Shenzhen Shichuangxinke Electronics Co.,Ltd
professional makes good quality, provide perfect product and service for every customer.
 |
| Place of Origin: | China ,Guang Dong |
| Brand Name: | Shichuangxinke |
| Certification: | CE RoHS FCC CCC TUV UL |
| Model Number: | SCXK-P8 |
| Minimum Order Quantity: | 1 square meters |
|---|---|
| Price: | negotiation |
| Packaging Details: | wooden box flight case, wooden case, carton, it is up to you. |
| Delivery Time: | 7-10 working days after deposit payment received |
| Payment Terms: | L/C, T/T, Western Union, D/A, D/P, MoneyGram |
| Supply Ability: | 5000sqm per month |
| Pixel: | 8mm | Pixel Configuration: | Red Green Blue |
|---|---|---|---|
| Scanning Mode: | 1/4 Scanning Mode | Module Size: | 256x128mm |
| HS Code: | 8528591090 | Application: | Airport,wall,church Wedding,exhibition Stand |
| Driver IC: | MB5024/MB5124 | Warranty: | 2-3 Years |
| Cabinet Size: | 1024x768mm/512x512mm | ||
| Highlight: | Commercial Center LED Display Screen,Large Scale LED Display Screen,High Stability LED Display Screen |
||
High Stability P8 Outdoor Full Color LED Display,commercial Center Advertising
Feature:
High-quality LEDs: Epistar DIP LEDs with excellent anti-static and UV protection; Waterproof SMD 3-in-1 LEDs: IP65 rated for all-weather use, with much better white balance than DIP series.
Energy saving: Low current, high brightness bulb, equipped with PFC switching power supply, power saving 30%.
High refresh rate, high grayscale: Adopting PWM driver IC, up to 16bit, refresh rate over 4000HZ, even under low brightness conditions, the grayscale is still very high.
Color Correction: Supports point-to-point correction to ensure the consistency of LED color and brightness, and no color difference of the new screen. 5.
5. Dual Backup: Power supply and system dual backup options, reliable performance...
6. Detection and monitoring: automatic monitoring of internal temperature, voltage, cooling fan, etc., automatic error detection.
The products in the table are commonly used products, drive mode and pixel pitch can be customized according to customer requirements.
| outdoor SMD P8 | |||||
| Resolution/mm | 8 | ||||
| Pixel configuration | 1R1G1B | ||||
| Pixel density/pixels/m² | 15625/m² | ||||
| Module resolution | 32x16 | ||||
| Module size/mm | 256x128 | ||||
| View distance | 14-300m | ||||
| Single point brightness adjust | Can be added | ||||
| Single point color adjust | Can be added | ||||
| White balance brightness | >7500cd/㎡ | ||||
| Color temperature | 6500K-9500K | ||||
| Horizontal view angle | 120(degrees) | ||||
| Vertical view angle | 60(degrees) | ||||
| Signal Process bit | 10 or 16bit | ||||
| Grey process | 1024x1024x1024 16834x16834x16834 65536x65536x65536 | ||||
| Control distances | Internet cable:100m, multimembrane:500m, monofilm:2km | ||||
| Driving mode | Constant driving current | ||||
| Scanning mode | 1/4SCANNING | ||||
| Frame rate | 60Hz | ||||
| Refresh frequency | >3000Hz | ||||
| Control mode | Computer synchronous | ||||
| Brightness adjusted range | Manual, automatic operation, stepless continuous adjusted | ||||
| 255 steps. No grey loss | |||||
| Out of control point | <1/10000 | ||||
| Working hours | ≥72hours | ||||
| Mean Time Between Failure | >5000hours | ||||
| Life time | 100000hours | ||||
| Life-all-white(brightness halving) | 50000hours | ||||
| Environment temperature range | Operating temperature range: -20-45℃ | ||||
| Self-check technology | LED spot self-check, communications check, power check, | ||||
| temperature monitor(need customization) | |||||
| Remote monitoring | Remote supervision and control, record potential fault, | ||||
| send out warning signs to the operators.(need customization) | |||||
| Software environment | WindowsNT,Windows1999,WindowsXP | ||||
| Luminous point width between centres | Deviation<3% | ||||
| Brightness uniformity | <10% | ||||
