Shenzhen Shichuangxinke Electronics Co.,Ltd
professional makes good quality, provide perfect product and service for every customer.
 |
| Place of Origin: | China ,Guang Dong |
| Brand Name: | Shichuangxinke |
| Certification: | CE RoHS FCC CCC TUV UL |
| Model Number: | SCXK-P6.67 |
| Minimum Order Quantity: | negotiation |
|---|---|
| Price: | negotiation |
| Packaging Details: | wooden box flight case, wooden case, carton, it is up to you. |
| Delivery Time: | 7-10 working days after deposit payment received |
| Payment Terms: | L/C, T/T, Western Union, D/A, D/P, MoneyGram |
| Supply Ability: | 5000sqm per month |
| Pixel Pitch: | P 6.67mm | Pixel Configuration: | Red Green Blue |
|---|---|---|---|
| Scanning Mode: | 1/8 | Module Size: | 320x160mm |
| Application: | Show-business, Concerts, Festivals, Motor Shows And Other Public Events | Driver IC: | MB5024/MB5124 |
| Material: | Aluminum | Cabinet Size: | 640x640mm |
| Highlight: | Ultra HD Full Color LED Display,Outdoor Full Color LED Display,P6.67 Full Color LED Display |
||
Die-cast P6.67 led board display smd outdoor led display screen
Features
1. LED brightness is high and adjustable, which can meet the changing needs of customers in different environments.
2. good flatness, high luminous uniformity, display without mosaic
3. wide viewing angle, horizontal viewing angle of up to 120 °, in this range of image display effect does not change.
4. outdoor display can use virtual pixel display, the resolution can be up to 4 times of the real pixel, so that the image is softer and more lifelike
5. LED single lamp low maintenance cost
6. Unique exhaust fan design, good heat dissipation performance
7. Environmental protection and energy saving.
Specifications :
| outdoor SMD P6.67 | |||||
| Resolution/mm | 6.67 | ||||
| Pixel configuration | 1R1G1B | ||||
| Pixel density/pixels/m² | 22478/m² | ||||
| Module resolution | 48x24 | ||||
| Module size/mm | 320x160mm | ||||
| View distance | 14-300m | ||||
| Single point brightness adjust | Can be added | ||||
| Single point color adjust | Can be added | ||||
| White balance brightness | >7500cd/㎡ | ||||
| Color temperature | 6500K-9500K | ||||
| Horizontal view angle | 120(degrees) | ||||
| Vertical view angle | 60(degrees) | ||||
| Signal Process bit | 10 or 16bit | ||||
| Grey process | 1024x1024x1024 16834x16834x16834 65536x65536x65536 | ||||
| Control distances | Internet cable:100m, multimembrane:500m, monofilm:2km | ||||
| Driving mode | Constant driving current | ||||
| Scanning mode | 1/4SCANNING | ||||
| Frame rate | 60Hz | ||||
| Refresh frequency | >3000Hz | ||||
| Control mode | Computer synchronous | ||||
| Brightness adjusted range | Manual, automatic operation, stepless continuous adjusted | ||||
| 255 steps. No grey loss | |||||
| Out of control point | <1/10000 | ||||
| Working hours | ≥72hours | ||||
| Mean Time Between Failure | >5000hours | ||||
| Life time | 100000hours | ||||
| Life-all-white(brightness halving) | 50000hours | ||||
| Environment temperature range | Operating temperature range: -20-45℃ | ||||
| Self-check technology | LED spot self-check, communications check, power check, | ||||
| temperature monitor(need customization) | |||||
| Remote monitoring | Remote supervision and control, record potential fault, | ||||
| send out warning signs to the operators.(need customization) | |||||
| Software environment | WindowsNT,Windows1999,WindowsXP | ||||
| Luminous point width between centres | Deviation<3% | ||||
| Brightness uniformity | <10% | ||||
| Color uniformity(chromaticity coordinate) | ±0.003 | ||||
| Power supply request | AC85-264V(50Hz-60Hz) | ||||
| Contrast | (1000:1) | ||||
| System protection | Moistureproof,dustproof,high temperature protection,anti-corrosion,anti-burning,anti-static,anti-vibration | ||||
| Humidity(working) | working:10-95% | ||||
| Humidity(storing) | storing:10-95% | ||||
Service:
1--.We will response within 24 hours when receive your inquiry.
2--.Led screen products have 2years warranty.
3--.Any install and aftersales problem, will have professional technology engineer help to guid and solve.
4--. Our products are pushing to all over the world, mainly in Russian, Iran, American, Turkey, Australia,Brazil, indonesia, Germany and so on.
5--.We want to developing distributors and agents from all over the world, and it will have advantages and profits to be our agents. we will help and grow with distributors and agents.
