Shenzhen Shichuangxinke Electronics Co.,Ltd
professional makes good quality, provide perfect product and service for every customer.

|
| Place of Origin: | China ,Guang Dong |
| Brand Name: | Shichuangxinke |
| Certification: | CE RoHS FCC CCC TUV UL |
| Model Number: | SCXK-P3.91 |
| Minimum Order Quantity: | 1 square meters |
|---|---|
| Price: | USD 1800-2700 per square meters |
| Packaging Details: | wooden box flight case, wooden case, carton, it is up to you. |
| Delivery Time: | 7-10 working days after deposit payment received |
| Payment Terms: | L/C, T/T, Western Union |
| Supply Ability: | 5000sqm per month |
| Resolution/mm: | 3.91 | Pixel Configuration: | 1R1G1B |
|---|---|---|---|
| Scanning Mode: | 1/8 Scanning | Module Size: | 250x250MM |
| Cabinet Size: | 500x1000MM | Certificates: | CE RoHS FCC CCC UL |
| Application: | Stadium,airport,shopping Mall,street Advertising | Material: | Aluminum |
| Warranty: | 3-5 Years | ||
| Highlight: | Fixed Screen Aluminum Screen,1000mm Aluminum Screen,Street Billboard Aluminum Screen |
||
Meanwell/g-energy LED driver street advertisement billboard aluminum cabinet 1000mm
We are a professional LED display screen manufacturer and supplier in China. Our primary products include indoor LED display screen, outdoor LED display screen, indoor rental LED screen, stadium LED display screen, LED curtain, LED ceiling light, and LED panel light.
P4 LED Display Screen P5 LED Display Screen P6 LED Display Screen P7 LED Display Screen P8 LED Display Screen P10 LED Display Screen
Other Products:
Indoor Rental LED Screen Vivid colors. The whole screen achieves high consistency in color and brightness. With high contrast ratio and high refresh rate, the image is well represented by the LED screen without any delay phenomenon.
Rental LED Screen Traditional motorized screens, such as CRT TV walls, rear projection TV walls, front projection screens, plasma display panels (PDP), etc., have limited applications due to insufficient brightness, size limitations and installation difficulties.
For outdoor stadium video screens, we use visual pixel technology to achieve better vivid video display performance. For indoor sports video screens, we utilize SMD 3 in 1 technology, which offers wider viewing angles, higher refresh rates and higher brightness.
The LED drapery mechanics are designed to enable the efficient installation and removal required for rental and staging applications. The most important feature of this product is its transparency, which can be changed to bring different visual effects to the audience by changing the brightness.
Specifications :
| outdoor DIP P3.91 | |||||
| Resolution/mm | 3.91 | ||||
| Pixel configuration | 1R1G1B | ||||
| Pixel density/pixels/m² | 65410/m² | ||||
| Module resolution | 64x64 | ||||
| Module size/mm | 250x250MM | ||||
| View distance | 14-300m | ||||
| Single point brightness adjust | Can be added | ||||
| Single point color adjust | Can be added | ||||
| White balance brightness | >7500cd/㎡ | ||||
| Color temperature | 6500K-9500K | ||||
| Horizontal view angle | 120(degrees) | ||||
| Vertical view angle | 60(degrees) | ||||
| Signal Process bit | 10 or 16bit | ||||
| Grey process | 1024x1024x1024 16834x16834x16834 65536x65536x65536 | ||||
| Control distances | Internet cable:100m, multimembrane:500m, monofilm:2km | ||||
| Driving mode | Constant driving current | ||||
| Scanning mode | 1/8 SCANNING | ||||
| Frame rate | 60Hz | ||||
| Refresh frequency | >3000Hz | ||||
| Control mode | Computer synchronous | ||||
| Brightness adjusted range | Manual, automatic operation, stepless continuous adjusted | ||||
| 255 steps. No grey loss | |||||
| Out of control point | <1/10000 | ||||
| Working hours | ≥72hours | ||||
| Mean Time Between Failure | >5000hours | ||||
| Life time | 100000hours | ||||
| Life-all-white(brightness halving) | 50000hours | ||||
| Environment temperature range | Operating temperature range: -20-45℃ | ||||
| Self-check technology | LED spot self-check, communications check, power check, | ||||
| temperature monitor(need customization) | |||||
| Remote monitoring | Remote supervision and control, record potential fault, | ||||
| send out warning signs to the operators.(need customization) | |||||
| Software environment | WindowsNT,Windows1999,WindowsXP | ||||
| Luminous point width between centres | Deviation<3% | ||||
| Brightness uniformity | <10% | ||||
| Color uniformity(chromaticity coordinate) | ±0.003 | ||||
| Power supply request | AC85-264V(50Hz-60Hz) | ||||
| Contrast | (1000:1) | ||||
| System protection | Moistureproof,dustproof,high temperature protection,anti-corrosion,anti-burning,anti-static,anti-vibration | ||||
| Humidity(working) | working:10-95% | ||||
| Humidity(storing) | storing:10-95% | ||||
Competitive advantages:
1. Stable quality: Professionally supplied LED screen to over 80 countries and installed thousands projects in 10 years;
2. P3.91 outdoor LED billboards is of high resolution for fixed installation outdoor LED screens;
3. High quality image and video presentation for large size LED billboards advertising use;
4. High brightness to deliver a clear image and video even under direct sunshine;
5. Brightness automatic adjustment for day and night use;
6. Communication distance support less than 100 meters by Lan, under 500 meters by multi mode fiber optic and lower than 20km by single mode fiber optic
FAQ
1.Q:Are you a factory or trading company?
A:We are a factory,located in Dalang,Longhua District .
2.Q:What kind of payment terms you accept?
A:We accept T/T,Western Union,MoneyGram etc.
3.Q:What's packaging?
A:1.Flight case packaging
2.Wooden case packaging
3.36pcs in one case packaging
4.Customized packaging
4.Q:Does you have CE/ROHS certificates?
A:Yes, we offer the CE & ROHS certificates .
5.Q:What's the shipping method,shipping time?
A:Our products could be shipped by Sea, by Air, and by Express.
by sea:20-40days; by air:5-10days ;by express:3-6days
