Place of Origin: | China(Mainland) |
Brand Name: | SCX |
Certification: | CE,ISO,FCC,UL |
Model Number: | SCX-P6.67 |
Minimum Order Quantity: | negotiation |
---|---|
Price: | negotiation |
Packaging Details: | Carton,wooden and flight cases. |
Delivery Time: | 12-15 working days. |
Payment Terms: | T/T, Western Union, L/C, D/A, D/P, MoneyGram |
Supply Ability: | 5000sqm/month |
Pixels: | 6.67mm | Tube Chip Color: | Full Color |
---|---|---|---|
Display Function: | Video | Brightness: | 6500cd/sqm |
Warranty: | 2 Years | Life Span: | 100000hours |
Module Size: | 320x160mm | Led Chip: | Epistar,Kinglight |
Power Supply: | G-energy | Led Encapsulation: | SMD 3535 |
Highlight: | 6500cd/M² LED Billboard,2 Years Warranty LED Billboard,DC 5V LED Billboard |
Outdoor P6.67 LED Billboards Full Color High Quality on Hot Sale DC5V
Modern production science management
The company has advanced modern production equipment, scientific and rigorous management methods, attention to detail and quality. We have a high-quality team to provide customers with high quality, cost-effective products.
Pre-sale design
Before the sale, we listened carefully to the needs of our customers, reasonably selected products suitable for our customers, and developed a series of excellent LED display solutions. Customer satisfaction is our constant pursuit.
Fast after sales service
After the sale, we patiently answer the customer's questions, receive timely and accurately feedback from customers, improve product shortages, update product quality, solve customer concerns, and always adhere to a rigorous and innovative scientific attitude.
Specifications:
SMD P6.67 | |||||
Resolution/mm | 6.67 | ||||
Pixel configuration | 1R1G1B | ||||
Pixel density/pixels/m² | 22478/square meter | ||||
Module resolution | 48x24mm | ||||
Module size/mm | 320x160mm | ||||
View distance | 7-60m | ||||
Single point brightness adjust | Can be added | ||||
Single point color adjust | Can be added | ||||
White balance brightness | 6000cd/square meter | ||||
Color temperature | 6500K-9500K | ||||
Horizontal view angle | 120(degrees) | ||||
Vertical view angle | 60(degrees) | ||||
Signal Process bit | 10 or 16bit | ||||
Grey process | 1024x1024x1024 16834x16834x16834 65536x65536x65536 | ||||
Control distances | Internet cable:100m, multimembrane:500m, monofilm:2km | ||||
Driving mode | Constant driving current | ||||
Scanning mode | 1/8 SCANNING | ||||
Frame rate | 60Hz | ||||
Refresh frequency | 1200Hz | ||||
Control mode | Computer synchronous | ||||
Brightness adjusted range | Manual, automatic operation, stepless continuous adjusted | ||||
255 steps. No grey loss | |||||
Out of control point | <1/10000 | ||||
Working hours | ≥72hours | ||||
Mean Time Between Failure | >5000hours | ||||
Life time | 100000hours | ||||
Life-all-white(brightness halving) | 50000hours | ||||
Environment temperature range | Operating temperature range: -20-45℃ | ||||
Self-check technology | LED spot self-check, communications check, power check, | ||||
temperature monitor(need customization) | |||||
Remote monitoring | Remote supervision and control, record potential fault, | ||||
send out warning signs to the operators.(need customization) | |||||
Software environment | WindowsNT,Windows1999,WindowsXP | ||||
Luminous point width between centres | Deviation<3% | ||||
Brightness uniformity | <10% | ||||
Color uniformity(chromaticity coordinate) | ±0.003 | ||||
Power supply request | AC85-264V(50Hz-60Hz) | ||||
Contrast | (1000:1) | ||||
System protection | Moistureproof,dustproof,high temperature protection,anti-corrosion,anti-burning,anti-static,anti-vibration | ||||
Humidity(working) | working:10-95% | ||||
Humidity(storing) | storing:10-95% |
Main features:
1) Realistic images, low noise, advanced testing equipment, supports any computer operating system, can play multiple information, such as video, text, flash, music, clock, chart, etc. 2) High brightness, support automatic brightness adjustment. 3) Long life, up to 100,000 hours, while power consumption is less than one-tenth of light bulbs or neon lights; 4) Simple and easy-to-understand installation interface, easy-to-use software, ensure that the LED display system has a friendly user interface 5) Rich experience in indoor full-color LED display engineering in domestic and foreign markets.
Packing:
1.wooden case packing for ironed steel cabinet.
2.flight case packing for die casting aluminum cabinet.
Delivery:
Shipping by sea,air or DHL,multiple shipping ways for your choice.
