Shenzhen Shichuangxinke Electronics Co.,Ltd
professional makes good quality, provide perfect product and service for every customer.

|
| Place of Origin: | China |
| Brand Name: | SCXK |
| Certification: | CE/ROHS/FCC/ISO |
| Model Number: | P2.604 |
| Minimum Order Quantity: | 1 Square Meter/Square Meters |
|---|---|
| Price: | USD654-780per square meters |
| Packaging Details: | wooden box flight case, wooden case, carton, it is up to you. |
| Payment Terms: | T/T, Western Union, MoneyGram, |
| Supply Ability: | 5000sqm per month |
| Pixel Pitch: | P2.604 | Usage: | Indoor |
|---|---|---|---|
| Display Function: | Video | Module Size: | 250*250mm |
| Pixel Density: | 147456 Dots/sqm | Module Resolution: | 96*96 |
| Brightness: | ≥5000 Cd/sqm | Scanning Mode: | 1/32 Scanning |
| Life Time: | 10 Years | Warranty: | 3years |
| Highlight: | Led Display Screen 500x1000mm,Rental Led Video Wall Panels |
||
Indoor Led Rental Screen Price Slim Light Weight Led Display for Stage Led Advertisement Display Screen for Indoor
Specifications :
| SMD P2.604 | |
| Lamp size | 2121 |
| Resolution/mm | 2.604 |
| Pixel configuration | RGB 3 in 1 |
| Pixel density/pixels/m² | 147456/square meter |
| Module resolution | 96x96 |
| Module size/mm | 250x250mm |
| View distance | ≥2m |
| Single point brightness adjust | Can be added |
| Single point color adjust | Can be added |
| White balance brightness | >5000cd/square meter |
| Color temperature | 6500K-9500K |
| Horizontal view angle | 120(degrees) |
| Vertical view angle | 60(degrees) |
| Signal Process bit | 10 or 14 bit |
| Grey process | 1024x1024x1024 16834x16834x16834 65536x65536x65536 |
| Control distances | Internet cable:100m, multimembrane:500m, monofilm:5km |
| Driving mode | Constant driving current |
| Scanning mode | 1/32 |
| Frame rate | 60Hz |
| Refresh frequency | >4200Hz |
| Control mode | Computer synchronous |
| Brightness adjusted range | Manual, automatic operation, stepless continuous adjusted 255 steps. No grey loss |
| Out of control point | <1/10000 |
| Working hours | ≥72hours |
| Mean Time Between Failure | >5000hours |
| Life time | 100000hours |
| Life-all-white(brightness halving) | 50000hours |
| Environment temperature range | Operating temperature range: -20-45℃ Storing temperature range: -30-65℃ |
| Maximum power:/square meter | <1000W |
| Average power:/square meter | <280W |
| Self-check technology | LED spot self-check, communications check, power check, temperature monitor(need customization) |
| Remote monitoring | Remote supervision and control, record potential fault, send out warning signs to the operators.(need customization) |
| Software environment | WindowsNT,Windows1999,WindowsXP |
| Luminous point width between centres | Deviation<3% |
| Brightness uniformity | <10% |
| Color uniformity(chromaticity coordinate) | ±0.003 |
| Power supply request | AC85-264V(50Hz-60Hz) |
| Contrast | (1000:1) |
| System protection | Moistureproof,dustproof,high temperature protection,anti-corrosion,anti-burning,anti-static,anti-vibration |
| Humidity(working) | working:10-95% |
| Humidity(storing) | storing:10-95% |
What we do?
We are a leading manufacturer and provider of technical solution of full color indoor an outdoor ledisplay,rental LED display, led modules where in Shenzhen ctiy,Guangdong province,China.
Why choose us?
1. Professional team and good after-sales service.
2. Promise high quality product for good price.
3. Quick delivery after payment.
4. Free technical support.
5. If any problems appear,we'll replay in 3-4 hours.
Advantages:
1. High-strength and precision die-cast aluminum cabinet, seamless installation.
2. Ultra light and ultra thin, it is more convenient transport and save shipping cost.
3. Unique design, easy to assembly and disassembly.
4. Two side quick lock, which makes screen a better flatness and stable.
5. Adopted pure black leds, high contrast ratio, pictures more clear and vivid.
6. High refresh rate, >=3840HZ. No flicker.
Our Results:
