P2 Fine Pitch Indoor Full Color LED Display Screen 2mm Pixel For Events

Brand Name:	SCXK
Model Number:	P2
MOQ:	5 pcs
Price:	negotiation
Payment Terms:	Western Union, MoneyGram, T/T
Supply Ability:	5000sqm per month

Detail Information

Product Description

Detail Information

Place of Origin:

ShenZhen in China

Certification:

CE/ROHS/FCC/ISO/UL/CB

Pixels:

2mm

Display Function:

Video

Waterproof:

Ip43

Cabinet:

Die-catsing Aluminum/iron

MBI:

5124

Viewing Angle:

H:100 V:50

Voltage:

DC5V

LED Parameter:

R:625-630nm

Module Size:

320*160mm

Cabinet Size:

640*640/960*960mm

Packaging Details:

flight case, wooden case, carton, it is up to you.

Highlight:

Indoor Fine Pitch LED Display Screen

P2 Full Color LED Display Screen

Ultra Thin LED Display Screen

Product Description

Indoor Fine Pitch Ultra Thin SMD P2 Full Color LED Display Screen

High-quality LED display screen designed for stage and wedding hall applications, featuring ultra-thin SMD technology and full color capabilities.

Product Specifications

Attribute	Value
Pixels	2mm
Display Function	Video
Waterproof	IP43
Cabinet	Die-casting aluminum/iron
MBI	5124
Viewing Angle	H:100° V:50°
Voltage	DC5V
LED Parameter	R:625-630nm
Module Size	320*160mm
Cabinet Size	640640/960960mm

Detailed Technical Specifications

Lamp size	1515
Resolution/mm	2
Pixel configuration	RGB 3 in 1
Pixel density/pixels/m²	250000/m²
Module resolution	160x80
Module size/mm	320x160
View distance	≥2m
Single point brightness adjust	Can be added
Single point color adjust	Can be added
White balance brightness	>1000cd/㎡
Color temperature	6500K-9500K
Horizontal view angle	120°
Vertical view angle	60°
Signal Process bit	10 or 14 bit
Grey process	1024x1024x1024 16834x16834x16834 65536x65536x65536
Control distances	Internet cable:100m, multimembrane:500m, monofilm:5km
Driving mode	Constant driving current
Scanning mode	1/40
Frame rate	60Hz
Refresh frequency	>3000Hz
Control mode	Computer synchronous
Brightness adjusted range	Manual, automatic operation, stepless continuous adjusted 255 steps. No grey loss
Out of control point	<1/10000
Working hours	≥72hours
Mean Time Between Failure	>5000hours
Life time	100000hours
Life-all-white(brightness halving)	50000hours
Environment temperature range	Operating: -20-45℃ Storing: -25-55℃
Maximum power:/㎡	<1000W
Average power:/㎡	<300W

Key Features

Natural Heat Dissipation (no cooling system needed)
360 degree rotation capability
Stunning Visual Experience with high resolution
High recall rate for attracting customers
Front service design for easy maintenance
Customizable pixel pitch options
Group control for easy management

Product Description

This specialized LED display is designed for both indoor and outdoor column facades, available in cylinder and square shapes. The 360° viewing angle provides a perfect viewing experience from any direction.

The front service design makes maintenance simple and efficient. Ideal for urban development projects, this screen can be customized to meet specific project requirements with various pixel pitch options available.

Packaging & Shipping

Available in wooden case or flight case packaging. Multiple shipping options including sea, air or DHL express service.

Why Choose Our Product

Continuous Quality

With over 10 years of LED display manufacturing experience, we regularly update our equipment and maintain strict quality control through standardized module production.

Competitive Pricing

Our large-scale production capacity and professional technology allow us to offer high-quality products at competitive prices while continuously innovating to reduce costs.

Fast Delivery

We maintain strict delivery schedules and utilize emergency inventory procedures when necessary to ensure uninterrupted supply.

Perfect Service

Pre-sales: We carefully evaluate your requirements and recommend suitable products. After-sales: We track product usage to continuously improve our offerings.
