Place of Origin: | China(Mainland) |
Brand Name: | SCXK |
Certification: | CE,ISO,DCC,UL |
Model Number: | SCXK-P10 |
Minimum Order Quantity: | negotiation |
---|---|
Price: | negotiation |
Packaging Details: | Wooden and flight cases. |
Delivery Time: | 12-15 working days. |
Payment Terms: | T/T, Western Union, L/C, D/A, D/P, MoneyGram |
Supply Ability: | 5000 sqm/month |
Country Of Origin: | China | Brand: | SCXK |
---|---|---|---|
Pixel Pitch: | 10mm | Module Size: | 320*160mm |
Cabinet: | Iron | Brightness: | 5500cd/sqm |
Cabinet Size: | 960*960mm | Pixel Density: | 10000dots/sqm |
Highlight: | P10 Football Stadium LED Display,Full Color Sports Screen LED Display,Ultra HD Sports Screen LED Display |
Outdoor Full Color Statium LED Display P10 Football IP65 Large Screen HD
Ourdoor Series:
1. Outdoor full-color LED display screens are widely used, especially in today's era of rapid development.
In the era of information explosion, the application of full-color display screens has reached its peak.
Large supermarkets, offline stores and public relations media will inevitably use full-color display screens, especially in large-scale events, such as award ceremonies, concerts, wedding entertainment, etc.
2. Another major advantage of full-color display screens is energy saving and environmental protection,
which is very consistent with the theme of today's era and is increasingly favored by the national government;
Generally speaking, many government projects are like this. Therefore, buying high-quality and low-priced products is the way to make money.
3. Our company has been established for more than ten years and has rich product
experience and sales services. At present, our products have been exported to more than 20 countries overseas,
and have established long-term cooperative relations. In the future, I hope you will become our next customer!
Specifications :
Outdoor P10 LED Display Screen | |||||
Resolution/mm | 10 | ||||
Pixel configuration | 1R1G1B | ||||
Pixel density/pixels/m² | 10000/square meter | ||||
Module resolution | 32x16 | ||||
Module size/mm | 320x160 | ||||
View distance | 10-80m | ||||
Single point brightness adjust | Can be added | ||||
Single point color adjust | Can be added | ||||
White balance brightness | 5500cd/square meter | ||||
Color temperature | 6500K-9500K | ||||
Horizontal view angle | 120(degrees) | ||||
Vertical view angle | 60(degrees) | ||||
Signal Process bit | 10 or 16bit | ||||
Grey process | 1024x1024x1024 16834x16834x16834 65536x65536x65536 | ||||
Control distances | Internet cable:100m, multimembrane:500m, monofilm:2km | ||||
Driving mode | Constant driving current | ||||
Scanning mode | 1/4 SCANNING | ||||
Frame rate | 60Hz | ||||
Refresh frequency | >1200Hz | ||||
Control mode | Computer synchronous | ||||
Brightness adjusted range | Manual, automatic operation, stepless continuous adjusted | ||||
255 steps. No grey loss | |||||
Out of control point | <1/10000 | ||||
Working hours | ≥72hours | ||||
Mean Time Between Failure | >5000hours | ||||
Life time | 100000hours | ||||
Life-all-white(brightness halving) | 50000hours | ||||
Environment temperature range | Operating temperature range: -20-45℃ | ||||
Self-check technology | LED spot self-check, communications check, power check, | ||||
temperature monitor(need customization) | |||||
Remote monitoring | Remote supervision and control, record potential fault, | ||||
send out warning signs to the operators.(need customization) | |||||
Software environment | WindowsNT,Windows1999,WindowsXP | ||||
Luminous point width between centres | Deviation<3% | ||||
Brightness uniformity | <10% | ||||
Color uniformity(chromaticity coordinate) | ±0.003 | ||||
Power supply request | AC85-264V(50Hz-60Hz) | ||||
Contrast | (1000:1) | ||||
System protection | Moistureproof,dustproof,high temperature protection,anti-corrosion,anti-burning,anti-static,anti-vibration | ||||
Humidity(working) | working:10-95% | ||||
Humidity(storing) | storing:10-95% |
Some customers' concerns:
1.Is it really possible to make money because of the large upfront cost?
-There is an old Chinese saying:won't loathe to give up the child set of wolves.
If you want to make your business,you should have the foresight,patience and investment.
But the most important is that you should choose the right product,like our products,it's suitable in many areas,
after choosing it,you should firmly believe the product cna bring you the profiel.
2.I've never heard your brand,how can i trust you?
-There are many things you've never seen before in the world,and in your home there must be some
things you bought also the small brand,but it is good to use. We can't guarantee everything is too famous to let everybody know,
but we can promise you the high quality and the reasonable price.The only thing you need to do is
to give us the chance and try to trust us,we won't let you down!
