Indoor p1.5 Full Color LED Display Panel with 640x640mm Cabinet 3840 refresh rate

Name: Indoor p1.5 Full Color LED Display Panel with 640x640mm Cabinet 3840 refresh rate
Brand: Shenzhen ShiXin Display Technology Co.,Ltd
SKU: indoor p1.5
Price: 10000 USD
Availability: InStock

Brand Name:	SCX
Model Number:	indoor p1.5
MOQ:	6sqm
Price:	negotiation
Payment Terms:	T/T, Western Union
Supply Ability:	3200 sqm per sqm

Detail Information

Product Description

Detail Information

Place of Origin:

shenzhen,China

Certification:

CE,CB,IEICC,FC

Display Type:

Indoor Full Color LED Display

Gray Scale:

16bit

Refresh Rate:

3840Hz

Pixel Configuration:

1r1g1b

Operating Temp:

- 10° —+55° Celcius Degree

Resolution:

1920x1080

Protection Level:

IP32

Viewing Angle:

160° Horizontal / 140° Vertical

Cabinet Size:

640x640mm

Packaging Details:

wooden case，flight case

Highlight:

wide viewing angle indoor led advertising

1.5mm indoor led advertising

advertising led display p1 5

Product Description

full color led display panel indoor fixed 4k video wall p1.5 led screen

Mini-Pro LED Display

Application Scope: Led small spacing display screen is widely used in radio and television, road traffic command center, public security monitoring, power system,water conservancy, urban management and so on Main Features: Low brightness, high gray, light and thin, fashionable, ultra wide viewing angle and fast maintenance.

00:08

00:28

Products Description

MODEL	KW63L09	KW63L11	KW63L12	KW63L15	KW63L18
Pixel Pitch(mm)	0.9375mm	1.17mm	1.25mm	1.5625mm	1.875mm
Pixel Density(pixels/sqm)	1,137,778	728,128	640,000	409,600	284,444
Cabinet Resolution	640*360	512*288	480*270	384*216	320*180
Lamp Type	MINI Four in one	SMD0808	SMD1010	SMD1010/1212	SMD1515
Brightness	＞500 nit	＞600 nit			＞1000 nit
Cabinet Size(mm)	600337.538mm
Pixels Calibration	Standard color and brightness calibration
Gray Scale	14~16Bit
Color Temp	2000K~10000K
Control System	Synchronous Control
Frame Frequency	50/60Hz, 120Hz
Refresh Rate	3840Hz
Working Voltage	AC:100V~240V, 50~60Hz
Power Consumption	Max: 700w/㎡ Ave: 200~250w/㎡
Lifetime(hours)	100,000
Operating Temp(℃)	-10℃~+60℃
Storage Temp(℃)	-25℃~+60℃
Humidity Range	10%~80%, Non-condensing
Weight	6.0kg/Cabinet

Easy Front Sevice Design

Cabinet and modules are separatedly packed, first install cabinets and then install modules.
Cabinets and modules are wireless connected;
Smart adjust: unique alignment features ensure the video wall is perfectly aligned and seamless, the flatness tolerance of screen is ≤0.1mm.

Intelligent Low Power Consumption Design

It can be optional with common-cathode or common-anode, Intelligent data storage function can be customized.

Low Brightness

With High Gray Scale

It use high quality LED Lamps and PWM drive IC, goes with Kewei patented mask and special image arithmetic processing that makes a better color rendering, color revivification and better details with excellent gray scale in low brightness mode(100cd/㎡).

TOPCOB

Unique Design Patent

It own unique LED surface treatment technology, can achieve high level of anti-collision, anti-water, anti-dust, protecting screen effectively, work properly in corrosive, damp and mist evironments.

HDR High Dynamic &

High Refresh Rate Display

System date polishing process and HDR high dynamic fine imaging can function at low brightness and high gray scale simultaneously, which enhances the level of gray scale, makes scene more real and makes color more corgeous. With anti-gamma corrction technology. Dynamic expression of color redition and 3840Hz high refresh rate is pratical and enjoyable.
