Shenzhen Shichuangxinke Electronics Co.,Ltd
professional makes good quality, provide perfect product and service for every customer.
 |
| Place of Origin: | China |
| Brand Name: | SCXK |
| Certification: | CE/ROHS/FCC/ISO/UL |
| Model Number: | P3.91 |
| Minimum Order Quantity: | 1 sqm |
|---|---|
| Price: | negotiation |
| Packaging Details: | wooden case or flight case. |
| Delivery Time: | 5-8 days |
| Payment Terms: | T/T, Western Union, MoneyGram |
| Supply Ability: | 5000sqm per month |
| IC&lamp: | MBI5124 SMD2121 | Pixel Density: | 65410dots/m2 |
|---|---|---|---|
| Module Size: | 250x250mm | Cabinet Size: | 500x500mm Or 500x1000mm |
| Brightness: | >1200cd | Power Supply: | G-energy |
| High Light: | p3.91 curved led screen,high refresh rate curved led screen,p3.91 curved led display |
||
High refresh rate outdoor P3.91 curved LED Screen G- Energy Power Supply
Description of Rental LED Screen
outdoor led digital billboards pixel include 4mm, 5mm, 6.67mm, 8mm, 10mm, 16mm, within these pixels, 4mm, 5mm, 6.67mm are the most hot-selling and highest cost-effective series. You can use it on car for advertising or fixed in some place as billboard or on building.
Product specifications
1. Same cabinet design for indoor & outdoor, rental & fixed installation application
2. Tthere are flat & curve LED Screen, and Rear & Front maintenance for choice
3. Two cabinet size: 500mmx500mm and 500mm*1000mm
4. Super high quality with popular design, stable long efficient working time,quality guranteed!
5. Its very easily replace the model & board in time; Avoiding more trouble and saving much time for after-salesmaintenance.
Module Parameter:
| Pixel pitch | 3.91mm |
| Pixel configuration | 1R1G1B |
| LED type | 3-in-1 SMD 2121 |
| Module size | 250x250mm |
| Module weight | 0.4kg |
| Module resolution | 64x64dots |
| Module quantity per cabinet | 4pcs |
Cabinet Parameter:
| Cabinet size | 500x500mm,500x1000mm |
| Cabinet material | die- casting aluminum |
| Cabinet weight | 6.4kg |
| Cabinet resolution | 128:128 dots |
| Ingress protection | Front/Rear IP65/IP54 |
Whole Screen Parameter
| Pixel density | 65410 dots/m² |
| Brightness | ≥1200 cd/m² |
| Viewing angle | H≥120° V≥120° |
| Min.viewing distance | 4m |
| Max.power consumption | 800W/m² |
| Avg.power consumption | 280 W/m² |
| Working voltage | 110~220VAC±15% |
| Interface | HUB75 |
| Colors | 16.7millon colors |
| Gray level | 14-16bits |
| Frame frequency | ≥60frames/s |
| Refresh rate | ≥480Hz |
| MTBF | ≥10000 hours |
| Lifespan | ≥50000 hours |
| Protective function |
Over-heat/Over-load /Power-down /Power-leakage /Lightning-protection etc. |
| Operating temperature | -10℃ ~ +60℃ |
| Operating humidity | 10-80% no condensation |
| Storage temperature | -20℃ ~ +60℃ |
| Storage humidity | 10-85% no condensation |
Control System Parameter:
| Video signal (with video processor) | AV, S-video,VGA, DVI, YPbPr, HDMI, SDI, DP |
| Color temperature | Adjustable by software |
| Brightness level | 256 levels, automatic adjustment by software |
| Control way | Computer, video-synchronous, real-time, off-line, internet etc. |
Cabinet details
Certificate
Packaging and shipping
Wooden case or flight case package are available.
Shipping by sea,air or DHL,multiple shipping ways for your choice.
Our service
Flexible design and concepts according to your project requirements and cost budget Professional solution that supports your special business requirements.
Pre-sale Service
Providing pre-service instructions and product knowledge training.
Providing competitive products and sales consultation.
Providing instructions on designing and decorating exhibition halls.
Providing regional distribution guarantee.
In-sale Service
Developing customized products.
Providing product documents and qualification certification.
Assisting in business negotiation in projects according to specific conditions.
Assisting in on-site measurement.
After-sale Service
Providing perfect logistics system to guarantee punctual delivery.
Providing training and support for installation staff and after-sale service staff.
Providing training on product features, operation, repair, maintain of products.
Providing support for debugging and problem checking.
Providing two-year quality guarantee.
Tracking Service
Inspecting and re-checking the quality of the pre-sale service, in-sale service, and after-sale service
Quality Guarantee
Quality Guarantee: High standard, precision and zero defects
Save your time and money with us!
