COB Fine Pitch 0.9mm Full Color Indoor LED Video Wall Display Panel

Name: COB Fine Pitch 0.9mm Full Color Indoor LED Video Wall Display Panel
Brand: Shenzhen ShiXin Display Technology Co.,Ltd
SKU: P0.9
Price: 1500 USD
Availability: InStock

Brand Name:	SCX-COB P0.9 ,P1.25 ,P1.56
Model Number:	P0.9
MOQ:	2 sqm
Price:	1500usd per sqm
Payment Terms:	L/C, D/P, T/T, Western Union, MoneyGram
Supply Ability:	4500 sqm month

Detail Information

Product Description

Detail Information

Place of Origin:

CHINA

Certification:

CB,FCC CE

Pixel Pitch:

0.9mm

Ip Protection:

Indoor IP43

Weight:

4kg

Pixel Density:

1137777dots/sqm

Cabinet Resolution:

640x360

Maintenance Method:

Front Maintenance

Moudle Size:

300X168.75mm

Control System:

Nova Star

Operating Voltage:

DC2.8V

Scanning Mode:

1/64

Maximum Power:

≤50W

Packaging Details:

wooden case, flight case

Highlight:

Videotron Display Screen Panel

Fine Pitch Indoor LED Video Wall

4K Indoor LED Video Wall

Product Description

COB Fine Pitch 4K P0.9 P1.25 P1.56 Indoor LED Video Wall Display Panel

Key Specifications

Attribute	Value
Pixel Pitch	0.9mm
IP Protection	Indoor IP43
Weight	4kg
Pixel Density	1,137,777 dots/sqm
Cabinet Resolution	640×360
Maintenance Method	Front Maintenance
Module Size	300×168.75mm
Control System	Nova Star
Operating Voltage	DC2.8V
Scanning Mode	1/64
Maximum Power	≤50W

Technical Parameters

Parameter	Specification
Product Model	Full Flip-Chip COB
Applications	Indoor
LED Type	Full Flip-Chip COB
Panel Size	600×337.5×42mm
Panel Weight	6±0.5Kg/panel
Brightness	600 cd/m²
Color Temperature	3000-13000K adjustable
Refresh Frequency	≥3840Hz
Viewing Angle	H140°/V140°
Contrast Ratio	1,000,000:1
LED Life	100,000 hours

Manufacturing Technique Comparison

Feature	Flip COB	Standard COB	SMD	IMB
Technical Difficulty	High	Moderately High	Low	Medium
Display Quality	Excellent	Excellent	Good	Average
Stability & Protection	Excellent	Good	Average	Average
Energy Efficiency	High	High	Moderate	Low
Cost	High	Moderately High	Low	Low

Project Case

Frequently Asked Questions

Can I order a sample of the LED display?

Yes, we welcome clients to order samples for quality testing.

What is the lead time?

Samples require 5-7 days, while bulk orders take 7-14 working days.

How are goods shipped and how long does delivery take?

LED screens are packed in wooden boxes or flight cases. We typically ship by sea, but DHL, UPS, FedEx or TNT are also available.

How do I place an order?

Please provide your requirements for a customized quote. After confirmation, we'll send a Proforma Invoice and arrange deposit payment. The balance is paid before shipment.

Can I have my logo printed on the product?

Yes, your logo can be printed on the cabinet.

What warranty do you offer?

We provide a 2-3 year warranty on our products.

What is the screen weight?

Aluminum cabinets weigh 22-30kg/sqm, while iron cabinets weigh 35-55kg/sqm.

What components are needed if I only purchase LED modules?

For fixed installations, you'll need sending cards, receiving cards, power supplies, and various cables, which we can provide.

How is the LED screen installed?

Cabinet-based screens are simple to install by connecting cabinets. For module-only purchases, we provide detailed installation instructions.

How is the LED screen debugged?

We pre-debug screens based on your specifications. After installation, simply connect the sending card. Remote technical support is also available.
