| Brand Name: | SCX |
| Model Number: | ourdoor p5 |
| MOQ: | 8 SQM |
| Price: | negotiation |
| Payment Terms: | L/C, T/T, Western Union, MoneyGram |
| Supply Ability: | 3900 sqm per month |
Product Features:
1. High brightness over 6500nits by using Epistar big LED chip from Taiwan.
2. High color output: 16 bit color so the video,images shown on the LED screen is very fresh and vivid. It catches the eyes of more audiences,making your advertising very effient.
3. High refresh rate over 3840HZ/S;when you take photoes or video,no scaning lines.
4. High waterproof function: IP65. Our cabinet backdoor has special cover,no need make additional frame to protect waterproof from the rear side.
5. Brightness can be automatically adjusted according to the real-time environment.
6. Front or rear maintenance option, realizing module, power supply and receiving card front or rear maintenance, saving your maintenance cost.
| No | Item | Parameter |
| 1 | Pixel Pitch | 5mm |
| 2 | Pixel Configuration | 1R1G1B / R:G:B=3:6:1 |
| 3 | LED Lamp | Full color |
| 4 | Density | 40000dot/m2 |
| 5 | Module Size | 320*160mm |
| 6 | Module Thickness | 17mm |
| 7 | Module Weight | 395g |
| 8 | Module Power | ≤63W |
| 9 | PortType | HUB-75D/B |
| 10 | Caninet Size | Customized size |
| 11 | Cabinet Weight | 35KGS/m2 |
| 12 | Brightness | ≥6500cd/m², Level 16- Automatic / Level 100-Manual operation |
| 13 | View Angle | ≥120°(Vertical),≥120°(Horizontal) |
| 14 | Best View Distance | 5-100m |
| 15 | Grey Scale | Within 65536 Step |
| 16 | Frame Frequency | ≥60Hz |
| 17 | Refresh Rate | ≥3840Hz |
| 18 | Scan Mode | 1/8 |
| 19 | Drive IC | 5020 |
| 20 | Max. power consumption | 850W/m2 |
| 21 | Ave. power consumption | 420W/m2 |
| 22 | Protection grade | IP65 |

Our service
1. OEM Manufacturing welcome: Product, Package...
2. Sample order
3. We will reply you for your inquiry in 24 hours.
4. after sending, we will track the products for you once every two days, until you get the products. When you got the
goods, test them, and give me a feedback.If you have any questions about the problem, contact with us, we will offer
the solve way for you.
