| Place of Origin: | China(Mainland) |
| Brand Name: | SCX |
| Certification: | CE,ISO,FCC,UL |
| Model Number: | SCX-P3 |
| Minimum Order Quantity: | 3 sqm |
|---|---|
| Price: | 899-1109USD/sqm |
| Packaging Details: | Carton,wooden and flight cases. |
| Delivery Time: | 12-15 working days. |
| Payment Terms: | T/T, Western Union |
| Supply Ability: | 5000sqm/month |
| Function: | Play Video | Pixels: | 3mm |
|---|---|---|---|
| Tube Chip Color: | Full Color | Brightness: | 1500nit |
| Usage: | Indoor | Application: | Competition/Advertising,Indoor Led Floor Screen |
| Cabinet Size: | 576x576x65mm Die Casting Aluminum | Pixel Density: | 111111dots/m2 |
| Highlight: | Die-Cast Aluminum RGB LED Monitor,Indoor Series RGB LED Monitor |
||
P3 RGB LED Display Indoor Series 1/32 Scan Mode 192*192mm HD Video Panel
1.Flexible and bendable
The flexible chassis and soft cover design allows users to bend freely, so it can be assembled in any uneven or irregular position.
2.Ultra-thin and ultra-light
Flexible LED signs are made of special materials and advanced technology, making them one of the thinnest and lightest LED signs in the world. Each module weighs only 800 grams.
3. Easy splicing, installation and maintenance
Modular design and no other connecting cables make the installation very simple, users only need to install the iron sheet or magnetic product on the surface first, and then paste the flexible LED sign on the surface.
4. Low Power Consumption
Maximum power consumption of one module is less than 12W.
5.Wide range of applications
It can be used in many fields and occasions, especially for various irregular buildings. For example, hotel advertising, stage rental, TV, shopping malls, large markets, outdoor stadiums, concerts, amusement parks, sightseeing areas and so on.
| Resolution/mm | 3 |
| Pixel configuration | 1R1G1B |
| Pixel density/pixels/m² | 111111dots/square meter |
| Module size/mm | 576x576 |
| View distance | 3-50m |
| Single point brightness adjust | Can be added |
| Single point color adjust | Can be added |
| White balance brightness | 1500cd/square meter |
| Color temperature | 6500K-9500K |
| Horizontal view angle | 120(degrees) |
| Vertical view angle | 60(degrees) |
| Signal Process bit | 10 or 16bit |
| Grey process | 1024x1024x1024 16834x16834x16834 65536x65536x65536 |
| Control distances | Internet cable:100m, multimembrane:500m, monofilm:2km |
| Driving mode | Constant driving current |
| Scanning mode | 1/32 |
| Frame rate | 60Hz |
| Refresh frequency | 1920Hz |
| Control mode | Computer synchronous |
| Brightness adjusted range | Manual, automatic operation, stepless continuous adjusted |
| 255 steps. No grey loss | |
| Out of control point | <1/10000 |
| Working hours | ≥72hours |
| Mean Time Between Failure | >5000hours |
| Life time | 100000hours |
| Life-all-white(brightness halving) | 50000hours |
| Environment temperature range | Operating temperature range: -20-45℃ |
| Maximum power:/square meter | <900W |
| Average power:/square meter | <300W |
| Self-check technology | LED spot self-check, communications check, power check, |
| temperature monitor(need customization) | |
| Remote monitoring | Remote supervision and control, record potential fault, |
| send out warning signs to the operators.(need customization) | |
| Software environment | WindowsNT,Windows1999,WindowsXP |
| Luminous point width between centres | Deviation<3% |
| Brightness uniformity | <10% |
| Color uniformity(chromaticity coordinate) | ±0.003 |
| Power supply request | AC85-264V(50Hz-60Hz) |
| Contrast | (1000:1) |
| System protection | Moistureproof,dustproof,high temperature protection,anti-corrosion,anti-burning,anti-static,anti-vibration |
| Humidity(working) | working:10-95% |
| Humidity(storing) | storing:10-95% |
FAQ
1.Q:Are you a factory or trading company?
A:We are a factory,located in Dalang,Longhua District .
2.Q:What kind of payment terms you accept?
A:We accept T/T,Western Union,MoneyGram etc.
3.Q:What's packaging?
A:1.Flight case packaging
2.Wooden case packaging
3.36pcs in one case packaging
4.Customized packaging
4.Q:Does you have CE/ROHS certificates?
A:Yes, we offer the CE & ROHS certificates .
5.Q:What's the shipping method,shipping time?
A:Our products could be shipped by Sea, by Air, and by Express.
by sea:20-40days; by air:5-10days ;by express:3-6days
