P8 Full Color LED Billboard 8mm Pixel Pitch IP65 Waterproof 7000cd/M² Brightness

Product Details:

Place of Origin:	Shenzhen in China
Brand Name:	SCXK
Certification:	CE/ROHS/FCC/ISO/UL/CB
Model Number:	P8

Payment & Shipping Terms:

Minimum Order Quantity:	3 sqm
Price:	negotiation
Packaging Details:	flight case/wooden case/carton
Delivery Time:	7-10 working days after receive your payment
Payment Terms:	Western Union, MoneyGram, D/P, T/T, L/C, D/A
Supply Ability:	5000sqm per month

Contact Now

Detailed Product Description

Pixels:	8mm	Led Type:	SMD 3535/2727
Display Function:	Video/Image	Waterproof:	IP65
Cabinet:	Iron Or Aluminum	Frame Frequency:	60-85HZ
Average NO Failure:	>=1000hours	Refresh Rate:	>=960HZ
Maximum Power:	850m2	The Optimum:	280w/m2
Highlight:	Outdoor High Brightness Led screen , HD Advertising P8 LED Screen , Full Color P8 LED Screen

Outdoor High Brightness P8 LED Screen HD Advertising Billboards Full Color

Electronics Digital LED Billboards High Resolution Led Screen P8 Full Color Led Display

Professional-grade outdoor LED display with superior brightness and color performance for advertising and digital signage applications.

Product Specifications

LED Lamp

Type	SMD3535/2727
Brand	Epistar
Arrangement	RGB 3in1
Chip parameters (Red)	620-625nm IV:800-960mcd
Chip parameters (Green)	520-525nm IV:1350-1650mcd
Chip parameters (Blue)	470-475nm IV:330-400mcd

LED Display Module

Pixel Pitch	8mm
Module Size	256×128mm
Module Resolution	32×16=512(Dots)

Pole LED Display

Display Dimension (W×H)	512×512mm
Entire screen size (W×H×D)	960×1600×130mm
Cabinets Material	DIE CASTING Aluminum
Frame Frequency	60 frame/sec
Input Voltage	AC110-220V±10%, 50/60Hz
Brightness	≥7000cd/sqm
Viewing Angle	140°(Horizontal), 140°(Vertical)
Minimum Viewing Distance	5m
Color Processing	R(1024)×G(1024)×B(1024)
Total Power Consumption (Max)	1600W/H
Brightness Adjustment	256 color levels, adjustable manually/automatically
Total Power Consumption (Average)	280W/H
MTBF	10,000 hours
Display Function	Text, Graphics, Video
Life-span	100,000 hours
Refresh Rate	≥1000Hz
Protection Level (front/back)	IP65
Working Temperature	-10℃~55℃
Malfunction Dot Rate	<0.0001
Humidity	10%~90%
Certification	CE, ROHS, FCC, UL, CCC, ISO9001, TUV, CB

Key Features

High Definition: 8mm pixel pitch ensures excellent image clarity at close viewing distances.
Wide Viewing Angle: 140° horizontal and vertical viewing angles for optimal visibility.
Superior Visual Quality: 65,536 grayscale levels (16-bit color) with high refresh rate for smooth video playback.
Durable Construction: Die-cast aluminum cabinet with IP65 protection for reliable outdoor operation.
Energy Efficient: Average power consumption of just 280W/H with automatic brightness adjustment.

Our Services

Quick response to inquiries within 12 hours
OEM/ODM services available for customized LED displays
72-hour aging test before shipment for product reliability
Custom logo printing available
Comprehensive after-sales support

Shipping & Trade Terms

Shipping options: Air, Sea (FCL), or customer-specified freight forwarders
Delivery time: 5-10 days for samples; 10-15 days for batch orders
Shipping port: Shenzhen
Payment methods: TT, Western Union, PayPal, Credit Cards, and more
MOQ: 1 Unit Pole LED Display

Why Choose Us

Proven Quality: 10+ years experience with regularly updated equipment and standardized production
Competitive Pricing: Large-scale production capacity and efficient modular production
Reliable Delivery: Commitment to promised delivery dates with emergency inventory procedures
Comprehensive Support: Pre-sales consultation and after-sales tracking for continuous improvement
