P10 Outdoor Full Color LED Display 10mm Pixel Pitch IP65 Waterproof

P10 Outdoor Full Color LED Display 10mm Pixel Pitch IP65 Waterproof

Brand Name: SCXK
Model Number: P10
MOQ: 3 sqm
Price: negotiation
Payment Terms: T/T, Western Union, Money Gram,
Supply Ability: 5000 sqm per month
Detail Information
Product Description
Detail Information
Place of Origin:
ShenZhen in China
Certification:
CE/ROHS/FCC/ISO/CB/UL
Pixel Pitch:
10mm
Led Type:
SMD3535
Display Function:
Video/Text/Image
Waterproof:
IP65
MBI:
5024
Viewing Angle:
H:160 V:140
Optimal Viewing Distance:
>=10m
Voltage:
DC5V
Brightness:
>=5000cd/m2
Module Size:
320*160mm
Packaging Details:
flight case, wooden case, carton, it is up to you.
Highlight:

P10 Outdoor Advertising Led Display Screen

,

P10 Waterproof Led Display Screen

,

Outdoor Advertising Led Display Screen

Product Description
Waterproof Video Big Screen P10 Full Color Outdoor Advertising LED Display Screen
Key Specifications
Attribute Value
Pixel pitch 10mm
Tube Chip Color Full color
LED Type SMD3535
Display Function Video/Text/Image
Waterproof IP65
MBI 5024
Viewing angle H:160° V:140°
Optimal viewing distance ≥10m
Voltage DC5V
Brightness ≥5000cd/m²
Module size 320×160mm
Manufacturer Advantages
  • OEM service with no minimum order quantity
  • Easy installation with regular items in stock
  • Free design drawings available upon request
  • Remote control and adjustment capabilities
  • Flexible packaging options (wooden case or flight case)
  • 24-hour response time for inquiries
  • Fast delivery: 6-8 working days typically
  • Expert R&D team offering factory-direct pricing and quality assurance
Production Process
  1. Incoming Inspection
  2. SMD
  3. Plug-in
  4. Wave Soldering
  5. After Welding
  6. Testing
  7. Semi Finished Aging
  8. Module Assembly
  9. Gluing
  10. Finished Aging
  11. Detection Finishing Warehousing
Technical Specifications
Lamp size 3535
Pixel configuration RGB 3 in 1
Pixel density 10000/m²
Module resolution 32×16
White balance brightness >5000cd/㎡
Refresh frequency >1200Hz
Working temperature range -20°C to 45°C
Average power consumption <200W/㎡
Lifetime 100,000 hours
Key Features

• Automatic brightness adjustment based on ambient lighting conditions for energy efficiency

• High refresh rate and grayscale for realistic, high-quality visuals

• Flexible content management for dynamic advertising

• Remote monitoring capabilities

• Programmable on/off scheduling for unattended operation

Packaging & Shipping

Available in wooden cases or flight cases. Shipping options include sea freight, air freight, or express courier services like DHL.

P10 Outdoor Full Color LED Display 10mm Pixel Pitch IP65 Waterproof 0
Project Showcase

Successfully implemented in Malaysia:

P10 Outdoor Full Color LED Display 10mm Pixel Pitch IP65 Waterproof 1
