Shenzhen Shichuangxinke Electronics Co.,Ltd
professional makes good quality, provide perfect product and service for every customer.
 |
| Place of Origin: | Made in china |
| Brand Name: | SCXK |
| Certification: | CE,ROHS, FCC.UL.CUL |
| Model Number: | SCXK-P6 |
| Minimum Order Quantity: | one cabinet sand one module can be avaiable. |
|---|---|
| Price: | Negotiable |
| Packaging Details: | wooden box, flight case, paper box |
| Delivery Time: | within 7-10days |
| Payment Terms: | D/A, L/C, D/A, D/P, T/T, Western Union, MoneyGram |
| Cabinet Size: | 960mm X960mm | Module Size: | 192mm X192mm |
|---|---|---|---|
| Warranty: | 3 Years | Refresh Rate: | 2500hz |
| Led Chip: | Epistar | Color: | Full Color |
| Scan Way: | 1/16 Scan | Dot Density: | 27777dots/sqm |
| Use: | Advertising Publish, Shopping Mall, Welcome Display, Restaurant & Hotel Supplies | Specification: | Video Wall |
| Place Of Origin: | Guangdong China | ||
| Highlight: | HD Stage LED Rental Screen,Outdoor Stage LED Rental Screen,High Resolution Stage LED Rental Screen |
||
P6 SMD3528 Stage LED Screens , LED Stage Screen 960mm x960mm cabinet
re-sale service:
1.Respond to inquiries within 24 hours.
2.Conduct market research and forecast for customers
3.Provide unique and professional solutions according to customer requirements.
In-sale service:
1.Tracking report during the production process.
2.Quality inspection report for each order
3.Photo and video according to customer's request.
4.Free spare parts.
After-sale service:
1.
Lifetime free maintenance and upgrade.
2. Complaints response time not more than 24 hours; provide maintenance guidance and problem solutions within 48 hours.
3.Customer satisfaction tracking report.
4. Free technician training.
5. Provide a full set of documents for free, including installation instructions, software operation manuals, simple maintenance manuals and control system software CD-ROMs.
6. Specialized services for large-scale projects, such as stadiums, exhibitions, plazas, etc.
| the indoor full color led display module( indoor usage only) | ||||||
| Number | drive mode | module size | resolution | led standard | pixel density | |
| p1.923 | 1/32scan | 246x246mm | 128x128 | 3 in 1 | 270420 | |
| p2 | 1/32scan | 128x64mm | 64x32 | 3 in 1 | 250000 | |
| p2.5 | 1/16scan | 160x160mm | 64x64 | 3 in 1 | 160000 | |
| p3 | 1/16scan | 192x192mm | 64x64 | 3 in 1 | 111111 | |
| p3.91 | 1/16scan | 250x250mm | 64x64 | 3 in 1 | 65410 | |
| p4 | 1/16scan | 256x128mm | 64x32 | 3 in 1 | 62500 | |
| p5 | 1/16/scan | 320x160mm | 64x32 | 3 in 1 | 40000 | |
| p6 | 1/16scan | 384x192mm | 64x32 | 3 in 1 | 27778 | |
| p7.62 | 1/8 scan | 244x244mm | 32x16 | 3 in 1 | 17222 | |
| p10 | 1/8 scan | 320x160mm | 32x16 | 3in 1 | 10000 | |
| Parameter | P6 | |
| Basic Parameter | Pixel Configuration | SMD 3 in 1 |
| Pixel Pitch (mm) | 6.0mm | |
| Pixel Density | 27777 pixels/m2 | |
| Cabinet Resolution | 160*160pixels | |
| Cabinet Dimension(W*H*D) | 640*640mm | |
| Weight (kg/sqm) | 35kg | |
| Cabinet Material | iron and steel cabinet | |
| Optical Parameter | Color Grayscale (bit) | 16bit |
| Frame Frequency (Hz) | 50/60Hz | |
| Brightness (nit) | 2,000 cd/m2 | |
| Viewing angle | 140°/140° | |
| Flatness error | ≤0.5mm | |
| Using Parameter | Working Voltage (V) | AC: 100-240V(50/60 Hz) |
| Max. Power Consumption | 600 W/sqm | |
| Storage Temperature (°C) | -20~60 | |
| Operating Temperature (°C) | -10~40 | |
| Storage Humidity (RH) | 10%~90% | |
| Operating Humidity (RH) | 10%~90% | |
| IP Rating (Front / Rear) | IP43 | |
| Lifetime Typical Value (hrs) | 50,000 | |
Continues Quality
With more than 10 years experience in led display producing,equipments are updated regularly.What’s
more,unique standardized and module production ensure our products continuous quality.
Competitive Price
With large scale production capacity and professional production technology,our company have built
effective modular production.We always stick to promote the technical innovation and reduce cost to
benefit customers.
Fast Delivery
Once we promise the delivery date,we will try our best to fulfill it.Special procedures such as emergency
inventory will be used to maintain your uninterrupted supply of the products.
Perfect Service
Pre-sales:Your purchasing requirements will be highly valued and we’ll recommend suitable products to you.After-sales:We will track the products usage and then constantly perfect our products.
