Place of Origin: | China(Mainland) |
Brand Name: | SCXK |
Certification: | CE,RoHS,FCC,CCC,SAA,TUV,UL |
Model Number: | SCXK-P6 |
Minimum Order Quantity: | Negotiations |
---|---|
Price: | Negotiations |
Packaging Details: | Wooden and flight cases,it's up to you. |
Delivery Time: | 7-10 working days after payment |
Payment Terms: | Western Union, T/T, D/A, D/P |
Supply Ability: | 5000sqs/month |
Brand Name: | SCXK-Full Color LED Display | Cabinet Material: | Aluminum |
---|---|---|---|
Brightness: | ≥7500cd/sq | Application: | Dance Floor,stadium,airport,Shopping Mall Advertising |
Module Size: | 192*192mm | Pixel Density: | 27778dots/sq |
Resolution: | 32*32 | Warranty: | 3 Years |
Highlight: | P6 LED Video Display,Outdoor Waterproof LED Video Display,Multi-Screen LED Video Display |
Outdoor Multi Screen P6 Rental LED Display 32*32 Resolution Aluminum SMD
Competitive advantages:
1. P6 SMD outdoor full color LED display screen has uniform brightness and color;
2. P6 LED full color screen use full black LED chips;
3. indoor full color LED video screen with contrast ratio up to 1000:1, which can truly present the color of the content;
4. 4. adopts Sum driver IC, which can realize high refresh rate and high grayscale level. 5;
5. Horizontal and vertical viewing angles of 140 degrees. 6;
6. the high resolution of the P6 LED display makes it suitable for indoor rental events where high quality presentations are required. Large size indoor LED screen at low cost;
Short details:
Resolution/mm | 6 |
Pixel configuration | 1R1G1B |
Pixel density/pixels/m² | 27778/square meter |
Module resolution | 32x32 |
Module size/mm | 192x192 |
View distance | 9-500m |
Single point brightness adjust | Can be added |
Single point color adjust | Can be added |
White balance brightness | >7500cd/square meter |
Color temperature | 6500K-9500K |
Horizontal view angle | 120(degrees) |
Vertical view angle | 60(degrees) |
Signal Process bit | 10 or 16bit |
Grey process | 1024x1024x1024 16834x16834x16834 65536x65536x65536 |
Control distances | Internet cable:100m, multimembrane:500m, monofilm:2km |
Driving mode | Constant driving current |
Scanning mode | static full color |
Frame rate | 60Hz |
Refresh frequency | >3000Hz |
Control mode | Computer synchronous |
Brightness adjusted range | Manual, automatic operation, stepless continuous adjusted |
255 steps. No grey loss | |
Out of control point | <1/10000 |
Working hours | ≥72hours |
Mean Time Between Failure | >5000hours |
Life time | 100000hours |
Life-all-white(brightness halving) | 50000hours |
Environment temperature range | Operating temperature range: -20-45℃ |
Maximum power:/square meter | <950W |
Average power:/square meter | <350W |
Self-check technology | LED spot self-check, communications check, power check, |
temperature monitor(need customization) | |
Remote monitoring | Remote supervision and control, record potential fault, |
send out warning signs to the operators.(need customization) | |
Software environment | WindowsNT,Windows1999,WindowsXP |
Luminous point width between centres | Deviation<3% |
Brightness uniformity | <10% |
Color uniformity(chromaticity coordinate) | ±0.003 |
Power supply request | AC85-264V(50Hz-60Hz) |
Contrast | (1000:1) |
System protection | Moistureproof,dustproof,high temperature protection,anti-corrosion,anti-burning,anti-static,anti-vibration |
Humidity(working) | working:10-95% |
Humidity(storing) | storing:10-95% |
Spare parts warranty period Configuration Guidelines:
(1) Adequacy: Matching with specific equipment, the spare parts configuration is sufficient to ensure that the equipment is replaced at the first time of failure;
(2) Necessity: on the basis of previous maintenance experience, we configure the spare parts are the key parts of the equipment, so as to ensure the economy of the configuration;
(3) Economical and practical: In order to deal with faults in the shortest possible time, the spare parts we configure are complete modules or units, and through our training, the owners can easily replace the spare parts, thus ensuring the normal operation of the system.
Our services:
1.Quick delivery after receiving your payment.
2.Provide free tachnical support.
3.Reply fof your inquiry within 4 hours.
4.Warranty for 3-5 years.
During the guarantee time,any problems of machine we provide free help.
And the products we send you promise the whole new and not the second hand.
If any questions,just contact us,we'll be here all the time!!!
Welcome to inquire us for more details!!!
Contact Person: Lillian seori
Tel: +8619386814677
