Shenzhen Shichuangxinke Electronics Co.,Ltd
professional makes good quality, provide perfect product and service for every customer.
 |
| Place of Origin: | China ,Guang Dong |
| Brand Name: | Shichuangxinke |
| Certification: | CE RoHS FCC CCC TUV UL |
| Model Number: | SCXK-P12 |
| Minimum Order Quantity: | negotiation |
|---|---|
| Price: | negotiation |
| Packaging Details: | wooden box flight case, wooden case, carton, it is up to you. |
| Delivery Time: | 7-10 working days after deposit payment received |
| Payment Terms: | L/C, T/T, Western Union, D/A, D/P, MoneyGram |
| Supply Ability: | 5000sqm per month |
| Resolution/mm: | 12 | Pixel Configuration: | 1R1G1B |
|---|---|---|---|
| Scanning Mode: | 1/4 Scanning | Module Size: | 192x192mm |
| Cabinet Size: | 960x768mm | Certificates: | CE RoHS FCC CCC UL |
| Application: | Stadium,airport,shopping Mall,street Advertising | Material: | Aluminum |
| Warranty: | 3-5 Years | ||
| Highlight: | Concert Outdoor Full Color LED Display,Waterproof Outdoor Full Color LED Display,IP65 Outdoor Full Color LED Display |
||
Commercial Advertising Outdoor Full Color LED Display , High Brightness Concert LED Screen IP65
Detailed description:
1. High brightness, brightness can be customized and adjusted according to customer requirements.
2. Wide visibility, good visual effect.
3. Can connect most devices for live broadcast.
4. Can input most signals, such as HDTV, CATV, NTSC, PAL S-video, VGA, VCD, DVD, MP3, MP4, etc.
5. Die-cast aluminum material, light weight (13.5KGS/cabinet), small size (640mm*640mm/cabinet).
6. Save control system cost and packaging cost, freight.
7. Can be quickly built and connected through aviation connectors and quick locks.
8. Packed in an air box for easy transportation.
P5 P6 P7.62 Indoor LED Display Screen Rental
FOB Price: US$500 - 1,000/m2 Get the latest price
Minimum order quantity: 5 sqm/m2
Supply capacity: 5000 sqm/m2 per month
Port: Shenzhen
Payment terms: T/T
LED display products:
Outdoor Fix Installation LED Display :P6,P8,P10(DIP),P10(SMD),P12,P16,P20,P25
Indoor Fix Installation LED Display :P1.2 P1.8,P2.5,P3,P4,P5,P6,P7.62,P8,P10
Outdoor Rental LED Display :P6,P6.94,P8,P8.9,P10
Indoor Rental LED Display :P2.5,P3,P4,P5,P6,P7.62
Perimeter LED Display :P12,P16
Freeform & creative display
Applications
Commercial advertising, Stadium perimeter, mobile media, night club, entertainment events, business establishments, such as banks, stock exchange centers, bus station, schools, telecommunications, customs, stadiums, studio, shopping malls, railways, airports, harbors, etc;
Specifications :
| outdoor DIP P12 | |||||
| Resolution/mm | 12 | ||||
| Pixel configuration | 1R1G1B | ||||
| Pixel density/pixels/m² | 6944/m² | ||||
| Module resolution | 16x16 | ||||
| Module size/mm | 192x192MM | ||||
| View distance | 14-300m | ||||
| Single point brightness adjust | Can be added | ||||
| Single point color adjust | Can be added | ||||
| White balance brightness | >7500cd/㎡ | ||||
| Color temperature | 6500K-9500K | ||||
| Horizontal view angle | 120(degrees) | ||||
| Vertical view angle | 60(degrees) | ||||
| Signal Process bit | 10 or 16bit | ||||
| Grey process | 1024x1024x1024 16834x16834x16834 65536x65536x65536 | ||||
| Control distances | Internet cable:100m, multimembrane:500m, monofilm:2km | ||||
| Driving mode | Constant driving current | ||||
| Scanning mode | 1/4 SCANNING | ||||
| Frame rate | 60Hz | ||||
| Refresh frequency | >3000Hz | ||||
| Control mode | Computer synchronous | ||||
| Brightness adjusted range | Manual, automatic operation, stepless continuous adjusted | ||||
| 255 steps. No grey loss | |||||
| Out of control point | <1/10000 | ||||
| Working hours | ≥72hours | ||||
| Mean Time Between Failure | >5000hours | ||||
| Life time | 100000hours | ||||
| Life-all-white(brightness halving) | 50000hours | ||||
| Environment temperature range | Operating temperature range: -20-45℃ | ||||
| Self-check technology | LED spot self-check, communications check, power check, | ||||
| temperature monitor(need customization) | |||||
| Remote monitoring | Remote supervision and control, record potential fault, | ||||
| send out warning signs to the operators.(need customization) | |||||
| Software environment | WindowsNT,Windows1999,WindowsXP | ||||
| Luminous point width between centres | Deviation<3% | ||||
| Brightness uniformity | <10% | ||||
| Color uniformity(chromaticity coordinate) | ±0.003 | ||||
| Power supply request | AC85-264V(50Hz-60Hz) | ||||
| Contrast | (1000:1) | ||||
| System protection | Moistureproof,dustproof,high temperature protection,anti-corrosion,anti-burning,anti-static,anti-vibration | ||||
| Humidity(working) | working:10-95% | ||||
| Humidity(storing) | storing:10-95% | ||||
Main Export Markets:
a)Asia
b)Australasia
c)Central/South America
d)Eastern Europe
e)Mid East/Africa
f)North America
g)Western Europe
Contact Person: Lillian seori
Tel: +8619386814677
