Shenzhen Shichuangxinke Electronics Co.,Ltd
professional makes good quality, provide perfect product and service for every customer.
 |
| Place of Origin: | China(Mainland) |
| Brand Name: | SCXK |
| Certification: | ISO,CE,FCC,UL |
| Model Number: | SCXK-P8 |
| Minimum Order Quantity: | negotiation |
|---|---|
| Price: | negotiation |
| Packaging Details: | Wooden and flight cases,it's up to you. |
| Delivery Time: | 12-15 working days after receiving your down payment. |
| Payment Terms: | T/T, Western Union, L/C, D/A, D/P, MoneyGram |
| Supply Ability: | 5000 sqms/month |
| Pixel Pitch: | 8mm | Control System: | Nova |
|---|---|---|---|
| Type Of Cabinet: | Die-cast Aluminum/Iron | Working Voltage: | DC5V |
| Outdoor Options: | P3.91,P4,P4.81,P5,P5.95,P6,P6.67,P8,P10 | Payment: | T/T,Western Union |
| Application Places: | Shopping Mall,Stations,Airports，Commercial Centure... | Certifications: | CE,ISO,FCC,UL. |
| Highlight: | P8 Advertising LED Screen,SMD 3528 Advertising LED Screen,Outdoor Waterproof Advertising LED Screen |
||
SMD 3528 IP65 Outdoor Full Color Advertising LED Screen P8 Nova and Linsn System
Application and Market:
1.Application
Widely use in stadiums, advertisement, banks, securities exchange, stations, shopping malls, postal offices, schools, restaurants, entertainment, enterprises ,highway etc
2.Market:
1) North America, South America, Eastern Europe, Southeast Asia, Africa, Oceania, Middle East, East Asia, Western Europe. We have professional R&D, production and quality control teams.
2) 8 R&D personnel with more than 8 years of LED market experience, can provide OEM/ODM services;
3) Own advanced imported LED packaging, SMD patch and reflow soldering equipment.
4) Professional production workers: about 200 people
5) Production lines: 10
6) Monthly production capacity: 50,000 pieces
Specifications of products:
| SMD 3528 IP65 Outdoor Full Color Advertising LED Screen P8 | |||||
| Resolution/mm | 8 | ||||
| Pixel configuration | 1R1G1B | ||||
| Pixel density/pixels/m² | 15625/square meter | ||||
| Module resolution | 40*20mm | ||||
| Module size/mm | 256*128mm | ||||
| View distance | 8-300m | ||||
| Single point brightness adjust | Can be added | ||||
| Single point color adjust | Can be added | ||||
| White balance brightness | >8000cd/square meter | ||||
| Color temperature | 6500K-9500K | ||||
| Horizontal view angle | 120(degrees) | ||||
| Vertical view angle | 60(degrees) | ||||
| Signal Process bit | 10 or 16bit | ||||
| Grey process | 1024x1024x1024 16834x16834x16834 65536x65536x65536 | ||||
| Control distances | Internet cable:100m, multimembrane:500m, monofilm:2km | ||||
| Driving mode | alternating driving current | ||||
| Scanning mode | 1/8 | ||||
| Fresh rate | 60Hz | ||||
| Refresh frequency | >3000Hz | ||||
| Control mode | Asynchronous,3G,4G,Wifi | ||||
| Brightness adjusted range | Manual, automatic operation, stepless continuous adjusted | ||||
| 255 steps. No grey loss | |||||
| Out of control point | <1/10000 | ||||
| Aging hours | ≥72hours | ||||
| Mean Time Between Failure | >5000hours | ||||
| Life time | 100000hours | ||||
| Life-all-white(brightness halving) | 50000hours | ||||
| Environment temperature range | Operating temperature range: -20-45℃ | ||||
| Self-check technology | LED spot self-check, communications check, power check, | ||||
| temperature monitor(need customization) | |||||
| Remote monitoring | Remote supervision and control, record potential fault, | ||||
| send out warning signs to the operators.(need customization) | |||||
| Software environment | WindowsNT,Windows1999,WindowsXP | ||||
| Luminous point width between centres | Deviation<3% | ||||
| Brightness uniformity | <10% | ||||
| Waterproof | Ip65 | ||||
| Color uniformity(chromaticity coordinate) | ±0.003 | ||||
| Power supply request | AC85-264V(50Hz-60Hz) | ||||
| Contrast | (1000:1) | ||||
| System protection | Moistureproof,dustproof,high temperature protection,anti-corrosion,anti-burning,anti-static,anti-vibration | ||||
| Humidity(working) | working:10-95% | ||||
| Humidity(storing) | storing:10-95% | ||||
Our service:
1. Complaint respond period not exceed 24 hours; maintenance guidance and problem solution supplied in 48 hours.
2. Warranty: 24 months.
3. Free technician training.
4. Full set of documents free of charge, which including installation guidance, software operation manual, easy maintenance manual and control system software CD and so on.
__________________________________FAQ____________________________________
Q1: What is the payment method?
