Shenzhen Shichuangxinke Electronics Co.,Ltd
professional makes good quality, provide perfect product and service for every customer.
 |
| Place of Origin: | ShenZhen in China |
| Brand Name: | SCXK |
| Certification: | CE/ROHS/FCC/ISO/UL |
| Model Number: | P4 |
| Minimum Order Quantity: | 2sqm |
|---|---|
| Price: | negotiation |
| Packaging Details: | flight case, wooden case, carton, it is up to you. |
| Delivery Time: | 7-10 working days after receive your payment |
| Payment Terms: | Western Union, MoneyGram, T/T |
| Supply Ability: | 5000sqm per month |
| Pixels: | 4mm | Tube Chip Color: | Full Color |
|---|---|---|---|
| Led Type: | SMD2121 | Display Function: | Video/Image |
| Cabinet: | Die-casting Aluminum Or Iron | Cabinet Size: | 320mm*160mm |
| Working Voltage: | DC5V | Warranty Time: | 3 Years |
| Dot Density: | 62500 | Driving Mode: | 1/16scaning |
| Piexl Dots: | 80*40 | ||
| Highlight: | Rental Outdoor Stage Led Video Wall,P4 Outdoor Stage Led Video Wall |
||
HD P4 Waterproof Outdoor Stage Led Video Wall Rental Screen for Events Concert Hire
P4 Rental LED Display
Products Advantages:
1) Price Advantage: we have the best competitive price at the market, also have the same even better quality.
2) Quality advantage: From material to finished product, from design to produce, we control all steps.
3) Service advantage: Better service at same situation, better cooperation at same service.
Product Specification
|
P4 Outdoor Full Color LED Display |
|||
|
Item |
Techinical Specifications |
||
|
Pixel Pitch |
4mm |
||
|
LED Configuration |
SMD 3 in 1 |
||
|
Pixel Density |
62500 pixels/sq.m |
||
|
Module Size |
320mm x 160mm |
||
|
Module Resilution |
80pixel x 40pixel |
||
|
Cabinet Size |
960mm x 960mm |
||
|
Cabinet Resolution |
96pixels x 96pixels |
||
|
Cabinet Material |
Iron/Aluminum |
||
|
Cabinet Weight |
48kg/m2 or 40kg/m2 |
||
|
Brightness |
5000cd/m2 |
||
|
Colour temperature |
3500K-9500K(adjustable) |
||
|
Viewing Angle |
H:110°/V:55° |
||
|
Brightness Uniformity |
≥97% |
||
|
Brightness Adjustment |
Manual/Auto/Programmable |
||
|
Ave. Power consumption |
200 W/m2 |
||
|
Max. Power consumption |
600 W/m2 |
||
|
Input Voltage |
AC220V/50HZ or AC110V/60HZ (±10%) |
||
|
Output Voltage |
5V,40A |
||
|
Best Viewing Distance |
10m~200m |
||
|
Contrast ratio |
5000:1 |
||
|
Frame rate |
50/60 Hz/sec |
||
|
Refresh rate |
≥1200Hz |
||
|
Grey scale levels |
R(256bit) x G(256bit) x B(256bit) |
||
|
Display Colors |
R(1024) x G(1024) x B(1024) |
||
|
Protection Level |
IP65 |
||
|
Life-span |
100,000 hours |
||
|
MTBF |
10,000 hours |
||
|
Malfunction dot rate |
< 0.0001 |
||
|
Storage Temp/Humidity |
-30~+60℃/10~90%RH |
||
|
Operating Temp/Humidity |
-20~+50℃/10~90%RH |
||
|
Drive Mode |
1/4 scan |
||
|
Control System |
Synchronous/Asynchronous/Wifi/3G Wireless for choosing |
||
|
Input Signal |
RF,TV,RGB,S-VIDEO,PAL,DVI,HDMI,VGA,SDI,AVI,RGBHV,CVBS,etc |
||
|
PC Operating System |
Microsoft Windows 7, 8, 98, 2000, XP and Vista |
||
Products function introduction:
1) High intensity and can be adjusted, so can meet the request of the customers according the environment.
2) Best equality, commendably solve the problem of the mosaic, have the excellent consistency of light
3) To pictures and character, have clear, exquisite and real display effect LED Curtain Screen
4) Big viewing angle to 160 degree at horizontal line, 140 degree at vertical line
5) Can repair each led lamps, so the cost of maintain is lower, and easy to repair.
6) Usually apply for physical sports, advertisement, bank, stock exchange, station, port, indoor P6 display etc
Packing& Shipping
