P4 Outdoor Waterproof Full Color LED Screen 4mm Pixel 10000h Lifespan

P4 Outdoor Waterproof Full Color LED Screen 4mm Pixel 10000h Lifespan

Brand Name:	SCX
Model Number:	P4
MOQ:	2 sqm
Price:	negotiation
Payment Terms:	T/T, Western Union, Western Union
Supply Ability:	4000 sqm per month

Detail Information

Product Description

Detail Information

Place of Origin:

ShenZhen in China

Certification:

CE/ROHS/FCC/ISO/UL/CB

Pixels:

4mm

Tube Chip Color:

Full Color

Cabinet:

Iron Or Aluminum For Options

Average NO Failure:

>=1000hours

Refresh Rate:

>=180HZ

Optimal Viewing Distance:

>=4m

LED Span Lifetime:

10000 H

Gray Level:

4096~16384

Packaging Details:

flight case, wooden case, carton, it is up to you.

Highlight:

Smd Advertising LED screen

Outdoor Flexible Advertising LED screen

Full Color Advertising LED screen

Product Description

SCX P4 Full Color Advertising LED Screen SMD Outdoor Flexible

Product Attributes

Attribute	Value
Pixels	4mm
Tube Chip Color	Full color
Cabinet	Iron or Aluminum For Options
Average NO Failure	>=1000hours
Refresh Rate	>=180HZ
Optimal viewing distance	>=4m
LED span lifetime	10000 h
Gray level	4096~16384

High Waterproof Level P4 Outdoor Advertising LED Billboards (3 Years Warranty)

P4 Outdoor LED Module: View Details

Type: SMD1919

Driver scan: 1/8 scan

Lamp Brand: Epistar

Arrangement: 1R1G1B

Module Size: 256x128mm

Module Resolution: 64×32=2048 (Dots)

Material: Iron

Dimension: 1024*1024*140mm

Weight: 40 KGS

Module Quantity /Cabinet: 4*8=32 pcs

Standard Power supply: G-energy N200V5 (220V) / A-200AF-5 (110V). Customizable as per requirement.

Use of environment: Outdoor IP65

Cabinet color: Black, Grey

Technical Parameters

Module Parameters

Item	Module Parameters
Pixel type	Real full color
Pixel color	RGB
Module size	256*128mm
Pixel led	SMD3528
Pixels pitch	4mm
Resolution rate	64*32
Driving way	1/8
Driving IC	MBI5024
Working voltage	DC5V
Power	80W
Working temperature	-30°C - +50°C

Screen Parameters

Item	Screen Parameters
Material	Aluminum/iron/aluminum die-casting
Color	Black
Size	1024768mm/512512mm
Resolution rate	96*96
Module quantity	3*3
Density	62500dots/m2
White balance luminance	7000-11000cd/m2
Color temperature	6500
Horizontal view angel	110
Vertical view angel	50
Protection grade	Before/after: IP67/IP65
Non-Flatness	<1mm
Module interval	<1mm
Weight	32kg or 6kg
Maximal power/m2	750W
Frame frequency	≥60Hz/s
Refresh frequency	800-3840Hz
Gray grade	102410241024Grade/1073741824
Luminance adjusted	256 grade by auto-optic/color &8 grade by hand
Input signal	RF,S-video,RGB,RGBHV,YUV,YC&Composition,etc
MTBF	>5000h
Life-span	>100000h
Speckles rate	<0.0001

Control System

Production Process

Incoming Inspection
DIP
Plug-in
Wave Soldering
After Welding
Testing
Semi Finished Aging
Module Assembly
Gluing
Finished Aging
Detection Finishing Warehousing

Packaging and Shipping

Wooden case or flight case package are available. Shipping by sea, air or DHL, multiple shipping ways for your choice.

Why Choose Us

Continues Quality: With more than 10 years experience in LED display producing, equipments are updated regularly. What's more, unique standardized and module production ensure our products continuous quality.

Competitive Price: With large scale production capacity and professional production technology, our company have built effective modular production. We always stick to promote the technical innovation and reduce cost to benefit customers.

Fast Delivery: Once we promise the delivery date, we will try our best to fulfill it. Special procedures such as emergency inventory will be used to maintain your uninterrupted supply of the products.

Perfect Service:

Pre-sales: Your purchasing requirements will be highly valued and we'll recommend suitable products to you.

After-sales: We will track the products usage and then constantly perfect our products.
