Shenzhen Shichuangxinke Electronics Co.,Ltd
professional makes good quality, provide perfect product and service for every customer.
 |
| Place of Origin: | China ,Guang Dong |
| Brand Name: | Shichuangxinke |
| Certification: | CE RoHS FCC CCC TUV UL |
| Model Number: | SCXK-P6 |
| Minimum Order Quantity: | 1 square meters |
|---|---|
| Price: | USD400-1600per square meters |
| Packaging Details: | wooden box flight case, wooden case, carton, it is up to you. |
| Delivery Time: | 7-10 working days after deposit payment received |
| Payment Terms: | L/C, T/T, Western Union |
| Supply Ability: | 5000sqm per month |
| Resolution/mm: | 6 | Pixel Configuration: | 1R1G1B |
|---|---|---|---|
| Scanning Mode: | 1/8 Scanning | Module Size: | 192x192 |
| Cabinet Size: | 960x768mm/576x576mm | Certificates: | CE RoHS FCC CCC UL |
| Application: | Stadium,airport,shopping Mall,street Advertising,stage Background | Material: | Aluminum |
| Warranty: | 3-5 Years | ||
| Highlight: | Weddings LED Display Screen,Meetings LED Display Screen,Fixed Installation LED Display Screen |
||
Interior Broadcast Live Show Multi Color P6 LED display For Stage Concert Wedding Meeting
Specifications :
| outdoor SMD P6 | |||||
| Resolution/mm | 6 | ||||
| Pixel configuration | 1R1G1B | ||||
| Pixel density/pixels/m² | 43222/m² | ||||
| Module resolution | 27778 | ||||
| Module size/mm | 192x192mm | ||||
| View distance | 14-300m | ||||
| Single point brightness adjust | Can be added | ||||
| Single point color adjust | Can be added | ||||
| White balance brightness | >7500cd/㎡ | ||||
| Color temperature | 6500K-9500K | ||||
| Horizontal view angle | 120(degrees) | ||||
| Vertical view angle | 60(degrees) | ||||
| Signal Process bit | 10 or 16bit | ||||
| Grey process | 1024x1024x1024 16834x16834x16834 65536x65536x65536 | ||||
| Control distances | Internet cable:100m, multimembrane:500m, monofilm:2km | ||||
| Driving mode | Constant driving current | ||||
| Scanning mode | 1/13 SCANNING | ||||
| Frame rate | 60Hz | ||||
| Refresh frequency | >3000Hz | ||||
| Control mode | Computer synchronous | ||||
| Brightness adjusted range | Manual, automatic operation, stepless continuous adjusted | ||||
| 255 steps. No grey loss | |||||
| Out of control point | <1/10000 | ||||
| Working hours | ≥72hours | ||||
| Mean Time Between Failure | >5000hours | ||||
| Life time | 100000hours | ||||
| Life-all-white(brightness halving) | 50000hours | ||||
| Environment temperature range | Operating temperature range: -20-45℃ | ||||
| Self-check technology | LED spot self-check, communications check, power check, | ||||
| temperature monitor(need customization) | |||||
| Remote monitoring | Remote supervision and control, record potential fault, | ||||
| send out warning signs to the operators.(need customization) | |||||
| Software environment | WindowsNT,Windows1999,WindowsXP | ||||
| Luminous point width between centres | Deviation<3% | ||||
| Brightness uniformity | <10% | ||||
| Color uniformity(chromaticity coordinate) | ±0.003 | ||||
| Power supply request | AC85-264V(50Hz-60Hz) | ||||
| Contrast | (1000:1) | ||||
| System protection | Moistureproof,dustproof,high temperature protection,anti-corrosion,anti-burning,anti-static,anti-vibration | ||||
| Humidity(working) | working:10-95% | ||||
| Humidity(storing) | storing:10-95% | ||||
Trade Terms
1. Payment: T/T, 40% deposits before production, 60% balance to be paid before shippment.
2. Freight charges are quoted under your requests
3. Shipping port: Xiamen, China
4. Warranty time: 2years.If there is no manmade problems,we will repair for you freely.
Our Sevrice
1. Your inquiry about products or prices will be responded within 24 hours. 2. OEM and ODM, any customized LED display, we can help you design and put it into production. 3. Provide distributorship for your unique design and some of our current models. 4. Warranty period: 2 years. If there is no man-made problem, we will repair it for you for free.
FAQ
Q: could you allow a trial order?
A: yes, we are alowing to a trail order.This would enable you to see the high quality of our product and give you the opportunity to test it's superiority.
Q: What's the delevery time?
A: For led moudle 1-5 days, for led display and rental led cabinet 5-12 days after receving the payment.
Q: Where is your nearest sea port?
A: Our neasert sea port is at Shenzhen ,GuangDong ,China.
Q: How to proceed an order for led display?
A: Firstly,let us know your requirements or application.
Secondly, we quote according to your requirements or our suggestion.
Thirdly,customer confirms the samples and places desposit for formal order.
Finally,we arrange the production.
