P6 Outdoor Waterproof IP65 LED Display Billboard Naked Eye 3D LED Display Screen

P6 Outdoor Waterproof IP65 LED Display Billboard Naked Eye 3D LED Display Screen

  • P6 Outdoor Waterproof IP65 LED Display Billboard Naked Eye 3D LED Display Screen
  • P6 Outdoor Waterproof IP65 LED Display Billboard Naked Eye 3D LED Display Screen
  • P6 Outdoor Waterproof IP65 LED Display Billboard Naked Eye 3D LED Display Screen
  • P6 Outdoor Waterproof IP65 LED Display Billboard Naked Eye 3D LED Display Screen
P6 Outdoor Waterproof IP65 LED Display Billboard Naked Eye 3D LED Display Screen
Product Details:
Place of Origin: CHINA
Brand Name: SCX
Certification: CB,CE,UL
Model Number: outdoor p6
Payment & Shipping Terms:
Minimum Order Quantity: 12 sqm
Price: negotiation
Packaging Details: wooden case,flight case
Delivery Time: 3-16 working days
Payment Terms: L/C, T/T, Western Union, MoneyGram
Supply Ability: 2900sqm per sqm
Contact Now
Detailed Product Description
Brightness: 7000nit Power: MW
Leds: Kinglight And Nationstar Waterproof: 100%
Refresh Rate: 3840hz Warranty: 5years
High Light:

P6 LED Display Billboard

,

Waterproof LED Display Billboard

,

7000nit LED Display Screen

P6 Outdoor Waterproof IP65 Fixed Installation LED Display Billboard /Outdoor LED Adverti Naked Eye 3D LED Display Screen

Product Advantage

1.Light ball:
Our company adopts high quality SMD3535 , from raw material processing to encapsulation technology to quality control, we are all more trustworthy than market three without products !
2.Chip:
The solid crystal, gold wire bonding, precision testing of the leading LED packaging technology, equipping with advanced automatic production line and production equipment, the international leading quality inspection and reliability test equipment, guaranteeing the effect of chip quality LED display screen refresh rate is higher.
3.Border:
From details to ensure product quality.The frame thickness is 0.5mm above the market, which is more durable and durable.Surface level not to drop paint, work fine and more beautiful.
4.Factory strength:
Our company focus on full color LED display screen and LED technology industry production, sales and service, our company has the industry advanced, complete automatic rapid assembly lines, production capacity output high on industry.Worldwide commitment and fulfillment of user professional services and guidance.
5.High gray high brush:
The sun is still bright and bright picture, the display is natural and true, each module has been through the point brightness and chroma correction, brightness and color uniformity.
High waterproof and dustproof rating (before IP65), strong anti-seismic ability to adapt to extreme weather
Flatness: the whole screen: ≤ ± 1mm patchwork between the module: ≤ 1mm
Viewing distance: 8-200m, the display is clearly visible
Image adjustment: Contrast / tone adjustment / single mode group brightness adjustment

Our Service

1.Pre-sales service:
Our team design and make solutions based on different requirements from different customers, what you think is what we can do.
2.After-sales services:
1). We provide customer service through Skype, phone or email, supply you video or drawing to solve problems.
2). We provide remote control service through internet to achieve real time service, which will short time of solving problems.
3). We provide professional engineer one-to-one to keep fastly reply.
3.Installation Service:
1). We provide detailed CAD drawing to customer for preparing metal structure.
2). We could dispatch our engineer to your place , guide installation and free training.
3). Special designs have special solutions; we will make perfect solutions to satisfy all customers' requirements.



Resolution/mm 6
Pixel configuration 1R1G1B
Pixel density/pixels/m^2 27778/m^2
Module resolution 32dotsx32dots
Module size/mm 192x192mm
View distance 10-200m
Single point brightness adjust Can be added
Single point color adjust Can be added
White balance brightness 6000 cd/m^2
Color temperature 6500K-9500K
Horizontal view angle 120(degrees)
Vertical view angle 60(degrees)
Signal Process bit 10 or 16bit
Grey process 1024x1024x1024 16834x16834x16834 65536x65536x65536
Control distances Internet cable:100m, multimembrane:500m, monofilm:2km
Driving mode Constant driving current
Scanning mode 1/8scan
Frame rate 60Hz
Refresh frequency >3000Hz
Control mode Computer synchronous
Brightness adjusted range

Manual, automatic operation, stepless continuous adjusted

255 steps. No grey loss

Out of control point <1/10000
Working hours ≥72hours
Mean Time Between Failure >10000hours
Life time 100000hours
Life-all-white(brightness halving) 100000hours
Environment temperature range Operating temperature range: -20-45℃
Maximum power:/^2 <700W
Average power:/^2 <200W
Self-check technology

LED spot self-check, communications check, power check,

temperature monitor(need customization)

Remote monitoring

Remote supervision and control, record potential fault,

send out warning signs to the operators.(need customization)

Software environment WindowsNT,Windows1999,WindowsXP
Luminous point width between centres Deviation<3%
Brightness uniformity <10%
Color uniformity(chromaticity coordinate) ±0.003
Power supply request AC85-264V(50Hz-60Hz)
Contrast (1000:1)
System protection Moistureproof,dustproof,high temperature protection,anti-corrosion,anti-burning,anti-static,anti-vibration
Humidity(working) working:10-95%
Humidity(storing) storing:10-95%






Specifications:
Indoor Outdoor LED Screen (Part of it, contact in detail)

Outdoor led module display panel p3 p4 p5 p6 p6.25 p8 p10 p16 led wall window screen p3 p4 p5 p6 p6.25 p8 p10 p16 outdoor fixed ultra slim led screen for building, factory, stadium, restaurant, publicity, street .…

With high refresh rate, high brightness, and fast assembling.
With waterproof, light & thin, and good heat dissipation.
Warranty for 5 years . no dead lamp and long time working hours .
Product Name
p3
p4
p5
p6
p6.25
p8
p10
p16
Module Size(W*H)mm
192*192
256*128
320*160
192*192
200*100
256*128
320*160
320*160
320*320
256*128
256*256
Color
full color
Brightness(nits)
≥5000nits—≥7000nits
Refresh rate
1920/3840HZ/5760HZ
Pixel Densitydots/㎡
111111
62500
40000
27777
25600
15625
10000
3906
Working Voltage
AC220±10% AC110±10% 50/60Hz
Screen life
≥100000 hours
Operating temperature
-45℃~+85℃
Control System
Linsn, Nova-star, Colorlight or as you required
Certificate
CE, RoHS, FCC,UL ,EMS, SASO,GS,INMETRO

Led screen video wall

P6 Outdoor Waterproof IP65 LED Display Billboard Naked Eye 3D LED Display Screen 0P6 Outdoor Waterproof IP65 LED Display Billboard Naked Eye 3D LED Display Screen 1



Super brightness single color LED billboard advertising

In the led billboard /panel series, The module design of the LED display enables you to create customized screen surfaces of virtually any size in either 4:3 or 16:9 ratios. Typically the LED display series are applied to large public squares. sport centers casino signage,public service announcement displays,media,commercial promotion and other large scale applications.

1, Superb brightness and color uniformity and reproduction. Brightness variances within+/-2.5%

2, High reliability: data hot backup aims to avoid any communication risks during the show; support automatic fault detection
