Shenzhen Shichuangxinke Electronics Co.,Ltd
professional makes good quality, provide perfect product and service for every customer.
 |
| Place of Origin: | CHINA |
| Brand Name: | SXCK |
| Certification: | CE/ROHS/FCC/ISO/UL |
| Model Number: | P10 |
| Minimum Order Quantity: | 10 sqm |
|---|---|
| Price: | negotation |
| Packaging Details: | plywood case, flight case, you choose what you like. |
| Delivery Time: | 7-15 working days |
| Payment Terms: | T/T, Western Union, MoneyGram |
| Supply Ability: | 5600 sqm per month |
| Application:: | Outdoor Stadium Advertising Led Display | Color: | Full Color |
|---|---|---|---|
| Panel Size:: | 960x960mm | Pixel Pitch:: | 10mm;8mm,6mm |
| Installation Type:: | Standing Type | Brightness:: | 6000nits |
| Refresh Rate:: | ≥1920Hz | IP Rate:: | IP65 |
| Life Span:: | 100000 Hours | Panel Weight (kgs):: | 32 |
| Screen Height:: | 0.96m (close To 1m) | Certificate:: | CE ROHS FCC EMC |
| High Light: | 6000nits Sport Score Led Display,1R1G1B Sport Score Led Display,SMD3535 Outdoor Perimeter LED Screen |
||
1. The first level LED chip from Taiwan Epistar
2. With pure golden wire connection in LED
3. Grand A row material for module frame and mask
4. 4 layers PCB and copper plating thickness > 18mil
5. Stainless steel screws when assembly
6. Disassembly and assembly are quick and easy
7. 3 to 5 years warranty
8 .Energy-saving 60% : driving with low frequency current, heat-dissipated roller fans with automatic temperature-controlling device.
9 .Life time >11 years;
Parameter specification
Module:
| Pixel pitch | 10mm |
| Pixel configuration | 1R1G1B |
| LED type | 3-in-1 SMD3535 |
| Module size | 320x160mm |
| Module resolution | 32*16dots |
Cabinet Parameter:
| Cabinet size | 960x960mm |
| Cabinet material | ironed steel cabinet |
| Cabinet weight | 27.5kg |
| Cabinet resolution | 96*96dots |
| Ingress protection | Front/Rear IP65/IP54 |
| Pixel density | 10000dots/m² |
| Brightness | ≥5000cd/m² |
| Viewing angle | H≥120° V≥60° |
| Min.viewing distance | 10m |
| Max.power consumption | 850W/m² |
| Avg.power consumption | 280W/m² |
| Working voltage | 110~220VAC±15% |
| Interface | HUB75 |
| Colors | 16.7millon colors |
| Gray level | 14-16bits |
| Refresh rate | ≥960Hz |
| MTBF | ≥100,000 hours |
| Lifespan | ≥100,000 hours |
| Protective function |
Over-heat/Over-load /Power-down /Power-leakage /Lightning-protection etc. |
| Operating temperature | -10℃ ~ +40℃ |
| Operating humidity | 10-80% no condensation |
| Storage temperature | -20℃ ~ +60℃ |
| Storage humidity | 10-85% no condensation |
Control System Parameter:
| Video signal (with video processor) | AV, S-video,VGA, DVI, YPbPr, HDMI, SDI, DP |
| Color temperature | Adjustable by software |
| Brightness level | 256 levels, automatic adjustment by software |
| Control way |
Computer, video-synchronous, real-time, off-line, wireless, internet etc. |
Our case
Certificate
Packaging and shipping
Packing:1.wooden case packing for ironed steel cabinet.
2.flight case packing for die casting aluminum cabinet.
Delivery:Shipping by sea,air or DHL,multiple shipping ways for your choice.
A: 24 Hours After sales support,professional support,manual book, and remote control if customer need it,not only sell display to you,but more supports.
B: Real Taiwan Chip + High quality suit, CE,ROHS,FCC certification factory.
C: Sure Dispaly from factory is 100% test done and not any quality problems, we will responsibile it if have any quality problems.
D: We offer 2 years warranty to our product.
E: Customized design is available.
F: Special discount are offered based on order quantity. Welcome to contact us.
FAQ
Q1. Can I have a sample order for led Display?
A: Yes, we welcome sample order to test and check quality. Mixed samples are acceptable.
Q2. What about the lead time?
A:Sample needs 3-5 days, mass production time needs 10-15days for order quantity more than
Q3. Do you have any MOQ limit for led light order?
A: Low MOQ, 1pc for sample checking is available
Q4. How do you ship the goods and how long does it take to arrive?
A: We usually ship by sea because led display volume . It usually takes 20 days to arrive. Airline DHL, UPS, FedEx or TNT and sea shipping also optional.
Q5. How to proceed an order for led Dispaly?
A: Firstly let us know your requirements or application.
Secondly We quote according to your requirements or our suggestions.
Thirdly customer confirms the samples and places deposit for formal order.
Fourthly We arrange the production.
Q6. Is it OK to print my logo on led light product?
A: Yes. Please inform us formally before our production and confirm the design firstly based on our sample.
Q7: Do you offer guarantee for the products?
A: Yes, we offer 3-5 years warranty to our products.
Q8: How to deal with the faulty?
Contact Person: BOSCO
