Shenzhen Shichuangxinke Electronics Co.,Ltd
professional makes good quality, provide perfect product and service for every customer.
 |
| Place of Origin: | China |
| Brand Name: | SCX |
| Certification: | CB,CE,UL |
| Model Number: | outdoor p3.9 |
| Minimum Order Quantity: | 13 sqm |
|---|---|
| Price: | negotiation |
| Packaging Details: | wooden case，flight case |
| Delivery Time: | 7-16 working days |
| Payment Terms: | L/C, D/P, T/T, Western Union, MoneyGram |
| Supply Ability: | 5200 sqm per month |
| Refresh Rate: | 3840Hz - 5760Hz | Input Voltage: | AC110V - AC240V |
|---|---|---|---|
| Brightness: | 8000nits | LED Control System:: | Novastar / Linsn / Colorlight /HUIDU Card |
| Power Supply:: | Meanwell | Material Of LED Screen: | Aluminum |
| High Light: | Stage Outdoor Full Color LED Display,500x500mm Outdoor Full Color LED Display,Full Color Rental LED Display |
||
Technology Specification Datasheet
| S/N | Item | Technical Parameters | |||
| LED Parameters | |||||
| 1 | Item Name | LED Type | Brightness | Wave Length | H/V Visual Angle |
| 2 | Red LED | SMD192 | 120-140mcd | 620-625nm | 160º/120º |
| 3 | Green LED | SMD1921 | 360-435mcd | 520-525nm | 160º/120º |
| 4 | Blue LED | SMD1921 | 80-100mcd | 470-475nm | 160º/120º |
| Module Specification | |||||
| 1 | Pixel Pitch | 3.91mm | |||
| 2 | Pixel Configuration | Nationstar SMD 1921 1R1G1B(3in1) | |||
| 3 | Module Resolution | 64 x 64 pixels | |||
| 4 | Module Pixles | 4096 pixels | |||
| 5 | Module Size | 250mm X 250mm | |||
| 6 | Input Voltage | DC 5V | |||
| 7 | Power Consumption | Max 45W | |||
| Cabinet Specification | |||||
| 1 | Cabinet Size(W X H X D) | 500mm x 1000mm x 85mm or 500mm x 500mm x 85mm | |||
| 2 | Cabinet Resolution(dot) | 128 x 256 pixels or 128 x 128 pixels | |||
| 3 | Module Quanity (pcs) | 8pcs or 4pcs | |||
| 4 | Cabinet Pixels | 32768 pixels | |||
| 5 | Pixel Density | 65410 pixels/m2 | |||
| 6 | Cabinet Materials | Die Casting Aluminum Cabinet for rental purpose | |||
| 7 | Cabinet Weight | 12kg or 6kg per cabinet | |||
| 8 | Packaging | Fly case | |||
| Whole Screen Specification | |||||
| 1 | Screen Brightness | ≥7000cd/m2 | |||
| 2 | Driving Method | Constant current | |||
| 3 | Best Viewing Distance | 3.91m - 40m | |||
| 4 | Max. Power Consumption | 600W/m2 | |||
| 5 | Average Power Consumption | 300W/m2 | |||
| 6 | Gray Level | 8bits input, 4096 levels(212) | |||
| 7 | Display Color | 16M | |||
| 8 | Frame Frequency | ≥60Hz | |||
| 9 | Refresh Frequency | ≥3840Hz | |||
| 10 | Uninterrupted Working Hours | ≥72 hours | |||
| 11 | Screen Life-span | ≥100,000 hours | |||
| 12 | MTBF | ≥10,000 hours | |||
| 13 | Discrete Blind Spot Rate | <1/10000 | |||
| 14 | Continuous Blind Spot Rate | None | |||
| 15 | Blind Spot Rate | <1/10000 | |||
| 16 | Protective Scale | For indoor use, non-waterproof | |||
| 17 | Screen Plainness | <±1mm | |||
| 18 | Power Supply Mode | AC220±10% 50Hz/AC110±10% 60Hz | |||
| 19 | Environment Temperature | Temperature:-20 Celsius~+60 Celsius | |||
| 20 | Humidity | Humidity:10%~90% RH | |||
| 21 | Control Mode | Synchronous display with control PC by DVI | |||
| 22 | Control System | Linsn, Nova-star, Colorlight or as you required | |||
| 23 | Display Content | Video, DVD, VCD, TV, picture, cartoon, graphics, texts.etc. | |||
| 24 | Interface | Standard Ethernet | |||
| 25 | Transmission Distance | Multi mode fiber <500m, single mode fiber <30km,internet cable <100m | |||
| 26 | Power Supply Brand | G-energy, MeanWell, CZCL or as you required | |||
