high definition 1/8 scanning fixing installed outdoor full color p6 led billboard

high definition 1/8 scanning fixing installed outdoor full color p6 led billboard

  • high definition 1/8 scanning fixing installed outdoor full color p6 led billboard
  • high definition 1/8 scanning fixing installed outdoor full color p6 led billboard
high definition 1/8 scanning fixing installed outdoor full color p6 led billboard
Product Details:
Place of Origin: China
Brand Name: SCXK
Certification: CE/ROHS/FCC/SGS
Model Number: P6
Payment & Shipping Terms:
Minimum Order Quantity: negotiation
Price: negotiation
Packaging Details: Packed in wooden case and flight case for outer packing
Delivery Time: 10 working days after received your payment
Payment Terms: T/T or western Union
Supply Ability: 5,000/ Sq m per month
Contact Now
Detailed Product Description
Product Name: Smd Full Color Led Screen Module Size(W * H): 192mm*192mm
Standard: CE/ROHS/FCC/ISO2001 Tube Chip Color: Full Color
Pixel Pitch: 6 Mm Module Qty: 1pcs
Type: Free Standing Resolution(W*H): 32dots*32dots
High Light:

led digital billboards

,

led screen billboard

high definition 1/8 scanning fixing installed outdoor full color p6 led billboard



Started in 2005,Shenzhen Shichuangxike Electronics Co.,Ltd has been focusing on the international market to realize the global strategic layout. With the perfect global marketing network, our products are sold to the Middle East, South America, North America, Europe and other regions.



Our Service



1)Training after order

After the order is placed, a processional training will be offered, including software use, operate safety, maintain equipment



2) Installation and debugging

BESD could send professionals to conduct on site installation and debugging in strict accordance with the requirements of the schemes and original manual.



3) Warranty

Warranty: 2 years warranty, lifetime maintenance

Equip with free spare parts. The first 2 years after shipment, we will be responsible for free maintenance if any problem caused by quality itself. While you should take the cost of the freight to us. After 2 years, service is still available, but would charge for labor, material and freight cost that generates.



4) Maintenance

Maintenance principles: response in time, solve problems asap and ensure the use.

Maintenance period: In the maintenance period of the led display body, free of all maintenance charges

After maintenance period, only charge the material cost and labor cost.



high definition 1/8 scanning fixing installed outdoor full color p6 led billboard 0


Resolution/mm 6
Pixel configuration 1R1G1B
Pixel density/pixels/m² 27778/m²
Module resolution 32dotsx32dots
Module size/mm 192mmx192mm
View distance 4-300m
Single point brightness adjust Can be added
Single point color adjust Can be added
White balance brightness 5000 cd/㎡
Color temperature 6500K-9500K
Horizontal view angle 120(degrees)
Vertical view angle 60(degrees)
Signal Process bit 10 or 16bit
Grey process 1024x1024x1024 16834x16834x16834 65536x65536x65536
Control distances Internet cable:100m, multimembrane:500m, monofilm:2km
Driving mode Constant driving current
Scanning mode (1/8 scan)
Frame rate 60Hz
Refresh frequency >3000Hz
Control mode Computer synchronous
Brightness adjusted range

Manual, automatic operation, stepless continuous adjusted

255 steps. No grey loss

Out of control point <1/10000
Working hours ≥72hours
Mean Time Between Failure >10000hours
Life time 100000hours
Life-all-white(brightness halving) 100000hours
Environment temperature range Operating temperature range: -20-45℃
Maximum power:/㎡ <700W
Average power:/㎡ <200W
Self-check technology

LED spot self-check, communications check, power check,

temperature monitor(need customization)

Remote monitoring

Remote supervision and control, record potential fault,

send out warning signs to the operators.(need customization)

Software environment WindowsNT,Windows1999,WindowsXP
Luminous point width between centres Deviation<3%
Brightness uniformity <10%
Color uniformity(chromaticity coordinate) ±0.003
Power supply request AC85-264V(50Hz-60Hz)
Contrast (1000:1)
System protection Moistureproof,dustproof,high temperature protection,anti-corrosion,anti-burning,anti-static,anti-vibration
Humidity(working) working:10-95%
Humidity(storing) storing:10-95%
Product Name acrylic cosmetics advertising display led sign board
Service Your inquiry will be reply within 12 hours.
Brand SCX
Material Stainless, aluminum ,steel, epoxide resin,PE
Item

Indoor P2P2.5,P3,P3.91P4,P5,P6,P7.62

Outdoor P4 ,P5 P6,P8,P10,P12,P16,P20

Feature High brightness, good resolution, working stable , easy installation.
Grade IP65
Driving mode 1/8 scanning
Stock Regular items of led display have stocks.
Color temperature 6500-9500K
Packing Method Flight case &Plywood case or Customized Packing
Power supply request AC85-264V(50HZ-60HZ)
Delivery Time Within 7-30 days according to your required size & quantity.
Using Range Shopping mall,bank,bus station, train station, center of downtown, airport, school, factory, bus, taxi, and etc.




Factory Equipment

Wave Soldering Conveyor, PC Console, Wave Soldering Machine,
Automatic Glue- pouring Machine, Solder Paste Printing Machine,
Re flow Soldering Machine, Automatic Solder Paste Printing Machine,
Withstand Voltage Tester, Ground Resistance Tester,
Medium-speed Automatic SMT Machine, Super Mute Terminal Machine,
Automatic Wire Stripping Machine, Automatic Optical Inspection (AOI) Equipment.

high definition 1/8 scanning fixing installed outdoor full color p6 led billboard 1high definition 1/8 scanning fixing installed outdoor full color p6 led billboard 2

high definition 1/8 scanning fixing installed outdoor full color p6 led billboard 3

Competitive Advantage:

1. 2 years’ warranty with free repair service

2. 24/7 Hours online Remote Support

3. Solution and PCB design

4. Free factory training

5. On site installation instruction and regular inspection

6, Small order accepted.



Payment and delivery


1) T/T, 30% deposit, 70% before shippment.
2) 100% Western Union in advance.



♦ Why choose us:



Continues Quality

With more than 10 years experience in led display producing,equipments are updated regularly.What’s

more,unique standardized and module production ensure our products continuous quality.



Competitive Price

With large scale production capacity and professional production technology,our company have built

effective modular production.We always stick to promote the technical innovation and reduce cost to

benefit customers.



Fast Delivery

Once we promise the delivery date,we will try our best to fulfill it.Special procedures such as emergency

inventory will be used to maintain your uninterrupted supply of the products.



Perfect Service

Pre-sales:Your purchasing requirements will be highly valued and we’ll recommend suitable products to

you.

After-sales:We will track the products usage and then constantly perfect our products.







♦ FAQ



What kind of payment terms you can accept ?

We can accept T/T and Western Union.



What about your Led Display quality ?

Checking in the whole manufacturing process&100% inspection before shipment ensure the quality of

our products continuity.



What is your delivery time ?

Within 7-35 days according to your area and quantity.



Is your LED display competitive ?

Yes,we are led display manufacturer for more than 10 years.Mass and professional production ensure

our led display’s competitiveness.



high definition 1/8 scanning fixing installed outdoor full color p6 led billboard 5