| Color uniformity(chromaticity coordinate) | ±0.003 | ||||
| Power supply request | AC85-264V(50Hz-60Hz) | ||||
| Contrast | (1000:1) | ||||
| System protection | Moistureproof,dustproof,high temperature protection,anti-corrosion,anti-burning,anti-static,anti-vibration | ||||
| Humidity(working) | working:10-95% | ||||
| Humidity(storing) | storing:10-95% | ||||
Other products:
Indoor fixed LED display: P2.5, P3, P4, P5, P6, P8, P10
Indoor rental LED display: P3, P3.9, P4, P4.8, P5, P6
Outdoor fixed LED display: P5, P6, P8, P10
Outdoor rental LED display: P3.9, P4.8, P5, P6, P6.25, P8, P10
Small pitch LED display: P1.6, P1.9
Front service maintenance LED display: P6.67, P8, P10
Stadium perimeter LED display: P8, P10
LED poster player: P2.5, P3, P4, P5, P6, P8, P10
Support and Services:
Our Rental LED Display products come with comprehensive technical support and services to ensure your experience is seamless and your events are successful. Our team of experienced technicians is dedicated to providing you with the necessary guidance and assistance to make the most of your LED display rental.
Our services include professional installation, which ensures that your display is set up correctly and operates flawlessly during your event. We provide detailed instructions and support for the setup and operation of the display, ensuring you have a clear understanding of how to manage the technology.
In the event that you encounter any technical difficulties, our on-call technical support team is ready to assist you with troubleshooting. We strive to resolve issues promptly to minimize any disruption to your service.
We also offer maintenance services to keep the LED display in optimal condition throughout the rental period. This includes regular checks and adjustments as needed to maintain the quality and performance of the display.
Furthermore, we provide training sessions for your staff on how to operate the LED display to ensure they are confident in managing it throughout the event. This training covers all aspects of the display's functionality, from basic operations to advanced features.
At the end of your rental period, our team will take care of the dismantling and removal of the LED display, ensuring that it is done safely and efficiently.
Our commitment to providing exceptional support and services is unwavering, and we are always looking for ways to enhance your rental experience. We are dedicated to ensuring that our Rental LED Displays not only meet but exceed your expectations.
Rental LED display products are carefully packaged to ensure their safety and integrity during transportation. Each panel is wrapped in protective foam and secured in a customized flight case to withstand the rigors of shipping and ease of handling. Flight boxes are stackable and come with reinforced corners and handles for added durability and convenience.
All boxes are inspected and sealed prior to shipment and are accompanied by a detailed packing list to verify the contents upon receipt. Rental LED displays are shipped using a reliable freight service with tracking options to monitor shipment progress prior to delivery. Customers are advised to inspect the product immediately upon arrival and report any discrepancies or damage to the carrier and our customer service team.
FAQ
1.Q:Are you a factory or trading company?
A:We are a factory,located in Dalang,Longhua District .
2.Q:What kind of payment terms you accept?
A:We accept T/T,Western Union,MoneyGram etc.
3.Q:What's packaging?
A:1.Flight case packaging
2.Wooden case packaging
3.36pcs in one case packaging
4.Customized packaging
4.Q:Does you have CE/ROHS certificates?
A:Yes, we offer the CE & ROHS certificates .
5.Q:What's the shipping method,shipping time?
A:Our products could be shipped by Sea, by Air, and by Express.
by sea:20-40days; by air:5-10days ;by express:3-6days
Contact Person: Lillian seori
Tel: +8619386814677
