Shenzhen Shichuangxinke Electronics Co.,Ltd
professional makes good quality, provide perfect product and service for every customer.
 |
| Place of Origin: | China(Mainland) |
| Brand Name: | SCX |
| Certification: | CE,ISO,FCC,UL |
| Model Number: | SCX-P4.81 |
| Minimum Order Quantity: | negotiation |
|---|---|
| Price: | negotiation |
| Packaging Details: | Wooden and flight cases,it's up to you. |
| Delivery Time: | 12-15 working days after receiving the down payment. |
| Payment Terms: | T/T, Western Union, D/P, D/A |
| Supply Ability: | 5000 sqms/month |
| Brand Name: | SCX | Color: | Full Color |
|---|---|---|---|
| Module Size: | 250*250mm | Waterproof: | IP65 |
| Pixel Density: | 43222dots/sqm | Brightness: | ≥7500cd/sq |
| Indoor Options: | P1.667,P2,P2.5,P3,P3.91,P4,P4.81,P5,P6,P10 | Certifications: | CE,FCC,ISO,UL |
| Highlight: | Outdoor Full Color LED Display,IP65 Outdoor Full Color LED Display,500*1000MM Outdoor Full Color LED Display |
||
High quality Outdoor Full Color LED Display P4.81 IP65 Module250*250mm HD
1.Our service
1) Your inquiry about products or prices will be responded within 24 hours.
2) OEM and ODM, any customized lamps you want, we can help you design and put into production.
3) Provide dealership rights for your unique design and some of our current models.
4) Protect your sales area, design ideas and all private information.
5) Top quality + reasonable price + responsible after-sales service = success and victory.
6) Trade Assurance (provided by Alibaba and Gteak to ensure the quality safety and security of your payment, shipment, goods.
2.Specifications of product:
| Outdoor Full Color LED Display P4.81 | |||||
| Resolution/mm | 4.81 | ||||
| Pixel configuration | 1R1G1B | ||||
| Pixel density/pixels/m² | 43222/square meter | ||||
| Module resolution | 52x52mm | ||||
| Module size/mm | 250x250mm | ||||
| View distance | 5-300m | ||||
| Single point brightness adjust | Can be added | ||||
| Single point color adjust | Can be added | ||||
| White balance brightness | >7500cd/square meter | ||||
| Color temperature | 6500K-9500K | ||||
| Horizontal view angle | 120(degrees) | ||||
| Vertical view angle | 60(degrees) | ||||
| Signal Process bit | 10 or 16bit | ||||
| Grey process | 1024x1024x1024 16834x16834x16834 65536x65536x65536 | ||||
| Control distances | Internet cable:100m, multimembrane:500m, monofilm:2km | ||||
| Driving mode | alternating driving current | ||||
| Scanning mode | 1/13 SCANNING | ||||
| Frame rate | 60Hz | ||||
| Refresh frequency | >3000Hz | ||||
| Control mode |
Asynchronous,3G,4G,Wifi |
||||
| Brightness adjusted range | Manual, automatic operation, stepless continuous adjusted | ||||
| 255 steps. No grey loss | |||||
| Out of control point | <1/10000 | ||||
| Aging hours | ≥72hours | ||||
| Mean Time Between Failure | >5000hours | ||||
| Life time | 100000hours | ||||
| Life-all-white(brightness halving) | 50000hours | ||||
| Environment temperature range | Operating temperature range: -20-45℃ | ||||
| Self-check technology | LED spot self-check, communications check, power check, | ||||
| temperature monitor(need customization) | |||||
| Remote monitoring | Remote supervision and control, record potential fault, | ||||
| send out warning signs to the operators.(need customization) | |||||
| Software environment | WindowsNT,Windows1999,WindowsXP | ||||
| Luminous point width between centres | Deviation<3% | ||||
| Brightness uniformity | <10% | ||||
| Color uniformity(chromaticity coordinate) | ±0.003 | ||||
| Power supply request | AC85-264V(50Hz-60Hz) | ||||
| Contrast | (1000:1) | ||||
| System protection | Moistureproof,dustproof,high temperature protection,anti-corrosion,anti-burning,anti-static,anti-vibration | ||||
| Humidity(working) | working:10-95% | ||||
| Humidity(storing) | storing:10-95% | ||||
3.Our advantages:
1)Diversified products :
Varieties of models for outdoor/indoor LED display screens,and customized cabinets available,meet all requirements and win more profits for customers.
2) Experienced&Professional:
10 years manufacturing experience on LED displays, professional workmanship & design.
Taiwan Epistar LED chip,high quality,high brightness and long life span.
3) Best raw materials:
4) Competitive price:
100% factory price,competitive and reasonable price.
FAQ
Q1.Can I have a sample order for the LED display?
A:Yes,we welcome sample orders to test and check quality.Both for the module or the whole screen.
Q2.What about the lead time?
A:Order less than 100 square meters lead time to take 15 working days
Q3.Do you have any MOQ limit for LED display orders?
A:Low MOQ,1 square meter or a module checking is available
Q4.How do you ship the goods and how long does it take to arrive?
A:We mostly accept EXW FOB CIF DDP and other shipping ways.It usually takes 20~30 days on the sea.a few days for customs clearance
Q5.How to proceed with an order for an LED display?
A:Firstly let us know your requirements or application.
Secondly,We quote according to your requirements or our suggestions.
Thirdly customer confirms the design document and places a deposit for the formal order.
Fourthly We arrange the production.
Q6.Is it OK to print my logo on the products?
A:Yes.Please inform us formally before our production and confirm the design firstly based on our sample.
Q7:Do you offer a guarantee for the products?
A:Yes,we offer 1-5 years warranty for our products.
