COB Indoor Die-Cast Aluminum Screen Fixed/Rental Full Color LED Display, LED Module

COB Indoor Die-Cast Aluminum Screen Fixed/Rental Full Color LED Display, LED Module

  • COB Indoor Die-Cast Aluminum Screen Fixed/Rental Full Color LED Display, LED Module
  • COB Indoor Die-Cast Aluminum Screen Fixed/Rental Full Color LED Display, LED Module
  • COB Indoor Die-Cast Aluminum Screen Fixed/Rental Full Color LED Display, LED Module
  • COB Indoor Die-Cast Aluminum Screen Fixed/Rental Full Color LED Display, LED Module
COB Indoor Die-Cast Aluminum Screen Fixed/Rental Full Color LED Display, LED Module
Product Details:
Place of Origin: China ,Guang Dong
Brand Name: Shichuangxinke
Certification: CE RoHS FCC CCC TUV UL
Model Number: SCXK-P4
Payment & Shipping Terms:
Minimum Order Quantity: 1 square meters
Price: USD1900-2100 per square meters
Packaging Details: wooden box flight case, wooden case, carton, it is up to you.
Delivery Time: 7-10 working days after deposit payment received
Payment Terms: L/C, T/T, Western Union
Supply Ability: 5000sqm per month
Contact Now
Detailed Product Description
Resolution/mm: 4 Pixel Configuration: 1R1G1B
Scanning Mode: 1/8 Scanning Module Size: 256x128MM
Cabinet Size: 512x512MM Certificates: CE RoHS FCC CCC UL
Application: Stadium,airport,shopping Mall,street Advertising Material: Aluminum
Warranty: 3-5 Years
Highlight:

Rental Full Color LED Display

,

Full Color LED Display

,

Indoor Die-Cast Aluminum Screen

P4 indoor soft module LED Display,256x128mm LED module 64x32dot





Description:

1. Use high-quality LED chips with strong anti-static ability.

2. Wide viewing angle, smooth display, good visual effects from all angles.

3. The lamp tube and driver IC are integrated, and a multi-circuit structure is adopted,

Even current distribution, low power consumption, and fast heat dissipation.

4. Ultra-high brightness, low attenuation, high reliability, and good weather resistance.

5. High contrast. Using black lamp tubes, the contrast can be increased by 50%.

6. High refresh rate, high grayscale, ghosting elimination, low power consumption, low EMI, leakage prevention, support for multi-channel redundant backup, and point-by-point correction.





Specifications :



outdoor SMD P4
Resolution/mm 4
Pixel configuration 1R1G1B
Pixel density/pixels/m² 62500/m²
Module resolution 256x128
Module size/mm 512x512MM
View distance 14-300m
Single point brightness adjust Can be added
Single point color adjust Can be added
White balance brightness >7500cd/㎡
Color temperature 6500K-9500K
Horizontal view angle 120(degrees)
Vertical view angle 60(degrees)
Signal Process bit 10 or 16bit
Grey process 1024x1024x1024 16834x16834x16834 65536x65536x65536
Control distances Internet cable:100m, multimembrane:500m, monofilm:2km
Driving mode Constant driving current
Scanning mode 1/8 SCANNING
Frame rate 60Hz
Refresh frequency >3000Hz
Control mode Computer synchronous
Brightness adjusted range Manual, automatic operation, stepless continuous adjusted
255 steps. No grey loss
Out of control point <1/10000
Working hours ≥72hours
Mean Time Between Failure >5000hours
Life time 100000hours
Life-all-white(brightness halving) 50000hours
Environment temperature range Operating temperature range: -20-45℃
Self-check technology LED spot self-check, communications check, power check,
temperature monitor(need customization)
Remote monitoring Remote supervision and control, record potential fault,
send out warning signs to the operators.(need customization)
Software environment WindowsNT,Windows1999,WindowsXP
Luminous point width between centres Deviation<3%
Brightness uniformity <10%
Color uniformity(chromaticity coordinate) ±0.003
Power supply request AC85-264V(50Hz-60Hz)
Contrast (1000:1)
System protection Moistureproof,dustproof,high temperature protection,anti-corrosion,anti-burning,anti-static,anti-vibration
Humidity(working) working:10-95%
Humidity(storing) storing:10-95%



after-sale service:

1. Lifetime free maintenance and upgrade.
2. Complaint respond period not exceed 24 hours; maintenance guidance and problem solution supplied in 48 hours.
3. Customer satisfaction tracking report.
4. Free technician training.
5. Full set of documents free of charge, which including installation guidance, software operation manual, easy maintenance
manual and control system software CD and so on.
6. Special service for big project, such as stadium, exhibitions, squares and so on.





COB Indoor Die-Cast Aluminum Screen Fixed/Rental Full Color LED Display, LED Module 0

COB Indoor Die-Cast Aluminum Screen Fixed/Rental Full Color LED Display, LED Module 1COB Indoor Die-Cast Aluminum Screen Fixed/Rental Full Color LED Display, LED Module 2COB Indoor Die-Cast Aluminum Screen Fixed/Rental Full Color LED Display, LED Module 3COB Indoor Die-Cast Aluminum Screen Fixed/Rental Full Color LED Display, LED Module 4

COB Indoor Die-Cast Aluminum Screen Fixed/Rental Full Color LED Display, LED Module 5COB Indoor Die-Cast Aluminum Screen Fixed/Rental Full Color LED Display, LED Module 6

FAQ



Q1: How can I select your product?

Firstly you need to tell us your requirement such as the viewing distance, size, installation height, and some other details for the LED screen that you want. And then we will give you a recommendation.

Q2:What if I don't know how to install the screen?

1. We will provide your details drawing for installation led screen, But you need provide us on-site picture for installation

place, and we can guide on line.

2. Training 2 people in the factory.

3. We can send our engineers to your country to guide how to install the screen.

Q3:What is the minimum order quantity?

Qty: 1 unit. Different order quantity different price.

Q4:I would like to ask you if it's possible to have my logo on the product.

Logo printing service is available for mass order based on our M.O.Q

Q5:What if I don't know how to maintain the screen?

We will provide you the operation manual, software when you place the order and also we can remote to help you to adjust the software by teamviwer.

Q6: How to deliver the my goods?

It denpens on your budget and time you need the led screen. Regularly, if the quantity is less, we guggest to deliver by air, otherwise by sea to save the costs.

Q7: How about your warranty?

We provide 3 year warranty for all of our products and supply life-time maintenance.

Q8: What kind of packaging do you provide?

We provide flight case, wooden case and carton.

Q9: How long will it take me to get the product?

We will send the goods as quick as possible, but oftenly it will take 1-2 weeks to get the goods according to the distance ,and some other necessary processes.

Q9: What kind of certification do you get?

We have ISO9001 Quality Control certification. Also CE/ROHS/FCC/CCC etc for different countries’ market.
