Shenzhen Shichuangxinke Electronics Co.,Ltd
professional makes good quality, provide perfect product and service for every customer.
 |
| Place of Origin: | China(Mainland) |
| Brand Name: | SCXK |
| Certification: | CE,RoHS,FCC,CCC,SAA,TUV,UL |
| Model Number: | SCXK-P4 |
| Minimum Order Quantity: | Negotiations |
|---|---|
| Price: | Negotiations |
| Packaging Details: | Wooden and flight cases,it's up to you. |
| Delivery Time: | 10 working days after payment |
| Payment Terms: | T/T, Western Union |
| Supply Ability: | 5000sqs/month |
| Pitch: | 4mm | Color: | Full Color,RGB 3In1 |
|---|---|---|---|
| LED Chip: | Epistar | System: | LSN |
| Module Size: | 256*128mm | Brightness: | 62500dots/sq |
| Certification: | CE,RoHS,FCC,ISO | Warranty: | 3-5 Years |
| Highlight: | P4 RGB Rental LED Display Board,IP34 HD Flexible LED Display Board,1/16 Scan LED Display Board |
||
P4 Indoor RGB Hanging LED Display for Rental 1/16 Scan IP34 High Resolution
Shenzhen Sitronix Xinke Electronics Co., Ltd. is a high-tech enterprise integrating LED display research and development, design, production, sales and after-sales service.
The company can provide all kinds of indoor and outdoor LED displays, which are widely used in banks, communication bureaus, electric power industry, transportation, stadiums, commercial plazas, entertainment venues, and other places for advertisements, sports, events, stock/sports news tickers, information centers, prices, and so on. The basic LED box is easier for customers to install and maintain and can meet the market demand.
We are also known for customizing LED displays to meet your unique and specific needs. In addition, we are committed to providing quality products at competitive prices and excellent customer service. With ISO9001 quality management system, strong R&D and manufacturing team, SCXK has become one of the leading companies in Shenzhen LED display industry.
Specifications :
| Indoor P4 LED Display | |||||
| Resolution/mm | 4 | ||||
| Pixel configuration | 1R1G1B | ||||
| Pixel density/pixels/m² | 62500/square meter | ||||
| Module resolution | 64x32 | ||||
| Module size/mm | 256x128mm | ||||
| View distance | 14-300m | ||||
| Single point brightness adjust | Can be added | ||||
| Single point color adjust | Can be added | ||||
| White balance brightness | >1200cd/square meter | ||||
| Color temperature | 6500K-9500K | ||||
| Horizontal view angle | 120(degrees) | ||||
| Vertical view angle | 60(degrees) | ||||
| Signal Process bit | 10 or 16bit | ||||
| Grey process | 1024x1024x1024 16834x16834x16834 65536x65536x65536 | ||||
| Control distances | Internet cable:100m, multimembrane:500m, monofilm:2km | ||||
| Driving mode | Constant driving current | ||||
| Scanning mode | 1/16 SCANNING | ||||
| Frame rate | 60Hz | ||||
| Refresh frequency | >3000Hz | ||||
| Control mode | Computer synchronous | ||||
| Brightness adjusted range | Manual, automatic operation, stepless continuous adjusted | ||||
| 255 steps. No grey loss | |||||
| Out of control point | <1/10000 | ||||
| Working hours | ≥72hours | ||||
| Mean Time Between Failure | >5000hours | ||||
| Life time | 100000hours | ||||
| Life-all-white(brightness halving) | 50000hours | ||||
| Environment temperature range | Operating temperature range: -20-45℃ | ||||
| Self-check technology | LED spot self-check, communications check, power check, | ||||
| temperature monitor(need customization) | |||||
| Remote monitoring | Remote supervision and control, record potential fault, | ||||
| send out warning signs to the operators.(need customization) | |||||
| Software environment | WindowsNT,Windows1999,WindowsXP | ||||
| Luminous point width between centres | Deviation<3% | ||||
| Brightness uniformity | <10% | ||||
| Color uniformity(chromaticity coordinate) | ±0.003 | ||||
| Power supply request | AC85-264V(50Hz-60Hz) | ||||
| Contrast | (1000:1) | ||||
| System protection | Moistureproof,dustproof,high temperature protection,anti-corrosion,anti-burning,anti-static,anti-vibration | ||||
| Humidity(working) | working:10-95% | ||||
| Humidity(storing) | storing:10-95% | ||||
Our cervices
1. After-sales service:
1) Service principle: Respond in time, solve problems as soon as possible, and ensure the use.
2) Service period: During the maintenance period of the LED screen body, all the maintenance fees are exempted; after the maintenance period expires, only the material fee is charged and the labor fee is exempted.
3) Service Scope: If users find any unsolvable problems, please contact our company, we can respond within 24 hours. In order to shorten the repair time, our company will deploy some spare parts, such as power supply, chips and so on.
4) Under normal use and storage, our company will be responsible for the equipment.
2. Pre-sale service:
1) Our company can arrange professional personnel to carry out on-site installation and debugging in strict accordance with the requirements of the program and the original instructions. If there is a special requirement to change part of the installation program, our company will coordinate with the user. Our company can ensure that the completion time is consistent with the time agreed in the contract. Any problems caused by natural or human factors, we will negotiate with the customer to solve.
2) We can train users according to the manual. The training includes system use, system maintenance and equipment protection.
Frequent inquiries:
1.Do i need a technical person to assist installation and debuging the system to mesh screen?
--Normally the competitors request to send one or two technical persons installation site for assist,
which will bring much extra costs.However,if you take mesh screen from us,there is no necessary
tyo send technical persons to there coz the frame and cabinet can match perfectly,and in case the
system needs to be debuged,just via remote,and the job can be done well!
2.How can i do if i want to put the mesh screen to the surface of glass surface building ?
--The mesh screen is designed mostly for glass surface building,but it's little difficult to find the
support position for the frame.We can provide OEM for the frame to hold the cabinet.You just need
to send us concerning building draw,and other jobs will be done well by us!!!
3.What's your leading time?
--The leading time normally is 12-15 working,which depends don the total quality and the if there is any special requirement or not.
Welcome to visit our website and inquire more details!!!
