and flight case can be choose.
Delivery Time:	7-12 working days
Payment Terms:	L/C, Western Union, MoneyGram
Supply Ability:	5000sqm per month

Cabinet Material:	Ironed Steel Cabinet Or Die Casting Aluminum	Cabinet Size::	960mm*960mm
Module Size::	320mm*160mm	Pixel Density::	10000 Dots/sqm
Brightness Of White::	7500cd/sqm	IP Rating::	IP65/IP54
Application::	Rental Display	Cabinet Material::	Die Casting Aluminum
Cabinet Weight::	26kg	Display Function::	Video
Screen Dimension::	Customized Size
High Light:	960x960mm Cabinet Stadium LED Display , 7500cd/sqm Stadium LED Display , IP65 Stadium Perimeter Led Display

model		P10
Pixel unit module	Pixel pitch(mm)	10
	Pixel density (dots/sqm)	10000
	LED type	SMD
	Module size(mm)	W320×H160
	Pixel composing	RGB full color
Pixel unit screen	screen size(mm)	960*960mm
	module Resolution (nits)	32*16
	Cabinet structure	Water-proof
	installation	fixed on the back
	screen material	magnesium alloy
	Protect degree	IP65 front ,IP54 rear
	Viewing distance(m)	10~100m
	Brightness(cd/sqm)	7000 cd/sqm or 7000 nits or more
	Power consumption (w/sqm)	Max 900W/sqm ,can be custom make 500W max
	Driving IC	1/4 scan MBI Brand Driver
	Refresh rate(HZ)	≥2000- 3000
	Viewing angel(c)	H120 V110
Other parameter	Image adjustment	contrast, tonal, the color saturation, gray calibration coefficient, color range, image variable times, etc
	Image processing	Video noise reduction, fast motion compensation, edge to sharpen, edge smooth, color space transformation and control, coordinate transformation of grey scale, etc
	Brightness uniformity	The whole screen on the monochrome, minimum pixel luminance and the brightest pixel luminance than more than 0.9
	Gray	65536
	Color temperature/contrast	Red, green, and blue brightness and contrast can through the software level 100 adjustable, color temperature can be adjusted according to need
	Transmitting Distance	The shielded twisted-pair cable transmission distance for 100 meters, the biggest up to 140 m. Multimode fiber of up to 500 meters, the single-mode optical fiber to 20 kilometers
	Input Signal	RF,S-VIDEO,RGBTV,YUT,YC,COMPOSITION
	Control System	PCTV non-liner editing card+DVI display card+main control card+optic fiber transmission(Optional) or video dealer
	Average No Failure Time	20000 hours
	Life span	100,000 hours
	Out-of Control rate	0.0001
	To floor drain current	Less than 3.5MA
	Control system	Synchronized
	Operating Environment Temperature	-20°C—65°C Optional

P10 960x960mm Cabinet 7500cd/sqm Stadium LED Display IP65

P10 960x960mm Cabinet 7500cd/sqm Stadium LED Display IP65

960x960mm Cabinet Stadium LED Display

7500cd/sqm Stadium LED Display

IP65 Stadium Perimeter Led Display

Outdoor Led Panels P10 Football Stadium Perimeter 960*960mm Advertising Led Screen Display

FAQ

Q1: Are you a factory or trading company?

A: We are a factory, warmly welcome to visit us.

Q2: How can I get some samples?

A: We are honored to offer you samples.

Q3:How long the delivery time?

A: 7 days to 18 days, depends on exact project.

Q4: How does your factory do regarding quality control?

A: Quality is priority. Shenzhen people always attach great importance to quality controlling from the very beginning to the very end.

Q5: What is your after-sale service?

A: We offer 100% guarantee on our product .

Q6: What is your MOQ?

A: Any quantity is acceptable for your order.

And the price is negotiable for large quantity.
