1)Front or rear maintenance option, realizing module, power supply and receiving card front or rear maintenance, saving your maintenance cost.
2)Adopt top high brightness with low power consumption LED lamp, energy-saving≥30%, if adopt 28 kinds of main patent technique, entire energy-saving ≥50%, environment protection.
3)Free back service path for all kinds of installation surroundings. Broadcast level color scale, color temperature and brightness-adjustable, smooth color, high color ratio, nature pictures.
Technical Parameters of P10 Advertising Led Screens
| Outdoor SMD P10 | |
| Resolution/mm | 10 |
| Pixel configuration | 1R1G1B |
| Pixel density/pixels/m² | 10000m2 |
| Module resolution | 32*16 |
| Module size/mm | 320*160 |
| View distance | 10-100m |
| Single point brightness adjust | Can be added |
| Single point color adjust | Can be added |
| White balance brightness | >8000cd/㎡ |
| Color temperature | 6500K-9500K |
| Horizontal view angle | 120(degrees) |
| Vertical view angle | 60(degrees) |
| Signal Process bit | 10 or 16bit |
| Driving mode | Constant driving current |
| Scanning mode | static dring |
| Frame rate | 60Hz |
| Refresh frequency | 3000Hz |
| Control mode | Computer synchronous |
| Brightness adjusted range |
Manual, automatic operation, stepless continuous adjusted 255 steps. No grey loss |
| Out of control point | <1/10000 |
| Working hours | >72hours |
| Mean time Between Failure | >500hours |
| life time | >100000hours |
| Envirornment temperature range | operating temperature range -200c-500c |
| Maximun power :/m2 | <600w |
| Average power:/m2 | <200w |
| Self-check technolog | LED spot self-check, communication check, power check, temperature monitor(need customization) |
| Remote monitoring | Remote supervision and control, record potential fault send out warning signs to the operators(need customization) |
| Software environment | Windows 1999, Windows |
| Input power cable | AC110v to 220v |
| Signal input | DVI |
| Warranty | 2 years quality warranty, 10 years spare parts support |
The Feature of P10 Module
1, the use of ultra-high brightness LED and high-quality plastic pieces
2, high-contrast hue can achieve a good display
3, lightweight, easy to install, remove
4, can be single-point, single lamp maintenance, low cost
5, using a constant current way to drive LED, light uniformity, low power consumption
6, the pixel pitch is 6mm, a total of 32 * 16 pixels, each pixel consists of 1R1G1B.
The Advantages of Our Products
1. The product structure is resistant to 100 Km / h wind and 8 earthquakes.
2. With excellent waterproof performance, safe and reliable power system.
3. All components of the product can be processed according to customer requirements.
4. All materials are environmentally friendly materials.
5. The life of the product is more than 5 years.
6. The warranty is for 2~5 years.
7. We can provide additional installation, permanent technical supports, and training services.
