Indoor SMD 3535 P4 HD Full Color Electronic Front Service Led Display With Magnetic Modules

Indoor SMD 3535 P4 HD Full Color Electronic Front Service Led Display With Magnetic Modules

Indoor SMD 3535 P4 HD Full Color Electronic Front Service Led Display With Magnetic Modules
Indoor SMD 3535 P4 HD Full Color Electronic Front Service Led Display With Magnetic Modules
Indoor SMD 3535 P4 HD Full Color Electronic Front Service Led Display With Magnetic Modules
Product Details:
Place of Origin: ShenZhen in China
Brand Name: SCXK
Certification: CE/ROHS/FCC/ISO/CB
Model Number: P4
Payment & Shipping Terms:
Minimum Order Quantity: 3 pcs
Price: negotiation
Packaging Details: flight case, wooden case, carton, it is up to you.
Delivery Time: 7-10 working days after receive your payment
Payment Terms: T/T, Western Union
Supply Ability: 5000 pcs per month
Contact Now
Detailed Product Description
Pixels: 4mm Led Type: SMD3535
Display Function: Video/Text/Image Waterproof: IP65
MBI: 5124 Viewing Angle: H:160 V:140
Optimal Viewing Distance: >=4m Voltage: DC5V
Brightness: 1000cd/㎡ LED Parameter: R:625-630nm
Highlight:

Indoor SMD 3535 Led Display

,

Magnetic Modules Led Display

,

Electronic Front Service Led Display

      Indoor SMD 3535 P4 HD 3 In 1 Electronic Front Service Led Display Rgb With Magnetic Modules


♦ Our service
1)Reply your inquiry in 24 working hours.
2)Experienced staffs answer all your query in fluent English,Spanish,French,German etc.
3)Customized design is available,OEM & ODM are welcomed.
4)Exclusive and unique solution can be provided to our customer by our well-trained and professional engineers and staffs.
5)Special discount and protection of sales area provided to our distributor.
6)Warmly welcome your visit in our company if available.
7)Warranty: 24 months, a little investment for longer warranty time.

♦ Product specification

indoor SMD P4
Lamp size 2121
Resolution/mm 4
Pixel configuration RGB 3 in 1
Pixel density/pixels/m² 62500/m²
Module resolution 80x40
Module size/mm 320x160
View distance ≥4m
Single point brightness adjust Can be added
Single point color adjust Can be added
White balance brightness >1500cd/㎡
Color temperature 6500K-9500K
Horizontal view angle 120(degrees)
Vertical view angle 120(degrees)
Signal Process bit 10 or 14 bit
Grey process 1024x1024x1024 16834x16834x16834 65536x65536x65536
Control distances Internet cable:100m, multimembrane:500m, monofilm:5km
Driving mode Constant driving current
Scanning mode 1/16
Frame rate 60Hz
Refresh frequency >1200Hz
Control mode Computer synchronous
Brightness adjusted range

Manual, automatic operation, stepless continuous adjusted
255 steps. No grey loss

Out of control point <1/10000
Working hours ≥72hours
Mean Time Between Failure >5000hours
Life time 100000hours
Life-all-white(brightness halving) 50000hours
Environment temperature range Operating temperature range: -20-45℃ Storing temperature range: -30-65℃
Maximum power:/㎡ <1100W
Average power:/㎡ <280W
Self-check technology

LED spot self-check, communications check, power check,
temperature monitor(need customization)

Remote monitoring

Remote supervision and control, record potential fault,
send out warning signs to the operators.(need customization)

Software environment WindowsNT,Windows1999,WindowsXP
Luminous point width between centres Deviation<3%
Brightness uniformity <10%
Color uniformity(chromaticity coordinate) ±0.003
Power supply request AC85-264V(50Hz-60Hz)
Contrast (1000:1)
System protection Moistureproof,dustproof,high temperature protection,anti-corrosion,anti-burning,anti-static,anti-vibration
Humidity(working) working:10-95%
Humidity(storing) storing:10-95%

Indoor SMD 3535 P4 HD Full Color Electronic Front Service Led Display With Magnetic Modules 0

♦ Production process:
1) Incoming Inspection→2) SMD→3) Plug-in
→4) Wave Soldering→5) After Welding→6) Testing
→7) Semi Finished Aging→8) Module Assembly
→9) Gluing→10) Finished Aging→11) Detection Finishing Warehousing

♦ Packaging and shipping
Wooden case or flight case package are available.
Shipping by sea,air or DHL,multiple shipping ways for your choice.

♦ Why choose us:
Continues Quality
With more than 10 years experience in led display producing,equipments are updated regularly.What’s
more,unique standardized and module production ensure our products continuous quality.

Competitive Price
With large scale production capacity and professional production technology,our company have built
effective modular production.We always stick to promote the technical innovation and reduce cost to
benefit customers.

Fast Delivery
Once we promise the delivery date,we will try our best to fulfill it.Special procedures such as emergency
inventory will be used to maintain your uninterrupted supply of the products.

Perfect Service
Pre-sales:Your purchasing requirements will be highly valued and we’ll recommend suitable products to you.
After-sales:We will track the products usage and then constantly perfect our products.

♦ Frequently Asked Questions
What kind of payment terms you can accept ?
We can accept T/T and Western Union.

What about your Led Display quality ?
Checking in the whole manufacturing process&100% inspection before shipment ensure the quality of
our products continuity.

What is your delivery time ?
Within 7-35 days according to your area and quantity.

Is your LED display competitive ?
Yes,we are led display manufacturer for more than 10 years.Mass and professional production ensure
our led display’s competitiveness.
Indoor SMD 3535 P4 HD Full Color Electronic Front Service Led Display With Magnetic Modules 1
