Shenzhen Shichuangxinke Electronics Co.,Ltd
professional makes good quality, provide perfect product and service for every customer.
 |
| Place of Origin: | China(Mainland) |
| Brand Name: | SCXK |
| Certification: | CE ,RoHS, FCC.CCC,SAA ,TUV ,UL |
| Model Number: | SCXK-P10 |
| Minimum Order Quantity: | Negotiations |
|---|---|
| Price: | Negotiations |
| Packaging Details: | Wooden and flight cases,it's up to you. |
| Delivery Time: | 10 working days after payment |
| Payment Terms: | T/T, Western Union, L/C, MoneyGram |
| Supply Ability: | 5000sqs/month |
| Resolution/mm: | 10mm | Module Size: | 320*160mm |
|---|---|---|---|
| Resolution: | 16*16 | Pixel Density: | 10000dots/sq |
| Color: | Full Color,RGB LED Display | LED Chip: | Epistar |
| Waterproof: | IP65 | Cabinet Material: | Iron |
| Product Name: | Advertising LED Screens | Scan Mode: | 1/8 |
| Brightness: | ≥7500cd/sq | Warranty: | 3-5years |
| Indoor Options: | P1.667,P1.923,P2,P2.5,P3,P3.91,P4,P5,P6,P10... | ||
| Highlight: | P10 SMD Advertising LED Display Screen |
||
Outdoor HD P10 DIP Full Color Advertising LED Screens Conenvient for Rental 16*16 Resolution
Specifications :
| outdoor SMD P10 Full Color Advertising LED Screens | |||||
| Resolution/mm | 10 | ||||
| Pixel configuration | 1R1G1B | ||||
| Pixel density/pixels/m² | 10000/square meter | ||||
| Module resolution | 16x16mm | ||||
| Module size/mm | 320x160mm | ||||
| View distance | 14-300m | ||||
| Single point brightness adjust | Can be added | ||||
| Single point color adjust | Can be added | ||||
| White balance brightness | >7500cd/square meter | ||||
| Color temperature | 6500K-9500K | ||||
| Horizontal view angle | 120(degrees) | ||||
| Vertical view angle | 60(degrees) | ||||
| Signal Process bit | 10 or 16bit | ||||
| Grey process | 1024x1024x1024 16834x16834x16834 65536x65536x65536 | ||||
| Control distances | Internet cable:100m, multimembrane:500m, monofilm:2km | ||||
| Driving mode | Constant driving current | ||||
| Scanning mode | 1/4 SCANNING | ||||
| Frame rate | 60Hz | ||||
| Refresh frequency | >3000Hz | ||||
| Control mode | Computer synchronous | ||||
| Brightness adjusted range | Manual, automatic operation, stepless continuous adjusted | ||||
| 255 steps. No grey loss | |||||
| Out of control point | <1/10000 | ||||
| Working hours | ≥72hours | ||||
| Mean Time Between Failure | >5000hours | ||||
| Life time | 100000hours | ||||
| Life-all-white(brightness halving) | 50000hours | ||||
| Environment temperature range | Operating temperature range: -20-45℃ | ||||
| Self-check technology | LED spot self-check, communications check, power check, | ||||
| temperature monitor(need customization) | |||||
| Remote monitoring | Remote supervision and control, record potential fault, | ||||
| send out warning signs to the operators.(need customization) | |||||
| Software environment | WindowsNT,Windows1999,WindowsXP | ||||
| Luminous point width between centres | Deviation<3% | ||||
| Brightness uniformity | <10% | ||||
| Color uniformity(chromaticity coordinate) | ±0.003 | ||||
| Power supply request | AC85-264V(50Hz-60Hz) | ||||
| Contrast | (1000:1) | ||||
| System protection | Moistureproof,dustproof,high temperature protection,anti-corrosion,anti-burning,anti-static,anti-vibration | ||||
| Humidity(working) | working:10-95% | ||||
| Humidity(storing) | storing:10-95% | ||||
Our factory specializes in the production of the following products,
1) Monochrome LED display, bi-color LED display, full-color LED display.
2) Indoor LED display, semi-outdoor LED display and outdoor LED display.
3) LED mobile signage, variable information signage, LED text display, programmable LED mobile information signage, LED scrolling information signage.
4) LED display, LED display board, LED display module, LED display control system.
5) LED video display, LED advertising display, rental LED display, concert LED display, stage LED display.
6) Wireless control LED display board, computer control LED display.
Main features:
Epistar and Silan brand LED chips, MBI5024 driver IC, Meanwell power supply, all well-known brand materials
Vivid image and video, rich color detail description
High brightness ≥ 1500 CD/m2, can automatically adjust the brightness according to the environment, IP65 and operating temperature range design, can meet your indoor use requirements
Signal and power auto-timer function, automatic operation
Remote control, error detection, control center management function, can feedback error information through SMS
Support DOT-DOT error correction function
* Products Advantages:
1) Price Advantage: We have the most competitive price in the market.
2) Performance Advantage: Best Equality, High Consistency, Large Viewing Angle, Repairable for every LED fixture.
3) Quality Advantage: From material to finished product, from design to production, we control all the steps, which is the guarantee of quality and reliability.
4) Service Advantage: Better service under the same condition, better cooperation under the same service!
Welcome to visit our website and inquire us more info,waiting for you all the time!!!
