IEICC Large Rental Outdoor Led Sign Panels Billboard P3.91

Name: IEICC Large Rental Outdoor Led Sign Panels Billboard P3.91
Brand: Shenzhen ShiXin Display Technology Co.,Ltd
SKU: outdoor p3.9
Price: 10000 USD
Availability: InStock

Brand Name:	SCX
Model Number:	outdoor p3.9
MOQ:	11 sqm
Price:	negotiation
Payment Terms:	T/T, Western Union
Supply Ability:	3700 sqm per sqm

Detail Information

Product Description

Detail Information

Place of Origin:

shenzhen,China

Certification:

CE,CB,IEICC,FC

Brightness:

6500cd/㎡

Gray Scale:

16bit

IP Rating:

IP65

Input Voltage:

AC220V/50Hz

Lifespan:

100000 Hours

Operating Temperature:

-20℃-50℃

Power Consumption:

800W/㎡

Refresh Rate:

1920Hz

Packaging Details:

wooden case，flight case

Highlight:

IEICC outdoor led sign panels

p3.91 outdoor led sign panels

p3.91 large led outdoor displays

Product Description

Rental Billboard P3.91 LED Screen Panel Cheap Video Wall Indoor Outdoor Advertising Screen Stage Led Display

Case

Indoor P3.91.

Total area: 30sqm 500*500mm

Brightness: ≥1300cd/㎡

Refresh Rate: ≥1920HZ

Location : Senegal, Africa

Indoor P3.91.

Total area: 30sqm 500*500mm

Brightness: ≥1300cd/㎡

Refresh Rate: ≥1920HZ

Location : Senegal, Africa

Indoor P3.91 with protective corner.

Cabinet Quantity: 40pcs 500*500mm

Brightness: ≥1300cd/㎡

Refresh Rate: ≥3840HZ

Location : Philippines, Asia

Outdoor P3.91.

Cabinet Quantity: 45pcs 500*500mm

Brightness: ≥4000cd/㎡

Refresh Rate: ≥1920HZ

Location : Philippines, Asia

Indoor P3.91.

Cabinet Quantity: 40pcs 500*500mm

Brightness: ≥1300cd/㎡

Refresh Rate: ≥3840HZ

Location : Poland, Europe

Outdoor P3.91.

Cabinet Quantity: 80pcs 500*500mm

Brightness: ≥4000cd/㎡

Refresh Rate: ≥3840HZ

Location : USA, North America

Indoor P3.91.

Cabinet Quantity: 32pcs 500*500mm

Brightness: ≥1300cd/㎡

Refresh Rate: ≥3840HZ

Location : Iraq, Asia

Outdoor P3.91.

Cabinet Quantity: 45pcs 500*500mm

Brightness: ≥4000cd/㎡

Refresh Rate: ≥1920HZ

Location : Philippines, Asia

Product Specifications

ITEM	HD OUTDOOR RENTAL INSTALLATION LED SCREENS
Product model	SJ-P2.604	SJ-P2.976	SJ-P3.91	SJ-P4.81	SJ-P5.95	SJ-P6.25
Pixel pitch	2.604mm	2.976mm	3.91mm	4.81mm	5.95mm	6.25mm
Physical density	147456dots/m²	112896dots/m²	65536dots/m²	43264dots/m²	28224dots/m²	25600dots/m²
LED Package	SMD 1415 (3in1)		Nation Star SMD 1921 (3in1)	SMD2727 (3in1)
Module size	250mm*250mm
Modules resolution	96*96	84*84	64*64	52*52	42*42	40*40
Modules weight	0.75±0.01kg
Driving method	1/30S	1/21S	1/16S	1/13S	1/7S	1/10S
Interface definition	HUB-16P
Cabinet size	500mm500mm85mm / 500mm1000mm85mm
Cabinets weight	8.6kg/16kg
Cabinets resolution	192192 192384	168168 168336	128128 128256	104104 104208	8484 84168	8080 80160
Equilibrium brightness	4500-6500cd/m²			5000-7500cd/m²
Power consumption	Max: ≤880W/m², Average: ≤400W/m²			Max: ≤700W/m², Average: ≤350W/m²
Refresh rate	≥3840Hz (ICN2055 Driving IC)
Viewing angle Level	H: ≥160°Optional, V: ≥120°Optional
Viewing distance	2.5-30m	3-40m	4-60m	5-70m	6-80m	6.5-90m
Temperature	Working : -25℃~60℃, Storage: -35℃~80℃
Humidity	10%~95%
Working voltage	Input: AC 100V~240V, 50Hz/60Hz, Output: DC 5V
Maintenance method	Front/Back service
Protection grade	Front: IP65, Back: IP65
Lifetime	100000 Hours
