Outdoor Waterproof P10 SMD Full Color LED Display 10000px/M² IP65 For Stadiums

Outdoor Waterproof P10 SMD Full Color LED Display 10000px/M² IP65 For Stadiums

Brand Name:	SCXK
Model Number:	P6
MOQ:	1 sqm
Price:	negotiation
Payment Terms:	Western Union, T/T, L/C, MoneyGram
Supply Ability:	3000 sqm per month

Detail Information

Product Description

Detail Information

Place of Origin:

Shenzhen China

Certification:

CE/ROHS/FCC/ISO

LED Chip:

Episatr

Tube Chip Color:

Full Color

Waterproof:

IP65

Frame Frequency:

>=60HZ

Average NO Failure:

>=1000hours

LED Shape & Size:

3mm SMD3535

Viewing Angle:

160/140

Control System:

LSN

Packaging Details:

flight case, wooden case, carton, it is up to you.

Highlight:

Commercial Advertising LED display

P10 stadium LED display

Commercial Advertising Stadium LED Display

Product Description

Outdoor HD Full Color SMD P10 Stadium LED Display Commercial Advertising Billboards

Product Specifications

LED Chip	Epistar
Tube Chip Color	Full color
Waterproof	IP65
Frame Frequency	≥60Hz
Average No Failure	≥1000 hours
LED Shape & Size	3mm SMD3535
Viewing Angle	160°/140°
Control System	LSN

Basketball Football Club Cricket Stadium Perimeter LED Commercial Advertising Billboards

Stadium LED Display Features:

High waterproof level (IP65)
Wide viewing angle (160°/140°)
Easy installation design
High level protection anti-collision

Function and Technology Characteristics:

Supports multiple file formats including VGA, Video, AVI, MOV, MPG, DAT, VOB
Compatible with various information sources: camera, video, VCD, DVD, LD, TV
Adjustable brightness, contrast, and saturation (manual/automatic)
Crystal clear picture without flicker or distortion
Synchronous display with your PC
Advanced correcting technology for distortion
Multiple interface options (1 sound, 2 video minimum)
PC control via LAN and remote control
Multilingual support: English, French, German, Greek, Russian, etc.

Wide Viewing Angle for Broader Reach

The display features a wide viewing angle of 140° which reaches more viewers. The picture quality remains seamless in all directions and at a distance, presenting all viewers with the same high-quality output. This makes it suitable for large gatherings.

Technical Specifications

Parameter	Specification
Model	Outdoor SMD P10
Resolution/mm	10
Pixel configuration	1R1G1B
Pixel density	10,000/m²
Module resolution	32×16
Module size	320×160mm
View distance	≥10m
Single point brightness adjust	Available
Single point color adjust	Available
White balance brightness	>5000cd/㎡
Color temperature	6500K-9500K
Horizontal view angle	120°
Vertical view angle	60°
Signal Process bit	10 or 16bit
Grey process	1024×1024×1024 to 65536×65536×65536
Control distances	Internet cable:100m, multimembrane:500m, monofilm:2km
Driving mode	Constant driving current
Scanning mode	1/4
Frame rate	60Hz
Refresh frequency	>4200Hz
Control mode	Computer synchronous
Brightness adjustment	Manual/automatic, 255 steps with no grey loss
Out of control point	<1/10000
Working hours	≥72 hours continuous
MTBF	>5000 hours
Lifetime	100,000 hours
Life-all-white (brightness halving)	50,000 hours
Operating temperature	-20℃ to 45℃
Maximum power	<600W/㎡
Average power	<200W/㎡
Self-check technology	LED spot, communications, power check, temperature monitor (customizable)
Remote monitoring	Supervision, fault recording, warning system (customizable)
Software environment	Windows /1999/XP
Luminous point width deviation	<3%
Brightness uniformity	<10%
Color uniformity	±0.003 chromaticity coordinate
Power supply	AC85-264V (50Hz-60Hz)
Contrast	1000:1
System protection	Moistureproof, dustproof, high temp protection, anti-corrosion, anti-burning, anti-static, anti-vibration
Operating humidity	10-95%
Storage humidity	10-95%
