| Place of Origin: | China(Mainland) |
| Brand Name: | SCXK |
| Certification: | CE,ISO,FCC,UL |
| Model Number: | SCXK-P10 |
| Minimum Order Quantity: | 3 sqm |
|---|---|
| Price: | 300-400USD/sqm |
| Packaging Details: | Wooden and flight cases. |
| Delivery Time: | 12-15 working days. |
| Payment Terms: | T/T, Western Union |
| Supply Ability: | 5000sqm/month |
| Application Place: | Outdoor | Pixel Pitch: | 10mm |
|---|---|---|---|
| Waterproof: | IP65 | Cabinet Material: | Iron |
| Cabinet Size: | 960*960mm | Brightness: | 5500cd/sqm |
| Pixel Density: | 10000dots/sqm | Warranty: | 2 Years |
| Highlight: | P10 Outdoor Full Color LED Display,Waterproof Outdoor Full Color LED Display |
||
Outdoor Full Color LED Display P10 Post Screen IP65 Large Size 1/4 Scan Mode
Our advantages:
1. Imported high-end luminous materials, high-quality dedicated IC chips, noise-free high-power power supply;
2. Static/dynamic constant current drive;
3. High brightness, high grayscale, high contrast, high density, wide viewing angle, high stability;
4. High color uniformity, high color saturation, delicate and clear image edges; smooth video effect;
Specifications :
| Outdoor P10 LED Display Screen | |||||
| Resolution/mm | 10 | ||||
| Pixel configuration | 1R1G1B | ||||
| Pixel density/pixels/m² | 10000/square meter | ||||
| Module resolution | 32x16 | ||||
| Module size/mm | 320x160 | ||||
| View distance | 10-100m | ||||
| Single point brightness adjust | Can be added | ||||
| Single point color adjust | Can be added | ||||
| White balance brightness | 5500cd/square meter | ||||
| Color temperature | 6500K-9500K | ||||
| Horizontal view angle | 120(degrees) | ||||
| Vertical view angle | 60(degrees) | ||||
| Signal Process bit | 10 or 16bit | ||||
| Grey process | 1024x1024x1024 16834x16834x16834 65536x65536x65536 | ||||
| Control distances | Internet cable:100m, multimembrane:500m, monofilm:2km | ||||
| Driving mode | Constant driving current | ||||
| Scanning mode | 1/4 SCANNING | ||||
| Frame rate | 60Hz | ||||
| Refresh frequency | >1000Hz | ||||
| Control mode | Computer synchronous | ||||
| Brightness adjusted range | Manual, automatic operation, stepless continuous adjusted | ||||
| 255 steps. No grey loss | |||||
| Out of control point | <1/10000 | ||||
| Working hours | ≥72hours | ||||
| Mean Time Between Failure | >5000hours | ||||
| Life time | 100000hours | ||||
| Life-all-white(brightness halving) | 50000hours | ||||
| Environment temperature range | Operating temperature range: -20-45℃ | ||||
| Self-check technology | LED spot self-check, communications check, power check, | ||||
| temperature monitor(need customization) | |||||
| Remote monitoring | Remote supervision and control, record potential fault, | ||||
| send out warning signs to the operators.(need customization) | |||||
| Software environment | WindowsNT,Windows1999,WindowsXP | ||||
| Luminous point width between centres | Deviation<3% | ||||
| Brightness uniformity | <10% | ||||
| Color uniformity(chromaticity coordinate) | ±0.003 | ||||
| Power supply request | AC85-264V(50Hz-60Hz) | ||||
| Contrast | (1000:1) | ||||
| System protection | Moistureproof,dustproof,high temperature protection,anti-corrosion,anti-burning,anti-static,anti-vibration | ||||
| Humidity(working) | working:10-95% | ||||
| Humidity(storing) | storing:10-95% | ||||
Short descriptions:
1. P10 outdoor LED display, high protection level, dustproof, waterproof, and corrosion-resistant;
2. Ultra-high resolution, bright colors;
3. Energy-saving and environmentally friendly, high cost performance;
4. 120-degree ultra-wide viewing angle, ultra-large viewing angle, watch at will;
5. Ultra-high uniformity, relieve eye fatigue;
6. Seamless splicing;
Applications places:
1.Educational publicity: the interactive system of campus area, training institutions and so on;
2.Public Places: Information Reality of Airport, Railway, Subway, Highway, Library, Museum, Mall and Other Places;
3.Commercial demonstrations: TV studios, large-scale performances and commercial exhibitions, Hotel lobbies, enterprises and institutions, etc. 4.Government Departments: Publicity for the People, Guidelines for Handling Affairs, Openness of Government Affairs, etc.
