Iron Cabinet Advertising LED Screen, Full-Color Outdoor LED Display Rental, Suitable For Streets And Commercial Streets

Iron Cabinet Advertising LED Screen, Full-Color Outdoor LED Display Rental, Suitable For Streets And Commercial Streets

  • Iron Cabinet Advertising LED Screen, Full-Color Outdoor LED Display Rental, Suitable For Streets And Commercial Streets
  • Iron Cabinet Advertising LED Screen, Full-Color Outdoor LED Display Rental, Suitable For Streets And Commercial Streets
  • Iron Cabinet Advertising LED Screen, Full-Color Outdoor LED Display Rental, Suitable For Streets And Commercial Streets
  • Iron Cabinet Advertising LED Screen, Full-Color Outdoor LED Display Rental, Suitable For Streets And Commercial Streets
Iron Cabinet Advertising LED Screen, Full-Color Outdoor LED Display Rental, Suitable For Streets And Commercial Streets
Product Details:
Place of Origin: China ,Guang Dong
Brand Name: Shichuangxinke
Certification: CE RoHS FCC CCC TUV UL
Model Number: SCXK-P25
Payment & Shipping Terms:
Minimum Order Quantity: 1 square meters
Price: negotiation
Packaging Details: wooden box flight case, wooden case, carton, it is up to you.
Delivery Time: 7-10 working days after deposit payment received
Payment Terms: L/C, T/T, Western Union, D/A, D/P, MoneyGram
Supply Ability: 5000sqm per month
Contact Now
Detailed Product Description
Pixel Pitch: 25mm Pixel Configuration: 1R1G1B
Scanning Mode: Static Full Color Module Size: 200x200mm
Cabinet Size: 1600x1200mm Certificates: CE RoHS FCC CCC UL
Application: Stadium,airport,shopping Mall,street Advertising Material: Aluminum
Warranty: 2-3 Years
Highlight:

Streets Outdoor LED Display Rental

,

Full Color Outdoor LED Display Rental

,

Commercial Streets Outdoor LED Display Rental



Iron Cabinet Rigid Advertising Led Screens , Full Color Outdoor Smd Led Display Rental





Product Introduction

1. High brightness, wide viewing angle, using SMD LED lamp beads, the brightness can reach more than 6500cd/m², which is very suitable for outdoor environments. The three-in-one LED lamp beads have good color mixing effect, especially the color reproduction and viewing angle are excellent, giving people a visual experience far beyond the traditional outdoor DIP full-color display.

2. Use energy-saving (low constant current at the control point) and high-efficiency constant current chips;

3. Use high-brightness and high-efficiency LED lamp beads;



Feature

1 . Good LEDs: Our factory LEDs has excellent performance in antistatic ability and UV protection; Waterproof SMD 3 in 1 LED lamp: IP65 grade, all-weather available



2 . Energy saving: Low electric current, high-bright lamps, equipped with PFC switching power supply, save 30% electricity.



3 . High refresh rate, high gray level: It can reach 16bit by using PWM driving IC, refresh rate is more than 4000HZ, the gray level is still high even under the condition of low brightness.



4 . Color correction: Support dot-to-dot correction, guarantee the consistence of LED color and brightness, No chromatic aberration for new screens.



5 . Dual back-up: Both power supply and system dual back-up are optional, reliable performance



6 . Detection and monitoring: It can monitor the inner temperature, voltage, cooling fans Etc and error detection automatically.





Specifications :



outdoor DIP P25
Resolution/mm 25
Pixel configuration 1R1G1B
Pixel density/pixels/m² 1600/m²
Module resolution 8x8
Module size/mm 200x200MM
View distance 14-300m
Single point brightness adjust Can be added
Single point color adjust Can be added
White balance brightness >7500cd/㎡
Color temperature 6500K-9500K
Horizontal view angle 120(degrees)
Vertical view angle 60(degrees)
Signal Process bit 10 or 16bit
Grey process 1024x1024x1024 16834x16834x16834 65536x65536x65536
Control distances Internet cable:100m, multimembrane:500m, monofilm:2km
Driving mode Constant driving current
Scanning mode 1/4 SCANNING
Frame rate 60Hz
Refresh frequency >3000Hz
Control mode Computer synchronous
Brightness adjusted range Manual, automatic operation, stepless continuous adjusted
255 steps. No grey loss
Out of control point <1/10000
Working hours ≥72hours
Mean Time Between Failure >5000hours
Life time 100000hours
Life-all-white(brightness halving) 50000hours
Environment temperature range Operating temperature range: -20-45℃
Self-check technology LED spot self-check, communications check, power check,
temperature monitor(need customization)
Remote monitoring Remote supervision and control, record potential fault,
send out warning signs to the operators.(need customization)
Software environment WindowsNT,Windows1999,WindowsXP
Luminous point width between centres Deviation<3%
Brightness uniformity <10%
Color uniformity(chromaticity coordinate) ±0.003
Power supply request AC85-264V(50Hz-60Hz)
Contrast (1000:1)
System protection Moistureproof,dustproof,high temperature protection,anti-corrosion,anti-burning,anti-static,anti-vibration
Humidity(working) working:10-95%
Humidity(storing) storing:10-95%







Advantage


1. We have the advantage of producing a full range of LED display screens

2: Indoor and outdoor P10, P8, P6, P4, P3, P3.91, P4.81, P2, P2.5, P1.976 are all in sufficient stock, and the quality is excellent, so you can buy and use with confidence
3. We have 24-hour online customer service to provide customers with product performance introduction and product advantage analysis; according to the actual situation and usage of customers, we will evaluate and select the most reasonable solution
4: At the same time, we can provide customers with professional LED display system operation and maintenance training, and solve display failures



Iron Cabinet Advertising LED Screen, Full-Color Outdoor LED Display Rental, Suitable For Streets And Commercial Streets 0

Iron Cabinet Advertising LED Screen, Full-Color Outdoor LED Display Rental, Suitable For Streets And Commercial Streets 1Iron Cabinet Advertising LED Screen, Full-Color Outdoor LED Display Rental, Suitable For Streets And Commercial Streets 2Iron Cabinet Advertising LED Screen, Full-Color Outdoor LED Display Rental, Suitable For Streets And Commercial Streets 3

Iron Cabinet Advertising LED Screen, Full-Color Outdoor LED Display Rental, Suitable For Streets And Commercial Streets 4





FAQ





1.Q:Are you a factory or trading company?

A:We are a factory,located in Dalang,Longhua District .



2.Q:What kind of payment terms you accept?

A:We accept T/T,Western Union,MoneyGram etc.



3.Q:What's packaging?

A:1.Flight case packaging

2.Wooden case packaging

3.36pcs in one case packaging

4.Customized packaging



4.Q:Does you have CE/ROHS certificates?

A:Yes, we offer the CE & ROHS certificates .



5.Q:What's the shipping method,shipping time?

A:Our products could be shipped by Sea, by Air, and by Express.

by sea:20-40days; by air:5-10days ;by express:3-6days
