P6 outdoor waterproof advertising led display with high definition image outdoor led advertising panel

P6 outdoor waterproof advertising led display with high definition image outdoor led advertising panel

P6 outdoor waterproof advertising led display with high definition image outdoor led advertising panel
P6 outdoor waterproof advertising led display with high definition image outdoor led advertising panel
P6 outdoor waterproof advertising led display with high definition image outdoor led advertising panel
Product Details:
Place of Origin: China
Brand Name: SCXK
Certification: CE/ROHS/FCC/SGS
Model Number: P6
Payment & Shipping Terms:
Minimum Order Quantity: negotiation
Price: negotiation
Packaging Details: Packed in wooden case and flight case for outer packing
Delivery Time: 10 working days after received your payment
Payment Terms: T/T or western Union
Supply Ability: 5,000/ Sq m per month
Contact Now
Detailed Product Description
Product Name: Led Display Module Module Size(W * H): 192mm*192mm
Standard: CE/ROHS/FCC/ISO2001 Tube Chip Color: Full Color
Pixel Pitch: 6mm Module Qty: 1pcs
Type: Free Standing Resolution: 27778
Highlight:

advertising led display board

,

advertising led billboard

P6 outdoor waterproof advertising led display with high definition image outdoor led advertising panel



Shenzhen Shichuangxinke Electronics Co.,Ltd is established in 2005. we are a leading manufacturer and provider of technical solution. We own our outstanding research and develop department and after-sales service workers, the separately design ability.Our product mainly included the RGB led display,outdoor full color led display,indoor full color led display, advertising led display,stage led display,led billboard,rental led display,stadium led display,led display module,car led sign display,hanging led display,mobile truck led display





About our led displays



1.Wide application field & short ROI time:

commercial advertising LED display screen, Stadium perimeter LED display screen, Mobile trailer LED display screen for mobile media,shopping mall LED display screen for logo showing, bank&stock exchange LED display screen for rates showing, train & bus station LED display screen

air port LED display screen, telecommunication LED display screen system for information showing and instruction .



2. High Contrast ratio: 4000:1
Which is a very high level to ensure a vivid image of our LED display screen system.



3. First-class LED chip:
Supplied by Nichia of Japan & other high strictly selected LED chip to ensure the long lifetime and high brightness of our LED display screen system



4. Clear vivid image quality:
Even in direct, full-on sunlight to ensure you attract more audience to get short ROI of your LED display screen's investment.



Application

It can be used on the shopping mall,bank, bus station, train station, center of downtown, airport, school, factory, bus, taxi, and so on. we adopt many methods and very good after-sales service to sell our product all over the world.. Whenever and wherever we are , we always take the principle that professional makes good quality, provide the perfect product and service for our customer.

P6 outdoor waterproof advertising led display with high definition image outdoor led advertising panel 0

P6 outdoor waterproof advertising led display with high definition image outdoor led advertising panel 1P6 outdoor waterproof advertising led display with high definition image outdoor led advertising panel 2



technology parameter

1, Item Name p6 outdoor waterproof advertising led display with high definition image
2, pixel tube:

pixel pitch:6mm; primary colors: pure red+ pure green +pure blue;

color composing:3 in 1 or 1R1G1B

Density 62500dots/sq m; SMD3528

3 , unit box

module size:192mm×196mm; Module resolution:32*32

cabinet thickness:(cold-roll steel sheet)150mm+(maintain)600mm;

4, whole screen:

the optimum viewing angel :horizontal 110°, vertical 50°

viewing distance:10-300m;working temperature:-20°C~+45°C(-30°C ~+50°C optional) relative humidity:≤95%RH; Drive IC MBI5024



5, operating voltage

AC220V±10% or 110V±10% ,average consumption:500 W/sq m

max consumption:≤650 W/ sq m.

6, main parameter

1) driving mode: 1/8 scan

2) refreshing rate:≥400Hz/s

3) frame frequency:≥60Hz/s

4) gray scale/color:≥16.7Mcolors(Synchronized)

5) manage gray:≥72bit

6) brightness:≥7000cd/sq m

7) color temperature condition:3500K~9500K,be adjustable

8) adjusting style of brightness: hand movement/auto

9) video signal: RF,S-Video,RGB,RGBHV,YUV,YC,COMPOSITION etc. managing ability of signal:≥12bit.against Y revised curve: owns 3pcs above Y curve that can adjustable.

10) average trouble-free time:≥5000hours

11) evenness: between random adjacent pixel ≤0.5mm,module splicing space<1mm

12) switch power loading:5V/40A

13) display mode of computer:1024×768





Methods for Quality Assurance

a. Aging

100% fully test Condition: 72 hours with 256 gray level





b. Vibration Testing

Condition: 3-5 min up and down in 5mm range

P6 outdoor waterproof advertising led display with high definition image outdoor led advertising panel 3


The epistar Led chip. with SMD and DIP Technology .



we adopt the epistar led chip from Taiwan and SMD led display module will be available





P6 outdoor waterproof advertising led display with high definition image outdoor led advertising panel 4

P6 outdoor waterproof advertising led display with high definition image outdoor led advertising panel 5



The steer consturction is very stable for led display,and you can purchase from your local market .





P6 outdoor waterproof advertising led display with high definition image outdoor led advertising panel 6

We can receive all kinds of transportation. and the shippment term. FOB and CIF. EXW and so on.
We can choose the best shippment which is convenient to you!
SCXK group can give you the short delivery time and With the large production ability.

Wooden case or flight case package are available.

Shipping by sea,air or DHL,multiple shipping ways for your choice.


A. Flight case Packing
1)150KG Per flight case
2)3 cabinets in one case
3)Flight case size: 1010mm*560mm*1175mm=39inch*22inch*46inch


B. Plywood case
1)180KG per plywood case
2)3 cabinets in one case
3)Plywood case size: 1120mm*585mm*930mm= 44inch*23inch*36inch

C.customized packing is acceptable
D. 20"FT container loading of 100sq.m







Factory Equipment

Wave Soldering Conveyor, PC Console, Wave Soldering Machine,
Automatic Glue- pouring Machine, Solder Paste Printing Machine,
Re flow Soldering Machine, Automatic Solder Paste Printing Machine,
Withstand Voltage Tester, Ground Resistance Tester,
Medium-speed Automatic SMT Machine, Super Mute Terminal Machine,
Automatic Wire Stripping Machine, Automatic Optical Inspection (AOI) Equipment.

P6 outdoor waterproof advertising led display with high definition image outdoor led advertising panel 7P6 outdoor waterproof advertising led display with high definition image outdoor led advertising panel 8



Competitive Advantage:

1. 2 years’ warranty with free repair service

2. 24/7 Hours online Remote Support

3. Solution and PCB design

4. Free factory training

5. On site installation instruction and regular inspection

6, Small order accepted.



P6 outdoor waterproof advertising led display with high definition image outdoor led advertising panel 9
