Outdoor Full Color LED Display
Created with Pixso.

Rental Full Color NOVA System SMD P3.91 Wide Viewing Angle Outdoor Advertising Wall Screen

Rental Full Color NOVA System SMD P3.91 Wide Viewing Angle Outdoor Advertising Wall Screen

Brand Name: Shichuangxinke
Model Number: SCXK-P3.91
MOQ: negotiation
Price: negotiation
Payment Terms: L/C, T/T, Western Union
Supply Ability: 3000sqm per month
Detail Information
Place of Origin:
China ,Guang Dong
Certification:
CE RoHS FCC CCC TUV UL
Resolution/mm:
3.91
Pixel Configuration:
1R1G1B
Scanning Mode:
1/8 Scanning
Module Size:
250x250MM
Cabinet Size:
500x1000MM
Certificates:
CE RoHS FCC CCC UL
Application:
Stadium,airport,shopping Mall,street Advertising
Material:
Aluminum
Warranty:
3-5 Years
Packaging Details:
wooden box flight case, wooden case, carton, it is up to you.
Highlight:

P3.91 Outdoor Advertising Wall Screen

,

Outdoor Advertising Wall Screen

Product Description

SMD P3.91 advertising video wall outdoor screen with large viewing angle





Product Features:

This system is integrated with such powerful functions as graph making and displaying, art font making and displaying and three-dimensional animation displaying, the interface is beautiful.the operation is very convenient. After freely combined by customers, all the functions can be played on a continuous loop and switchover automatically.



Product Description:


CE,FCC,RoHS,C-Tick approved

High definition and refresh, seamless splice, good uniformity, HD video with vivid picture

Black body LEDs ensure high contrast ratio and high resolution

SMD LED encapsulation confirm wide view angle, above 120 degree for horizontal and vertical, without no strobe and color casting from different angle,good vision effect.

Light weight and slim thickness, easy to move and be portable.

Vivid and exact picture, minimum noise, advanced test equipment, support any PC operation system and play a variety of information like video,word, flash, music, clock, graph etc.



Specifications :



outdoor DIP P3.91
Resolution/mm 3.91
Pixel configuration 1R1G1B
Pixel density/pixels/m² 65410/m²
Module resolution 64x64
Module size/mm 250x250MM
View distance 14-300m
Single point brightness adjust Can be added
Single point color adjust Can be added
White balance brightness >7500cd/㎡
Color temperature 6500K-9500K
Horizontal view angle 120(degrees)
Vertical view angle 60(degrees)
Signal Process bit 10 or 16bit
Grey process 1024x1024x1024 16834x16834x16834 65536x65536x65536
Control distances Internet cable:100m, multimembrane:500m, monofilm:2km
Driving mode Constant driving current
Scanning mode 1/8 SCANNING
Frame rate 60Hz
Refresh frequency >3000Hz
Control mode Computer synchronous
Brightness adjusted range Manual, automatic operation, stepless continuous adjusted
255 steps. No grey loss
Out of control point <1/10000
Working hours ≥72hours
Mean Time Between Failure >5000hours
Life time 100000hours
Life-all-white(brightness halving) 50000hours
Environment temperature range Operating temperature range: -20-45℃
Self-check technology LED spot self-check, communications check, power check,
temperature monitor(need customization)
Remote monitoring Remote supervision and control, record potential fault,
send out warning signs to the operators.(need customization)
Software environment WindowsNT,Windows1999,WindowsXP
Luminous point width between centres Deviation<3%
Brightness uniformity <10%
Color uniformity(chromaticity coordinate) ±0.003
Power supply request AC85-264V(50Hz-60Hz)
Contrast (1000:1)
System protection Moistureproof,dustproof,high temperature protection,anti-corrosion,anti-burning,anti-static,anti-vibration
Humidity(working) working:10-95%
Humidity(storing) storing:10-95%



Applications:


Concert rental LED display

Entertainment events LED screen

Stadium rental LED wall

Fash show stage LED display

Car exhibition LED display

Rental commercial LED display



Rental Full Color NOVA System SMD P3.91 Wide Viewing Angle Outdoor Advertising Wall Screen 0

Rental Full Color NOVA System SMD P3.91 Wide Viewing Angle Outdoor Advertising Wall Screen 1

Rental Full Color NOVA System SMD P3.91 Wide Viewing Angle Outdoor Advertising Wall Screen 2Rental Full Color NOVA System SMD P3.91 Wide Viewing Angle Outdoor Advertising Wall Screen 3Rental Full Color NOVA System SMD P3.91 Wide Viewing Angle Outdoor Advertising Wall Screen 4Rental Full Color NOVA System SMD P3.91 Wide Viewing Angle Outdoor Advertising Wall Screen 5

Rental Full Color NOVA System SMD P3.91 Wide Viewing Angle Outdoor Advertising Wall Screen 6

FAQ



1.Q:Are you a factory or trading company?

A:We are a factory,located in Dalang,Longhua District .



2.Q:What kind of payment terms you accept?

A:We accept T/T,Western Union,MoneyGram etc.



3.Q:What's packaging?

A:1.Flight case packaging

2.Wooden case packaging

3.36pcs in one case packaging

4.Customized packaging



4.Q:Does you have CE/ROHS certificates?

A:Yes, we offer the CE & ROHS certificates .



5.Q:What's the shipping method,shipping time?

A:Our products could be shipped by Sea, by Air, and by Express.

by sea:20-40days; by air:5-10days ;by express:3-6days
