Curve Screen 7500cd/M2 Brightness HD Outdoor Full Color LED Display P10 DIP IP 65 Fixed Installation

Curve Screen 7500cd/M2 Brightness HD Outdoor Full Color LED Display P10 DIP IP 65 Fixed Installation

  • Curve Screen 7500cd/M2 Brightness HD Outdoor Full Color LED Display P10 DIP IP 65 Fixed Installation
  • Curve Screen 7500cd/M2 Brightness HD Outdoor Full Color LED Display P10 DIP IP 65 Fixed Installation
  • Curve Screen 7500cd/M2 Brightness HD Outdoor Full Color LED Display P10 DIP IP 65 Fixed Installation
  • Curve Screen 7500cd/M2 Brightness HD Outdoor Full Color LED Display P10 DIP IP 65 Fixed Installation
Curve Screen 7500cd/M2 Brightness HD Outdoor Full Color LED Display P10 DIP IP 65 Fixed Installation
Product Details:
Place of Origin: China(Mainland)
Brand Name: SCXK
Certification: ISO,FCC,CE,UL
Model Number: SCXK-P10
Payment & Shipping Terms:
Minimum Order Quantity: 5 sqms
Price: negotiation
Packaging Details: Wooden and flight cases,it's up to you.
Delivery Time: 12-15 working days after receiving your down payment.
Payment Terms: T/T, Western Union, D/A, D/P, MoneyGram
Supply Ability: 5000sqms/month
Contact Now
Detailed Product Description
Picth: 10MM Color: Full Color
Module Size: 320*160MM Cabinet Size: 960*960MM
Waterproof: IP65 Application Place: Outdoor
Resolution: 16*16 Brightness: 7500cd/sqm
Highlight:

HD Outdoor Full Color LED Display

,

P10 Outdoor Full Color LED Display

HD Outdoor Full Color LED Display P10 DIP for Fixed Installation IP 65

Product description:
1) Reliable quality, advanced and mature technology, in line with industry standards and technological development trends.
2) Good heat dissipation, good waterproof performance, and stable performance.
3) The system has audio and video interfaces, which can provide vivid, complete, and high-quality LED display screens for TV broadcast signals.
4) The screen image has high resolution, high definition, clear pictures, and no flicker.
5) Supports video and RF input, and the special structure can be freely assembled.
Curve Screen 7500cd/M2 Brightness HD Outdoor Full Color LED Display P10 DIP IP 65 Fixed Installation 0
Curve Screen 7500cd/M2 Brightness HD Outdoor Full Color LED Display P10 DIP IP 65 Fixed Installation 1
Curve Screen 7500cd/M2 Brightness HD Outdoor Full Color LED Display P10 DIP IP 65 Fixed Installation 2
Curve Screen 7500cd/M2 Brightness HD Outdoor Full Color LED Display P10 DIP IP 65 Fixed Installation 3
Curve Screen 7500cd/M2 Brightness HD Outdoor Full Color LED Display P10 DIP IP 65 Fixed Installation 4
Curve Screen 7500cd/M2 Brightness HD Outdoor Full Color LED Display P10 DIP IP 65 Fixed Installation 5Curve Screen 7500cd/M2 Brightness HD Outdoor Full Color LED Display P10 DIP IP 65 Fixed Installation 6
Specification :

outdoor P10 DIP LED screen Display
Resolution/mm 10
Pixel configuration 1R1G1B
Pixel density/pixels/m² 10000/square meter
Module resolution 16*16mm
Module size/mm 320*160mm
View distance 10-150m
Single point brightness adjust Can be added
Single point color adjust Can be added
White balance brightness >7500cd/square meter
Color temperature 6500K-9500K
Horizontal view angle 120(degrees)
Vertical view angle 120(degrees)
Signal Process bit 10 or 16bit
Grey process 1024x1024x1024 16834x16834x16834 65536x65536x65536
Control distances Internet cable:100m, multimembrane:500m, monofilm:2km
Driving mode Constant driving current
Scanning mode static full color SCANNING
Fresh rate 60Hz
Refresh frequency >3000Hz
Control mode Computer synchronous
Brightness adjusted range Manual, automatic operation, stepless continuous adjusted
255 steps. No grey loss
Out of control point <1/10000
Working hours ≥72hours
Mean Time Between Failure >5000hours
Life time 100000hours
Life-all-white(brightness halving) 50000hours
Environment temperature range Operating temperature range: -20-45℃
Self-check technology LED spot self-check, communications check, power check,
temperature monitor(need customization)
Remote monitoring Remote supervision and control, record potential fault,
send out warning signs to the operators.(need customization)
Software environment WindowsNT,Windows1999,WindowsXP
Luminous point width between centres Deviation<3%
Brightness uniformity <10%
Waterproof IP65
Color uniformity(chromaticity coordinate) ±0.003
Power supply request AC85-264V(50Hz-60Hz)
Contrast (1000:1)
System protection Moistureproof,dustproof,high temperature protection,anti-corrosion,anti-burning,anti-static,anti-vibration
Humidity(working) working:10-95%
Humidity(storing)

storing:10-95%


Spare parts warranty period Configuration Guidelines:

(1)Adequacy: With the specific equipment, spare parts allocation adequate, ensure replacement in the first time of equipment failure;
(2)Necessity: On the basis of previous maintenance experience, we configure the spare parts are the key parts of the equipment, so as to ensure the economic allocation;
(3)Economic practicality: In order to deal with the fault in the shortest time, we configure the spare parts are complete module or unit, through our training, the owners can easily replace the spare parts, so as to ensure the normal operation of the system.

FAQ

Q1: Can you provide OEM or ODM service?
Yes, our company specializes in OEM and ODM services with excellent R&D team, perfect quality and lighting solutions, just tell us what you think.

Q2: What kind of packaging is usually used for this product?
Usually we provide air box packaging (wooden box and flight case are available)

Q3: Can I print my logo on the lamps?
A: Yes, we can print your logo on the lamps for free.

Q 4: Do you offer a warranty on your products?
A: We offer a three-year warranty. The defective rate of our products is less than 0.2%.

Q 5: How long does it take to produce after an order is placed?
A: It depends on the quantity of the order. Most online wholesale orders are shipped within 3-5 days after payment is received.

Q 6: What payment methods do you accept for full orders?
We offer a variety of payment methods including PayPal, Visa, MasterCard, Alibaba Trade Assurance, Western Union, and Wire Transfer (T/T).
