1000nits Smd2121 Free Standing Poster Display 300W For Advertising



Led Poster Specification:

Item	Parameter
Pixel pitch	PH2.5mm
Pixel configuration	1R1G1B
LED type	SMD2121
Module size	192x192mm
Module resolution	64*64dots
Cabinet resolution	640*192pixels
Cabinet size	2000x630mm(h*l)
Cabinet material	Steel
Density	122880pixels
Brightness	≥1200 cd
Scan method	1/32S
Best view distance	≥3m
Max. power consumption	900W/pc
Ave. power consumption	300W/pc
Weight	36.5kg/pc
Grey scale	R(256bit) x G(256bit) x B(256bit)
Colors	sR(1024) x G(1024) x B(1024)
Refresh rate	1920HZ
View angle	Horizontal: 140°, Vertical: 140°
Frame frequency	≥1920Hz
Out of control pixel rate	<1/10000
MTBF	>5,0000 hours
Lifespan	100,000 hours
Control mode	Synchronous display with control PC by DVI
Working voltage	AC 100/200v 50-60Hz
Operation temperature	-40 to +50
Operation Humidity	10% to 80%
Protection level	IP43 front, IP31 back



Case



Why choose us

Continues Quality

With more than 10 years experience in led display,equipments are updated regularly.What’s more,unique standardized and module production ensure our products continuous quality.



Competitive Price

With large scale production capacity and professional production technology,our company have built effective modular production.We always stick to promote the technical innovation and reduce cost to benefit customers.



Fast Delivery

Once we promise the delivery date,we will try our best to fulfill it.Special procedures such as emergency inventory will be used to maintain your uninterrupted supply of the products.



Perfect Service

Pre-sales:Your purchasing requirements will be highly valued and we’ll recommend suitable products to you.

After-sales:We will track the products usage and then constantly perfect our products.

Update your content with our built in media player via Wifi or USB. input and output allows external 3rd party software

Multi-Screen

Poster LED can be used as a video wall wirelessly. Creative freedom with mirroring and extended mode.



Wireless Multi-Screen

Link up to three poster LED together and stay connected via wireless connection.

Mirroring Mode

Show the content of on one display on other displays simultaneously

Extended Mode

Split and show the same piece of content on multiple poster displays at the same time creating a large surface video display.

The LED display is the final completed product for advertising or information showing, it was composed by a certain rows and lines of unit LED cabinet;the unit LED cabinet were composed by module certain quantity of LED modules, each LED module were composed by 16*16/16*8/8*8/4*4/1*1 LED pixels; each LED pixels were composed by 2R1G1B/2R2G1B/2R1B/2R1G/2R/1R…. .



2. What is virtual pixel, real pixel?

Real LED pixel is the physical LED pixel; virtual LED pixel is theoretically 4 times higher than real LED pixel. Actually, the real effect of the virtual pixel is not really 4 times better. It is only a much better, but not really can be 4 times better. When you LED display system is more than 640*480pixels, actually you don’t need to use virtual pixel if you plan to use the whole LED display for one advertising contents.

The most important reason why use virtual pixel is the red LED lamp’s brightness is not strong enough to match with the green and blue LED lamps to get the most pure white color. The virtual pixel is not popular any longer since the red lamp’s brightness is high enough now



3. What is dot correction, why it is better than the common control system?

Dot correction is a new technology and will be the direction of future LED display industry. The much more improved color consistence & high fresh frequency make it be the only solution for high level advertising need.



4. How to choose the rational product model of the LED display

Corresponding with the LED display’s best viewing distance, size, application & installation, there will be many optional product models fit for each specific project. ROI & Budget is also very important factors.



5. What is the best viewing distance, how to calculate the best viewing distance of the LED display

Best viewing distance refers to the distance from the LED display, where the people can see a whole and clear picture of the image on the LED display.There’s 2 ways to calculate the best viewing distance: one is by the pixel pitch, one is by the diagonal. There’s also the reason why there’s different viewing distance for same model LED display, also different viewing distance for same size LED display.



6. Why there's different viewing distance for same model of the LED display & different viewing distance for same size of the LED display.

There’s 2 ways to calculate the best viewing distance: one is by the pixel pitch, one is by the diagonal. There’s also the reason why there’s different viewing distance for same model LED display, also different viewing distance for same size LED display.



7. What is multi-function card? What is sending card, receiving card & hub card of the LED display system:

Multi-function card can help the LED display screen system achieve many functions, such as automatic False Alarms, fire & smoke alarms, brightness adjustment, etc.

Sending card, receiving card & hub card is the LED display screen’s control system. Sending card is installed in the controlling PC, is the data sending equipment; receiving card is installed in each cabinet, is the data receiving equipment; hub card is installed together with each receiving card, is the data distribution equipment. All the above composed the main necessary parts of the control system



8. What is selected LED, what is pure green & pure blue? Why the full color LED display need selected LED & also pure green & pure blue LED.

For the common LED chip, the wave length difference is very big and the brightness difference is very big too if not selected LED.The selected LED means the LED is choose from a certain ratio of LED to choose the most consistent LED.

Pure green & pure blue means the choose the green and blue LED chips strictly by the standard of main wavelength: G: 518-520, B: 466-468

Full color LED display need pure green & pure blue LED chip since if not it cannot achieve high gray grade and the image will be very poor.



9. What is the brightness control, how to achieve automatic brightness control?

BGX Brightness control is needed since the environment brightness level is changing during the daytime. If you don’t adjust the brightness to the environment, the LED display screen system will not have a perfect viewing effect.

There’s two ways to achieve the brightness control: manually changing & automatic changing. The automatic brightness changing can adjust the LED display screen system’s brightness perfectly to the environment brightness level.

For more questions, please contact me of RGX LED direct OEM manufacturer right now! Welcome any question!



9, Our Advantage:

1) Competitive price with high quality

2) Professional manufacturer

3) Exquisite quality

a: ISO 9000 and 5S management system

b: Each procedure have special machine and QC to supervise and check

c: From the material purchasing, all have the special Equiment to stakeout



4) Perfect service

a; 2-3years guarantee with free charge, maintain in all life

b: Free training in our company or guide installation and train in customer country or on lone training by long-distance control in internet

c: Regular training and meeting in each month for all customers, provide strong technology for each customer at the first time



5) Delivery date is quick and on time

6) New product exploring



Collecting the customers ideas combined with the LED Market requirement, gradually perfect the LED signs functions, on meanwhile research the new LED signs to satisfy the customer demands.

We sincerely to client, we make everything the same as we promise in the contract.
