Die-cast Aluminum Screen Fixed Installation/Rental Customizable P16 Outdoor Waterproof LED Screen

Die-cast Aluminum Screen Fixed Installation/Rental Customizable P16 Outdoor Waterproof LED Screen

Die-cast Aluminum Screen Fixed Installation/Rental Customizable P16 Outdoor Waterproof LED Screen
Die-cast Aluminum Screen Fixed Installation/Rental Customizable P16 Outdoor Waterproof LED Screen
Die-cast Aluminum Screen Fixed Installation/Rental Customizable P16 Outdoor Waterproof LED Screen
Product Details:
Place of Origin: China ,Guang Dong
Brand Name: Shichuangxinke
Certification: CE RoHS FCC CCC TUV UL
Model Number: SCXK-P16
Payment & Shipping Terms:
Minimum Order Quantity: negotiation
Price: negotiation
Packaging Details: wooden box flight case, wooden case, carton, it is up to you.
Delivery Time: 7-10 working days after deposit payment received
Payment Terms: L/C, T/T, Western Union, D/A, D/P
Supply Ability: 5000sqm per month
Contact Now
Detailed Product Description
Resolution/mm: 16 Pixel Configuration: 1R1G1B
Scanning Mode: Static Full Color Module Size: 256x256mm
Cabinet Size: 1024x1024mm Certificates: CE RoHS FCC CCC UL
Application: Stadium,airport,shopping Mall,street Advertising Material: Aluminum
Warranty: 3-5 Years
Highlight:

Outdoor Waterproof LED Screen

,

Customizable P16 LED Screen

,

Rental P16 LED Screen

P16 Ultra Thin Led Display Outdoor With G Energy Power Supply And Meanwell Driver


Customer Service
1) Warranty Period: One year after shipment from the factory
2) Warranty coverage: LED modules, power supplies, control systems and other accessories (this warranty does not cover accessories purchased from other manufacturers)
3) Repair Method:
Repair, express delivery, etc.
4) Repair response time:
Repair method: Upon receipt of the returned product, the repair will be completed and returned to the user within 24 hours;
Telephone or Internet: contact the user within 2 hours after receiving the information, and provide a solution within 8 hours;
On-site mode: (domestic users only) after receiving the repair information, users in Guangdong Province will give a reply within 48 hours, and users outside Guangdong Province will give a reply within 72 hours. Under special circumstances, the two sides will solve the problem by friendly negotiation.


Specifications:

outdoor DIP 16 LED Display
Resolution/mm 16mm
Pixel configuration 1R1G1B
Pixel density/pixels/m² 3906/sqm
Module resolution 16x16
Module size/mm 256x256m
View distance 14-300m
Single point brightness adjust Can be added
Single point color adjust Can be added
White balance brightness >7500cd/㎡
Color temperature 6500K-9500K
Horizontal view angle 120(degrees)
Vertical view angle 60(degrees)
Signal Process bit 10 or 16bit
Grey process 1024x1024x1024 16834x16834x16834 65536x65536x65536
Control distances Internet cable:100m, multimembrane:500m, monofilm:2km
Driving mode Constant driving current
Scanning mode static full color
Frame rate 60Hz
Refresh frequency >3000Hz
Control mode Computer synchronous
Brightness adjusted range Manual, automatic operation, stepless continuous adjusted
255 steps. No grey loss
Out of control point <1/10000
Working hours ≥72hours
Mean Time Between Failure >5000hours
Life time 100000hours
Life-all-white(brightness halving) 50000hours
Environment temperature range Operating temperature range: -20-45℃
Self-check technology LED spot self-check, communications check, power check,
temperature monitor(need customization)
Remote monitoring Remote supervision and control, record potential fault,
send out warning signs to the operators.(need customization)
Software environment WindowsNT,Windows1999,WindowsXP
Luminous point width between centres Deviation<3%
Brightness uniformity <10%
Color uniformity(chromaticity coordinate) ±0.003
Power supply request AC85-264V(50Hz-60Hz)
Contrast (1000:1)
System protection Moistureproof,dustproof,high temperature protection,anti-corrosion,anti-burning,anti-static,anti-vibration
Humidity(working) working:10-95%
Humidity(storing) storing:10-95%




Upgrade Service :
Unschedule,we will upgrade our system of products without extra formal; we'll do our best to help users with upgrading ; the following conditions are excluded by this warranty :

  1. Without approved documents;
  2. Series code on products having been torn or changed ;
  3. Damage caused by lighting strike or electrical problems;
  4. Risks caused by irresistible incidents includes all kinds of natural disasters, fire, wars, policy changes, and some other human error accidents.
  5. Users or third party refit or repaired by themselves without SCX permission ;
  6. Water intrusion or corrosion caused by improper keeping or operating ;
  7. Over period of free maintenance .



Die-cast Aluminum Screen Fixed Installation/Rental Customizable P16 Outdoor Waterproof LED Screen 0
Die-cast Aluminum Screen Fixed Installation/Rental Customizable P16 Outdoor Waterproof LED Screen 1Die-cast Aluminum Screen Fixed Installation/Rental Customizable P16 Outdoor Waterproof LED Screen 2Die-cast Aluminum Screen Fixed Installation/Rental Customizable P16 Outdoor Waterproof LED Screen 3

Die-cast Aluminum Screen Fixed Installation/Rental Customizable P16 Outdoor Waterproof LED Screen 4

Die-cast Aluminum Screen Fixed Installation/Rental Customizable P16 Outdoor Waterproof LED Screen 5Die-cast Aluminum Screen Fixed Installation/Rental Customizable P16 Outdoor Waterproof LED Screen 6


FAQ



Q1: How to help client choose suitable display?

A1:

(1)specific application scenario
(2)viewing distance requirement
(3)display brightness requirement
(4)specific installation environment
(5)budget and cost control



Q2: What about your technical support?

A2: Proffessional engineers are on standby, can offer guidance, on site technical support as required.



Q3: What's the control system?

A3: For synchronization control: Nova, Linsn or Mooncell control system.
For asynchronous control: Onbon or Xixun control system.



Q4: What's the warranty of your LED displays?

A4: We provide 2 years warranty and conditioned lifetime technical support for our LED display products.



Q5: What's your payment method?

A5: Our payment method is T/T 30% as deposit, balancing before delivery.
