Ultra-Clear Die-Casting Aluminum RGB LED Display 1/4 Scanning Stadium Full Color Outdoor Screen Waterproof Single And Dual Color Screen





DIP Multi Screen RGB LED Display 1/4 Scanning Statium Full Color Outdoor



Quick Detail:

1, High resolution at 10000pixels/㎡;
2, LED Chips: Epistar high brightness;
3, High brightness up to 7000cd/㎡;
4, Power Supply: Meanwell;
5, Control System: Linsn,Nova etc.

Description:

1. P10 DIP LED display has high resolution, suitable for outdoor LED screen use;
2. Both horizontal and vertical viewing angles are 140 degrees;
3. The use of electronic digital signage P10 is increasing because the trend of LED screens is high resolution.
4. Clear and realistic advertising images and videos;
5. High contrast ratio 1000:1, presenting a real and natural color LED screen;
6. IP65 waterproof, suitable for outdoor use;


Applications:

Airport Full Color Indoor LED displays

Train station Indoor Full Color LED Displays

Entertainment Bar Indoor Full Color LED Screen

Stadium Indoor Full Color LED Display

Museum Full Color Indoor LED display

Car exhibition LED display

Conference room Indoor Full Color LED Video Display

Shopping Mall Indoor Full Color LED display





Specifications :



outdoor DIP P10
Resolution/mm	10
Pixel configuration	1R1G1B
Pixel density/pixels/m²	10000/m²
Module resolution	32x16
Module size/mm	160X160MM
View distance	14-300m
Single point brightness adjust	Can be added
Single point color adjust	Can be added
White balance brightness	>7500cd/㎡
Color temperature	6500K-9500K
Horizontal view angle	120(degrees)
Vertical view angle	60(degrees)
Signal Process bit	10 or 16bit
Grey process	1024x1024x1024 16834x16834x16834 65536x65536x65536
Control distances	Internet cable:100m, multimembrane:500m, monofilm:2km
Driving mode	Constant driving current
Scanning mode	1/4 SCANNING
Frame rate	60Hz
Refresh frequency	>3000Hz
Control mode	Computer synchronous
Brightness adjusted range	Manual, automatic operation, stepless continuous adjusted
	255 steps. No grey loss
Out of control point	<1/10000
Working hours	≥72hours
Mean Time Between Failure	>5000hours
Life time	100000hours
Life-all-white(brightness halving)	50000hours
Environment temperature range	Operating temperature range: -20-45℃
Self-check technology	LED spot self-check, communications check, power check,
	temperature monitor(need customization)
Remote monitoring	Remote supervision and control, record potential fault,
	send out warning signs to the operators.(need customization)
Software environment	WindowsNT,Windows1999,WindowsXP
Luminous point width between centres	Deviation<3%
Brightness uniformity	<10%
Color uniformity(chromaticity coordinate)	±0.003
Power supply request	AC85-264V(50Hz-60Hz)
Contrast	(1000:1)
System protection	Moistureproof,dustproof,high temperature protection,anti-corrosion,anti-burning,anti-static,anti-vibration
Humidity(working)	working:10-95%
Humidity(storing)	storing:10-95%







Competitive advantages:

1. The P10 outdoor full-color LED display has uniform brightness and color;
2. The full-color P10 LED screen uses all-black LED chips;
3. The indoor full-color LED display has a contrast ratio of up to 1000:1, which truly restores the content color;
4. It uses Sum driver IC, with high refresh rate and high grayscale;
5. Both horizontal and vertical viewing angles are 140 degrees;
6. The P10 LED display has a high resolution and is suitable for indoor rental activities that require high-quality demonstrations. The large-size indoor LED screen has a low cost of use;



♦ Production process



1) Incoming Inspection→2)DIP→3)Plug-in

→4) Wave Soldering→5)After Welding→6)Testing

→7) Semi Finished Aging→8)Module Assembly

→9) Gluing→10)Finished Aging→11)Detection Finishing Warehousing







♦ Packaging and shipping



Wooden case or flight case package are available.

Shipping by sea,air or DHL,multiple shipping ways for your choice.



♦ Why choose us



Continues Quality

With more than 10 years experience in led display producing,equipments are updated regularly.What’s

more,unique standardized and module production ensure our products continuous quality.



Competitive Price

With large scale production capacity and professional production technology,our company have built

effective modular production.We always stick to promote the technical innovation and reduce cost to

benefit customers.



Fast Delivery

Once we promise the delivery date,we will try our best to fulfill it.Special procedures such as emergency

inventory will be used to maintain your uninterrupted supply of the products.



Perfect Service

Pre-sales:Your purchasing requirements will be highly valued and we’ll recommend suitable products to

you.

After-sales:We will track the products usage and then constantly perfect our products.





♦ Frequently Asked Questions



What kind of payment terms you can accept ?

We can accept T/T and Western Union.



What about your Led Display quality ?

Checking in the whole manufacturing process&100% inspection before shipment ensure the quality of

our products continuity.



What is your delivery time ?

Within 7-35 days according to your area and quantity.



Is your LED display competitive ?

Yes,we are led display manufacturer for more than 10 years.Mass and professional production ensure

our led display’s competitiveness.



Welcome to visit our website and inquire us more info,waiting for you all the time!!!
