Shenzhen Shichuangxinke Electronics Co.,Ltd
professional makes good quality, provide perfect product and service for every customer.
 |
| Place of Origin: | Made in china |
| Brand Name: | SCXK |
| Certification: | CE,ROHS, FCC.UL.CUL |
| Model Number: | SCXK-P4 |
| Minimum Order Quantity: | one cabinet sand one module can be avaiable. |
|---|---|
| Price: | Negotiable |
| Packaging Details: | wooden box, flight case, paper box |
| Delivery Time: | within 7-10 days |
| Payment Terms: | D/A, L/C, D/A, D/P, T/T, Western Union, MoneyGram |
| Material: | Die Cast Aluminum Cabinet | Cabinet Size: | 640mm X 640mm |
|---|---|---|---|
| Module Size: | 320mm X 160mm | Warranty: | 3 Years |
| Refresh Rate: | 3000hz | Led Chip: | Epistar |
| Color: | Full Color | Scan Way: | 1/16 Scan |
| Dot Density: | 62500dots/sqm | Use: | Advertising Publish, Shopping Mall, Welcome Display, Restaurant & Hotel Supplies |
| Specification: | Video Wall | Place Of Origin: | Guangdong China |
| Highlight: | Indoor LED TV Wall,Noiseless Stage LED Screen |
||
Lightweight rgb Stage LED Screens , Indoor LED Video Wall Noiseless 62500 dots / sqm
SCXK has been specialized in LED field since 2005. We are a leading manufacturer an provider of technical solution of full color indoor
and outdoor led display,rental LED display, led modules where in Shenzhen city Guang dong province,China.
My company's customer service tenet is: "Clients are always the first.”
we manage the satisfaction and loyalty of customers;
we improve the ability of customer service staffs;
we properly handle the complaints from our customers with an optimistic attitude and make the greatest efforts to customer satisfaction.
We put in time every need of our clients from all aspects into our consideration and serve it with our most professional ability.
The detailed parameter of indoor P4 stage led display as follows.
| LED Lamps | Type | SMD2121 (High Brightness LEDs) | ||||||
| LED Standard | Real Pixel(1R1G1B) | |||||||
| Red Wavelength | 625-630nm | |||||||
| LED Module | Pixel Pitch | 4mm | ||||||
| Module Size | 320mmx160mm | |||||||
| Module Resolution | 80*40 dots | |||||||
| LED Cabinet | Cabinet Size | 640mm x 640mm | ||||||
| Cabinet Resolution | 160pixels *160pixels | |||||||
| Cabinets Material | Sealed Iron Cabinet | |||||||
| led screen | Pixel Density | 62500pixels/sq.m | ||||||
| Drive IC | MBI5124 | |||||||
| Power Supply | Series connection | |||||||
| Brightness | >2500cd/sqm | |||||||
| Display Color | 16.7million | |||||||
| Viewing Angle | 160°(Horizontal),110°(Vertical) | |||||||
| Best Viewing Distance | 4m~200m | |||||||
| Max Power Consumption | 600 w/sq.m | |||||||
| Weight | 22kgs/sq.m | |||||||
| Refresh Rate | 3000hz | |||||||
| Input Voltage | AC220V/50H or AC110V/60H | |||||||
| Output Voltage | DC5V,40A | |||||||
| Grey Scale Levels | 16bit | |||||||
| Display Colors | R(1024) x G(1024) x B(1024) | |||||||
| MTBF | 10,000 hours | |||||||
| Life-span | 100,000 hours | |||||||
| Drive Mode | 1/16 scaning | |||||||
| Working Humidity | 10%~99% | |||||||
| Control System | Control method | Synchronization & Asynchronization | ||||||
| Control System | (software) linsn | |||||||
| Software | LED Studio | |||||||
| PC Operating system | Microsoft Windows 7, 98, 2000, XP and Vista | |||||||
Free Training
Via internet, or in our workshop, we provide all the training including process of operation, installation, maintenance, system set up, etc.
Warranty
1,According to the contract, 2-3 years, from the beginning of installation to the completion of the display, we will be responsible for all quality issues.
2,After the completion of the project, we will continue to maintain the system for life and update the software.
3,For hardware equipment, we only charge component cost.
FAQ
Q1. What's the warranty of your LED Display Screen ?
A1. We have a 3-years warranty for our led display screen, and 100,000 hours life span of the led lamps.
Q2. What about your pre-sale service and post-sale service?
A2. For pre-sale service. We have a professional sales team and a 8 years technical team who are willing to answer your question 24/7.
We can offer a whole complete solution for your project!
For post-sale service. We can instruct you how to use, adjust the screens, and change the boken modules with spare parts.
Also, we can send technicals to your country to solve problems. Mostly, our led display will not have big problems within warranty time!
Q3. Whats your payment term? How long it takes to delivery?
A3. We accept T/T and L/C, For both T/T and L/C, At least 30% deposit in advance, and the rest 70% before delivery.Our average Production time is 10 days, after receiving the deposit.
Q4. What's the control system?
A4. For synchronization control. We use Nova, Linsn Or Colorlight control system.
Contact Person: Nora
Tel: +8617264502421
