Rental Outdoor Full Color Waterproof HD LED Display P8 Front-End Service Fixed Installation

Rental Outdoor Full Color Waterproof HD LED Display P8 Front-End Service Fixed Installation

  • Rental Outdoor Full Color Waterproof HD LED Display P8 Front-End Service Fixed Installation
  • Rental Outdoor Full Color Waterproof HD LED Display P8 Front-End Service Fixed Installation
  • Rental Outdoor Full Color Waterproof HD LED Display P8 Front-End Service Fixed Installation
  • Rental Outdoor Full Color Waterproof HD LED Display P8 Front-End Service Fixed Installation
Rental Outdoor Full Color Waterproof HD LED Display P8 Front-End Service Fixed Installation
Product Details:
Place of Origin: China(Mainland)
Brand Name: SCX
Certification: CE,ISO,FCC,UL
Model Number: SCX-P8
Payment & Shipping Terms:
Minimum Order Quantity: 3 sqm
Price: 300-500USD/sqm
Packaging Details: Carton,wooden and flight cases.
Delivery Time: 7 working days.
Payment Terms: T/T, T/T, Western Union
Supply Ability: 5000sqm/month
Contact Now
Detailed Product Description
Color: Full Color Function: Video
Pixel Pitch: 8mm Cabinet Material: Iron
Installation: Outdoor Pixel Density: 15625dots/sqm
Brightness: 6000nits Drive Mode: 1/4
Highlight:

Outdoor Full Color LED Display

,

P8 HD LED Display

,

Waterproof HD LED Display

Outdoor Full Color LED Display P8 Front Service HD Fixed Installation

Product performance instroduction:

1. Front-end maintenance - only need to remove the module for maintenance;
2. Iron box - heavy weight, can be firmly fixed installation;
3. High protection level, can be effectively waterproof, waterproof coefficient 65;
4. Can be designed as two-sided screen, more convenient for advertising;

Here are the details for picture:

Rental Outdoor Full Color Waterproof HD LED Display P8 Front-End Service Fixed Installation 0

Rental Outdoor Full Color Waterproof HD LED Display P8 Front-End Service Fixed Installation 1

Parameters of it:

Resolution/mm8
Pixel configuration1R1G1B
Pixel density/pixels/m²15625dots/square meter
Module resolution32x16
Module size/mm256x128
View distance8-100m
Single point brightness adjustCan be added
Single point color adjustCan be added
White balance brightness6000cd/square meter
Color temperature6500K-9500K
Horizontal view angle120(degrees)
Vertical view angle60(degrees)
Signal Process bit10 or 16bit
Grey process1024x1024x1024 16834x16834x16834 65536x65536x65536
Control distancesInternet cable:100m, multimembrane:500m, monofilm:2km
Driving modeConstant driving current
Scanning mode1/4
Frame rate60Hz
Refresh frequency1200Hz
Control modeComputer synchronous
Brightness adjusted rangeManual, automatic operation, stepless continuous adjusted
255 steps. No grey loss
Out of control point<1/10000
Working hours≥72hours
Mean Time Between Failure>5000hours
Life time100000hours
Life-all-white(brightness halving)50000hours
Environment temperature rangeOperating temperature range: -20-45℃
Maximum power:/square meter<850W
Average power:/square meter<280W
Self-check technologyLED spot self-check, communications check, power check,
temperature monitor(need customization)
Remote monitoringRemote supervision and control, record potential fault,
send out warning signs to the operators.(need customization)
Software environmentWindowsNT,Windows1999,WindowsXP
Luminous point width between centresDeviation<3%
Brightness uniformity<10%
Color uniformity(chromaticity coordinate)±0.003
Power supply requestAC85-264V(50Hz-60Hz)
Contrast(1000:1)
System protectionMoistureproof,dustproof,high temperature protection,anti-corrosion,anti-burning,anti-static,anti-vibration
Humidity(working)working:10-95%
Humidity(storing)storing:10-95%



FAQ

1.Q:Are you a factory or trading company?
A:We are a factory,located in Dalang,Longhua District .

2.Q:What kind of payment terms you accept?
A:We accept T/T,Western Union,MoneyGram etc.

3.Q:What's packaging?
A:1.Flight case packaging
2.Wooden case packaging
3.36pcs in one case packaging
4.Customized packaging

4.Q:Does you have CE/ROHS certificates?
A:Yes, we offer the CE & ROHS certificates .

5.Q:What's the shipping method,shipping time?
A:Our products could be shipped by Sea, by Air, and by Express.
by sea:20-40days; by air:5-10days ;by express:3-6days
