Shenzhen Shichuangxinke Electronics Co.,Ltd
professional makes good quality, provide perfect product and service for every customer.
 |
| Place of Origin: | China |
| Brand Name: | SCXK |
| Certification: | CE/ROHS/FCC/ISO |
| Model Number: | P8 |
| Minimum Order Quantity: | 5 |
|---|---|
| Price: | USD450-489per square meters |
| Packaging Details: | wooden box flight case, wooden case, carton, it is up to you. |
| Delivery Time: | 7-10 working days after deposit payment received |
| Payment Terms: | T/T, Western Union, MoneyGram, |
| Supply Ability: | 5000sqm per month |
| Pixel Pitch: | P8 | Display Function: | Video |
|---|---|---|---|
| Usage: | Outdoor | Pixel Density: | 15625 Dots/sqm |
| Module Size: | 320*160MM | Module Resolution: | 40*20 |
| Warranty: | 2years | Brightness: | ≥5000 Cd/sqm |
| Scanning Mode: | 1/5 Scanning | Certificates: | CE RoHS FCC CCC |
| Highlight: | Custom LED Panel Rental Display,P8 Custom LED Panel Rental Display,Waterproof SMD Full Color Display |
||
P8 Rental Led Screen LED Stage Backdrop Panel Display Stage Outdoor Waterproof SMD Full Color Led Display
Advertising LED Specification:
| Advertising LED SMD P8 | ||||||
| Resolution/mm | 8 | |||||
| Pixel configuration | 1R1G1B | |||||
| Pixel density/pixels/m2 | 15625/m2 | |||||
| Module resolution |
|
|||||
| Module size/mm |
|
|||||
| View distance | 14-300m | |||||
| Single point brightness adjust | Can be added | |||||
| Single point color adjust | Can be added | |||||
| White balance brightness | >7500cd/m2 | |||||
| Color temperature | 6500K-9500K | |||||
| Horizontal view angle | 120(degrees) | |||||
| Vertical view angle | 60(degrees) | |||||
| Signal Process bit | 10 or 16bit | |||||
| Grey process | 1024x1024x1024 16834x16834x16834 65536x65536x65536 | |||||
| Control distances | Internet cable:100m, multimembrane:500m, monofilm:2km | |||||
| Driving mode | Constant driving current | |||||
| Scanning mode | 1/5 SCANNING | |||||
| Frame rate | 60Hz | |||||
| Refresh frequency | >3000Hz | |||||
| Control mode | Computer synchronous | |||||
| Brightness adjusted range | Manual, automatic operation, stepless continuous adjusted | |||||
| 255 steps. No grey loss | ||||||
| Out of control point | <1/10000 | |||||
| Working hours | ≥72hours | |||||
| Mean Time Between Failure | >5000hours | |||||
| Life time | 100000hours | |||||
| Life-all-white(brightness halving) | 50000hours | |||||
| Environment temperature range | Operating temperature range: -20-45℃ | |||||
| Self-check technology | LED spot self-check, communications check, power check, | |||||
| temperature monitor(need customization) | ||||||
| Remote monitoring | Remote supervision and control, record potential fault, | |||||
| send out warning signs to the operators.(need customization) | ||||||
| Software environment | WindowsNT,Windows1999,WindowsXP | |||||
| Luminous point width between centres | Deviation<3% | |||||
| Brightness uniformity | <10% | |||||
| Color uniformity(chromaticity coordinate) | ±0.003 | |||||
| Power supply request | AC85-264V(50Hz-60Hz) | |||||
| Contrast | (1000:1) | |||||
| System protection | Moistureproof,dustproof,high temperature protection,anti-corrosion,anti-burning,anti-static,anti-vibration | |||||
| Humidity(working) | working:10-95% | |||||
| Humidity(storing) | storing:10-95% | |||||
Why choose us?
5. Excellent flatness: The precision design of the module frame components controls the deviation of adjacent modules within 0.1 mm, providing excellent flatness and no mosaic phenomenon.
6. High Contrast: Consistent deep black and patented masking enable higher contrast and more vivid colors.
7. Easy Installation: Modular design makes installation and maintenance easier.
8. Excellent material: Adopting the same grade of imported LED chips from Taiwan, the United States or Japan, high-quality driver IC, low-noise power supply, which can ensure the screen to work smoothly in the environment of -40~60.
9. Multiple formats: Customers can choose any screen display format, can support TXT, graphics, pictures, animation and video programs.
10. Paint: Paint can protect PCB and related components from environmental erosion, with good resistance to high and low temperatures, as well as insulation, moisture, crepe, dust, corrosion and other excellent characteristics.
11. High anti-vibration performance: the cabinet must be tested for anti-vibration performance before shipment to avoid poor contact due to loose screws.
High anti-vibration performance: the cabinet must be tested for anti-vibration performance before shipment to avoid poor contact due to loose screws after a long time of line transportation.
Advertising LED Function Introduction:
1. We have the advantage of a full range of LED display production
2: Goods supply from indoor and outdoor P10, P8, P6, P4,P3,P3.91, P4.81, P2, P2.5, P1.976 have sufficient inventory, at the same time has high quality, let you buy at ease, use at ease
3. We have round-the-clock online customers to help customers and give customers product performance introduction, as
wellasproduct advantage analysis; According to the actual situation and the use of the situation, for the customer
evaluation,choosethe most reasonable scheme
4: At the same time, we can provide customers with professional training on the operation and maintenance of the led display
system Display troubleshooting
Our service:
1.Your inquiry related to our products or prices will be replied in 24hrs.
2.Well-trained and experienced staffs to answer all your enquires in fluent English .
3.OEM&ODM, any your customized screen we can help you to design and put into product.
4.Distributoer ship are offered for your unique design and some our current models .
5.Protection of your sales area, ideas of design and all your private information.
Shenzhen ShiChuangXin Ke Electronic Co.,Ltd is a high-tech enterprise integrating R&D, design, production, marketing and after-sales service of LED displays.
We can offer all types of indoor and outdoor led display, and it's widely used in banking, communications offices, electric power industry, traffic, stadiums and sporting area, business plaza, entertainment for the applications of advertising, sports,event, stock/ sport news ticker, message center, price etc. The basic LED cabinet are easier for customers' installation and maintenance to meet the market requirement.
Welcome to visit our website and inquire us more info,waiting for you all the time!!!
Contact Person: Lillian seori
Tel: +8619386814677
