Shenzhen Shichuangxinke Electronics Co.,Ltd
professional makes good quality, provide perfect product and service for every customer.
 |
| Place of Origin: | China(Mianland) |
| Brand Name: | SCXK |
| Certification: | CE,RoHS,FCC,CCC,SAA,TUV,UL |
| Model Number: | SCXK-P1.667 |
| Minimum Order Quantity: | Negotiations |
|---|---|
| Price: | Negotiations |
| Packaging Details: | Wooden and flight cases,it's up to you. |
| Delivery Time: | 7-10 working days after payment |
| Payment Terms: | Western Union, T/T |
| Supply Ability: | 5000sqs/month |
| Brand Name: | RGB LED Display | Brightness: | ≥1200cd/sq |
|---|---|---|---|
| Certifications: | CE,RoHS,FCC,CCC,SAA,TUV,UL | LED Chip: | Epistar |
| Waterproof: | IP34 | Operation Power: | 220V 60HZ |
| Module Size: | 200*150mm | Cabinet Size: | 400*300mm |
| Control System: | LSN | Pixel Density: | 360000dots/sq |
| Resolution: | 120*90 | Scan Mode: | 1/30 |
| LED Type: | SMD2121 | Indoor Options: | P1.667,P1.923,P2,P2.5,P3,P3.91,P4,P5,P6,P10... |
Indoor P1.667 RGB LED Display 200*150mm Module LSN System Epistar LED Chip
Shenzhen Shichuangxinke Electronics Co., Ltd. was established in 2005, we have become a pioneer in the LED industry, developing double-sided LED screens, gas station LEDs, taxi roof LED screens, outdoor LED screens, indoor LED screens, outdoor LED modules, indoor LED modules. We are proud to provide a comprehensive service to our customers, earning their trust and respect.
Specifications :
| Indoor P1.667 LED Display | |||||
| Resolution/mm | 1.667 | ||||
| Pixel configuration | 1R1G1B | ||||
| Pixel density/pixels/m² | 360000/square meter | ||||
| Module resolution | 120x90 | ||||
| Module size/mm | 200x150 | ||||
| View distance | 14-300m | ||||
| Single point brightness adjust | Can be added | ||||
| Single point color adjust | Can be added | ||||
| White balance brightness | >1200cd/square meter | ||||
| Color temperature | 6500K-9500K | ||||
| Horizontal view angle | 120(degrees) | ||||
| Vertical view angle | 60(degrees) | ||||
| Signal Process bit | 10 or 16bit | ||||
| Grey process | 1024x1024x1024 16834x16834x16834 65536x65536x65536 | ||||
| Control distances | Internet cable:100m, multimembrane:500m, monofilm:2km | ||||
| Driving mode | Constant driving current | ||||
| Scanning mode | 1/30 SCANNING | ||||
| Frame rate | 60Hz | ||||
| Refresh frequency | >3000Hz | ||||
| Control mode | Computer synchronous | ||||
| Brightness adjusted range | Manual, automatic operation, stepless continuous adjusted | ||||
| 255 steps. No grey loss | |||||
| Out of control point | <1/10000 | ||||
| Working hours | ≥72hours | ||||
| Mean Time Between Failure | >5000hours | ||||
| Life time | 100000hours | ||||
| Life-all-white(brightness halving) | 50000hours | ||||
| Environment temperature range | Operating temperature range: -20-45℃ | ||||
| Self-check technology | LED spot self-check, communications check, power check, | ||||
| temperature monitor(need customization) | |||||
| Remote monitoring | Remote supervision and control, record potential fault, | ||||
| send out warning signs to the operators.(need customization) | |||||
| Software environment | WindowsNT,Windows1999,WindowsXP | ||||
| Luminous point width between centres | Deviation<3% | ||||
| Brightness uniformity | <10% | ||||
| Color uniformity(chromaticity coordinate) | ±0.003 | ||||
| Power supply request | AC85-264V(50Hz-60Hz) | ||||
| Contrast | (1000:1) | ||||
| System protection | Moistureproof,dustproof,high temperature protection,anti-corrosion,anti-burning,anti-static,anti-vibration | ||||
| Humidity(working) | working:10-95% | ||||
| Humidity(storing) | storing:10-95% | ||||
Our services
We have a complete customer service system and a well-trained, strong and skilled service team to provide customers with comprehensive pre-sales service, product service and after-sales service.
Our customer service department has more than a dozen skilled and experienced technical support engineers who are responsible for the technical support of all LED display products we provide worldwide.
We continue to improve the level and quality of service, quickly and effectively meet customer needs and protect the interests of customers.
Service Concept
We advocate proactive service, honesty and trustworthiness, respond quickly to customer problems, and do everything possible to meet customer needs.
Service Contents
1.24-hour hotline service, including consultation and technical guidance.
2.Online service.
3.LED display screen fault repair.
4.Free professional technical training
5.Paid software upgrade.
6.Warranty service.
7.Engineering technical service.
Warranty Period
Each of our LED display products comes with at least two years warranty and a lifetime maintanance services.
FAQ
Q1: What is the control system? How is it?
A: We use Nova Taurus Series asynchronous control system. Support cluster play and management. Support APP/Phone/ WIFI/ Ipad/ Laptop/ PC/ Cloud control. It’s very easy and convenient to control.
Q2: Can I have a sample order for led screen?
A: Yes, we welcome sample order to test and check quality. Mixed samples areacceptable.
Q3:Is it OK to print my logo on product?
A: Yes. Please inform us formally before our production and confirm the design firstly based on our sample.
Q4: What is your best service?
1: One to one sales engineer to customer responsibility system;
2. Know your project and provide the best solution for it;
3. Track your order and let you know each step and detail of it;
4. Teach you how to install and use the screen;
5. Care the subsequent use of your screen and ensure your after - sales service be well.
Q5. How about your delivery time?
A: Generally, it will take 7-15 days after receiving your deposit. The specific delivery time depends on the items and the quantity of your order.
Q6:How about your Warranty Term?
A: 2-year warranty. Structure design, installation problem, system problem, how to use the screen…don’t worry, we have professional after-sale team to solve your any questions after you placed an order. And your exclusive sales engineer will also help you get over any problems.
