Place of Origin: | Made in china |
Brand Name: | SCXK |
Certification: | CE,ROHS, FCC.UL.CUL |
Model Number: | SCXK-P4 |
Minimum Order Quantity: | one cabinet sand one module can be avaiable. |
---|---|
Price: | Negotiable |
Packaging Details: | wooden box, flight case, paper box |
Delivery Time: | within 7-10 days |
Payment Terms: | D/A, L/C, D/A, D/P, T/T, Western Union, MoneyGram |
Material: | Die Cast Aluminum Cabinet | Cabinet Size: | 640mm X 640mm |
---|---|---|---|
Module Size: | 320mm X 160mm | Warranty: | 3 Years |
Refresh Rate: | 3000hz | Led Chip: | Epistar |
Color: | Full Color | Scan Way: | 1/16 Scan |
Dot Density: | 62500dots/sqm | Use: | Advertising Publish, Shopping Mall, Welcome Display, Restaurant & Hotel Supplies |
Specification: | Video Wall | Place Of Origin: | Guangdong China |
Highlight: | Event Outdoor LED Rental Screen,Outdoor High Definition LED Rental Screen |
Lightweight rgb Stage LED Screens , Indoor LED Video Wall Noiseless 62500 dots / sqm
SCXK has been specialized in LED field since 2005. We are a leading manufacturer an provider of technical solution of full color indoor
and outdoor led display,rental LED display, led modules where in Shenzhen city Guang dong province,China.
My company's customer service tenet is: "Clients are always the first.”
We manage customer satisfaction and loyalty;
We improve the competence of our customer service staff;
We handle customer complaints appropriately with optimism and do our best to satisfy our customers.
We consider all aspects of our customers' needs in a timely manner and serve them with the utmost professional competence.
The detailed parameter of indoor P4 stage led display as follows.
LED Lamps | Type | SMD2121 (High Brightness LEDs) | ||||||
LED Standard | Real Pixel(1R1G1B) | |||||||
Red Wavelength | 625-630nm | |||||||
LED Module | Pixel Pitch | 4mm | ||||||
Module Size | 320mmx160mm | |||||||
Module Resolution | 80*40 dots | |||||||
LED Cabinet | Cabinet Size | 640mm x 640mm | ||||||
Cabinet Resolution | 160pixels *160pixels | |||||||
Cabinets Material | Sealed Iron Cabinet | |||||||
led screen | Pixel Density | 62500pixels/sq.m | ||||||
Drive IC | MBI5124 | |||||||
Power Supply | Series connection | |||||||
Brightness | >2500cd/sqm | |||||||
Display Color | 16.7million | |||||||
Viewing Angle | 160°(Horizontal),110°(Vertical) | |||||||
Best Viewing Distance | 4m~200m | |||||||
Max Power Consumption | 600 w/sq.m | |||||||
Weight | 22kgs/sq.m | |||||||
Refresh Rate | 3000hz | |||||||
Input Voltage | AC220V/50H or AC110V/60H | |||||||
Output Voltage | DC5V,40A | |||||||
Grey Scale Levels | 16bit | |||||||
Display Colors | R(1024) x G(1024) x B(1024) | |||||||
MTBF | 10,000 hours | |||||||
Life-span | 100,000 hours | |||||||
Drive Mode | 1/16 scaning | |||||||
Working Humidity | 10%~99% | |||||||
Control System | Control method | Synchronization & Asynchronization | ||||||
Control System | (software) linsn | |||||||
Software | LED Studio | |||||||
PC Operating system | Microsoft Windows 7, 98, 2000, XP and Vista |
Continues Quality
With more than 10 years experience in led display producing,equipments are updated regularly.What’s
more,unique standardized and module production ensure our products continuous quality.
Competitive Price
With large scale production capacity and professional production technology,our company have built
effective modular production.We always stick to promote the technical innovation and reduce cost to
benefit customers.
Fast Delivery
Once we promise the delivery date,we will try our best to fulfill it.Special procedures such as emergency
inventory will be used to maintain your uninterrupted supply of the products.
Perfect Service
Pre-sales:Your purchasing requirements will be highly valued and we’ll recommend suitable products to you.After-sales:We will track the products usage and then constantly perfect our products.
Free Training
Via internet, or in our workshop, we provide all the training including process of operation, installation, maintenance, system set up, etc.
Warranty
1, 2-3years accrording to the contract .From beginning of installation finished the led display, we will be responsible for all the quality problem.
2, After the completion of the project, we will conduct life maintenance of the system continuously and update the and software.
3, For the hardware equipment, we only collect expenses on components.
