Shenzhen Shichuangxinke Electronics Co.,Ltd
professional makes good quality, provide perfect product and service for every customer.
 |
| Place of Origin: | China (Mainland) |
| Brand Name: | SCXK |
| Certification: | CE ,RoHS, FCC.CCC,SAA ,TUV ,UL |
| Model Number: | SCXK-P3 |
| Minimum Order Quantity: | Negotiations |
|---|---|
| Price: | Negotiations |
| Packaging Details: | Wooden and flight case,it's up to you. |
| Delivery Time: | 7-10 working days after payment |
| Payment Terms: | T/T, L/C, MoneyGram, Western Union, D/A, D/P |
| Supply Ability: | 5000sqs/month |
| Pitch: | 3mm | Pixel Density: | 111111dots/sq |
|---|---|---|---|
| LED Chip: | Epistar,Silan | Cabinet Material: | Aluminum/Iron |
| Application Place: | Dance Floor,Stadium,Airport,Shopping Mall Advertising | Module Size: | 192*192mm |
| Cabinet Size: | 576*576mm | Brightness: | ≥1500cd/sq |
| Warranty: | 3-5years | Certifications: | CE ,RoHS, FCC,CCC,SAA ,TUV ,UL |
| Highlight: | HD LED Video Wall Panel,P3 Full Color LED Display Screen,P3 Indoor Outdoor LED Display Screen |
||
Indoor P3 Full Color Advertising Screens Video HD 192*192mm Module Aluminum
Quick Detail:
1. Resolution up to 160,000 pixels/㎡;
2. LED chip: Eppistar high brightness;
3. Brightness up to 7000cd/㎡;
4. Power supply: Meanwell; G-nergy, driver led by changlian
5. Control systems: Linsn, Nova, etc.
Description:
1, P2.5 SMD LED display is high resolution for indoor LED screens use;
2, Large viewing angle at 140 degree horizontal and vertical;
3, Eletronic digital sign P2.5 is being used more and more, as LED screens trend is high resolution.
4, Clear and vivid advertising image and video;
5, High contrast ratio at 1000:1 to present true and natural color LED screens;
Applications:
Airport Indoor Full Color LED Display Advertising
Full-color LED display in the train station
Entertainment column indoor full color LED display
Full-color LED display in the gymnasium
Full-color LED display in the museum
Automobile exhibition LED display
Full-color LED video display in the conference room
Full-color LED display in the shopping center
Specifications :
| Indoor Full Color P3 LED Display | |||||
| Resolution/mm | 3 | ||||
| Pixel configuration | 1R1G1B | ||||
| Pixel density/pixels/m² | 111111/square meter | ||||
| Module resolution | 64x64 | ||||
| Module size/mm | 192x192MM | ||||
| View distance | 14-300m | ||||
| Single point brightness adjust | Can be added | ||||
| Single point color adjust | Can be added | ||||
| White balance brightness | >1500cd/square meter | ||||
| Color temperature | 6500K-9500K | ||||
| Horizontal view angle | 120(degrees) | ||||
| Vertical view angle | 60(degrees) | ||||
| Signal Process bit | 10 or 16bit | ||||
| Grey process | 1024x1024x1024 16834x16834x16834 65536x65536x65536 | ||||
| Control distances | Internet cable:100m, multimembrane:500m, monofilm:2km | ||||
| Driving mode | Constant driving current | ||||
| Scanning mode | 1/32 SCANNING | ||||
| Frame rate | 60Hz | ||||
| Refresh frequency | >3000Hz | ||||
| Control mode | Computer synchronous | ||||
| Brightness adjusted range | Manual, automatic operation, stepless continuous adjusted | ||||
| 255 steps. No grey loss | |||||
| Out of control point | <1/10000 | ||||
| Working hours | ≥72hours | ||||
| Mean Time Between Failure | >5000hours | ||||
| Life time | 100000hours | ||||
| Life-all-white(brightness halving) | 50000hours | ||||
| Environment temperature range | Operating temperature range: -20-45℃ | ||||
| Self-check technology | LED spot self-check, communications check, power check, | ||||
| temperature monitor(need customization) | |||||
| Remote monitoring | Remote supervision and control, record potential fault, | ||||
| send out warning signs to the operators.(need customization) | |||||
| Software environment | WindowsNT,Windows1999,WindowsXP | ||||
| Luminous point width between centres | Deviation<3% | ||||
| Brightness uniformity | <10% | ||||
| Color uniformity(chromaticity coordinate) | ±0.003 | ||||
| Power supply request | AC85-264V(50Hz-60Hz) | ||||
| Contrast | (1000:1) | ||||
| System protection | Moistureproof,dustproof,high temperature protection,anti-corrosion,anti-burning,anti-static,anti-vibration | ||||
| Humidity(working) | working:10-95% | ||||
| Humidity(storing) | storing:10-95% | ||||
Our advantages:
1. High quality for good price.
2. Quick delivery after payment.
3. Provide free technical support.
4. Warranty for 3-5 years.
5. If any questions,we'll replay and solve it in 24 hours.
♦ Frequently Asked Questions
What kind of payment terms you can accept ?
We can accept T/T and Western Union.
What about your Led Display quality ?
Checking in the whole manufacturing process&100% inspection before shipment ensure the quality of
our products continuity.
What is your delivery time ?
Within 7-35 days according to your area and quantity.
Is your LED display competitive ?
Yes,we are led display manufacturer for more than 10 years.Mass and professional production ensure
our led display’s competitiveness.
Welcome to visit our website and inquire us more info!!!
Waiting for you all the time!!!
