High Brightness and Wide Viewing Angle Outdoor Full Color LED Display for Branding COB

Brand Name:	SCXK
Model Number:	P10
MOQ:	1sqm
Price:	negotiation
Payment Terms:	L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability:	3000sqm per month

Detail Information

Product Description

Detail Information

Place of Origin:

SHENZHEN

Certification:

CE/ROHS/FCC/ISO/UL/CB/IECEE/SABER

Tube Chip Color:

FULL COLOR

High Brightness:

7000

Pixel Conformation:

1R1G1B

Operating Voltage:

220±10% Or 110±10%

Moduel Size:

160×160mm

Interface:

HUB75B

Drive Type:

1/16 Scan

Power Consumption:

Max: 800W/m², Avg: 400W/m²

Cabinet Weight:

35kg/panel

Ip Grade:

IP65

Warranty Time:

At 2 Years

Brightness Control:

256grade

Smd Or Dip:

SMD

Pixel:

10mm

Dot Density:

43222dots/sqm

Packaging Details:

flight case, wooden case, carton, it is up to you.

Product Description

Features of LED Display:

1. High brightness: it can still display clearly even under direct sunlight, suitable for outdoor environment.

2. High resolution: pixel pitch is 10mm, providing high image and video resolution and clear content display.

3. Wide Viewing Angle: Wide viewing angle increases audience coverage.

4. Energy saving and environmental protection: low energy consumption and long life, saving energy and maintenance costs.

5. High refresh rate: smooth video playback and dynamic display, avoiding image dragging and flickering phenomenon.

6. Multi-functional application: Support multiple signal inputs.

7. High stability: waterproof, dustproof and shockproof performance.

8. Convenient maintenance: easy and quick installation and maintenance, reducing the difficulty and cost of maintenance.

High Brightness and Wide Viewing Angle Outdoor Full Color LED Display for Branding COB 0

Specification:

Part No.	P10
Driving Mode	Static Full Color
Brightness	10000cd
Contrast	≥3000:1
Display Color	1.07 billion
View Angle	120° degree Horizontal & 60° degree Vertical110
Brightness Adjustment	0-100% 8 levels
Operation Power	220V 60HZ
Max Power Consumption	750 w
Average Power Consumption	280 w
Frame Update Frequency	100hz
Screen Refresh Frequency	480hz
Gamma Correction	(-0.5—5.0)
Operating Temp.	- 10° —+55° Celcius degree
Operating Humidity	10 - 90 % RH
Operating Life	100,000 Hours
MTBF	5000 Hours
Protection Level	IP65
Out of Control Pixel Rate	0.01%
Input Signal Support	Composite, S-Video,Component,VGA, DVI,HDMI,SDI,HD_SDI
Control Distance	UTP CAT5E:100m; Multi-mode Fiber:500m;Single-mode Fiber:10km
Support VGA Mode	800 x 600, 1024 x 768, 1280 x 1024, 1600 x 1200,
Brightness Correction	Dot by Dot,module by module, cabinet by cabinet
Control Mode	Synchronous display with control PC by DV

After-sales Services:

- Extended Warranty: option to purchase extended warranty service to add additional warranty period.

- 24/7 online support: provide 24/7 technical support by phone, email or online chat.

- Operation Training: Provide training on how to operate and maintain the LED display.

- Technical Training: Provide in-depth technical training for technicians to help solve complex problems.

- Regular Inspection: Provide regular inspection services to ensure that the display is in good working condition.

- Cleaning service: regular cleaning and dust-proofing treatment to extend the service life of the display.

- Spare parts stock: Ensure sufficient spare parts stock for quick replacement of damaged components.

- Quick Response: In case of component failure, we can provide the required spare parts quickly.

- Remote Diagnostics: Troubleshooting and problem solving via remote connection.

- Customer return visit: Regular customer return visit to collect feedback and improve service.

- Satisfaction Survey: Understand customer experience through satisfaction survey and improve service quality.

- Hardware Upgrade: Provide upgrading services for display hardware to improve display effect and performance.

- System Integration: Help customers integrate new systems and equipment to optimise the use of the display.
